  • Page 1 1 User manual Gebrauchsanleitung Gas built-in oven Einbau Gas-Backofen EOG 21300...
  • Page 3 Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable.
  • Page 4: Table Of Contents

    4 electrolux Contents For the User Important safety information ................5 Description of the appliance ................8 Controls ......................9 Before using the oven for the first time .............. 11 Using the oven ....................12 Using the gas oven ..................13 Cooking chart-Gas oven ..................
  • Page 5: Important Safety Information

    5 ENGLISH ENGLISH ENGLISH ENGLISH ENGLISH Important safety information These warnings are provided for the safety of the users and those living with them. So read them carefully before connecting and/or using the appliance. Always keep these user instructions with the appliance. Should the...
  • Page 6 6 electrolux • Always stand back from the oven Maintenance and Cleaning Maintenance and Cleaning Maintenance and Cleaning Maintenance and Cleaning Maintenance and Cleaning when opening the oven door during • Only clean this oven in accordance with cooking or at the end of it to allow the instructions.
  • Page 7 This appliance conforms with the following ECC Directives : (Low Voltage Directive); 2006/95 (EMC Directive); 89/336 (General Directive); 93/68 (Gas Appliances); 90/396 and subsequent modifications. MANUFACTURER: ELECTROLUX HOME PRODUCTS ITALY S.p.A. Viale Bologna, 298 47100 FORLÌ (Italy)
  • Page 8: Description Of The Appliance

    8 electrolux Description of the appliance 1 . 1 . 1 . 1 . 1 . Control panel 2 . 2 . 2 . 2 . 2 . Minute minder 3 . 3 . 3 . 3 . 3 . Oven function (Light, Grill & Fan) control knob 4 .
  • Page 9: Controls

    9 Controls Oven Function Control Knob (Light, Grill & Fan) The oven is off Oven Light - The oven light will be on without any cooking function. Electric grill and rotisserie operation Range of temperature adjustment for the electric grill (from a minimum of about 50ºC to a maximum of about...
  • Page 10: Minute Minder

    10 electrolux Gas Oven Control Knob Oven burner off 150 - 240 150 - 240 Range of temperature 150 - 240 150 - 240 150 - 240 adjustment for conventional cooking Minute minder The minute minder will mark the end of a timed period with an acoustic alarm.
  • Page 11: Before Using The Oven For The First Time

    11 Before using the oven for the first time Remove all packaging, both inside and outside the oven, before using the oven. Before using for the first time, the oven should be heated up without food. During this time, an unpleasant odour may be emitted.
  • Page 12: Using The Oven

    12 electrolux Using the oven The oven is supplied with an exclusive system which produces a natural circulation of air and the constant recycling of steam. This system makes it possible to cook in a steamy environment and keep the dishes soft inside and crusty outside.
  • Page 13: Using The Gas Oven

    13 Using the gas oven Oven safety device Always cook with the oven Always cook with the oven Always cook with the oven Always cook with the oven Always cook with the oven door closed. door closed. door closed.
  • Page 14 14 electrolux Manual ignition (in case of lack of electrical supply) 1. Open the oven door. 2. Hold a flame near the hole in the bottom of the oven cavity as shown in the relevant picture. 3. At the same time press the gas oven...
  • Page 15: Cooking Chart-Gas Oven

    15 Cooking chart - Gas oven Cooking times do not include pre-heating time. A short oven pre-heating Cooking times do not include pre-heating time. A short oven pre-heating Cooking times do not include pre-heating time. A short oven pre-heating Cooking times do not include pre-heating time.
  • Page 16: Using The Fan Oven

    16 electrolux Using the fan oven Using the fan oven Using the fan oven Using the fan oven Using the fan oven Always cook with the oven door closed. The air inside the oven is heated by the gas burner and the fan circulates hot air to maintain an even temperature inside the oven.
  • Page 17: Cooking Chart-Fan Oven

    17 Cooking chart-Fan oven Cooking times do not include pre-heating time. A short oven pre- Cooking times do not include pre-heating time. A short oven pre- Cooking times do not include pre-heating time. A short oven pre- Cooking times do not include pre-heating time. A short oven pre- Cooking times do not include pre-heating time.
  • Page 18: Grilling

    18 electrolux Grilling Grilling must be carried out Hints and Tips with the oven door closed. Most foods should be placed on the grid in the grill pan to allow maximum How to Use the Grill circulation of air to lift the food out of 1.
  • Page 19: Cooking Chart-Grilling

    19 Cooking chart - Grilling Cooking times do not include pre-heating time. A short oven pre-heating (about 10 minutes) is necessary before any cooking. Cooking time in Quantity Grilling TYPE OF DISH minutes 1st side Pieces temp.°C 2nd side...
  • Page 20: Turnspit

    20 electrolux T T T T T ur ur ur ur ur nspit nspit nspit nspit nspit To use the turnspit, proceed as follows: 1. Insert the spit frame on the second guide from the bottom, as shown in the figure.
  • Page 21: Cleaning And Maintenance

    21 Cleaning and Maintenance Before any maintenance or Before any maintenance or Before any maintenance or • Rust removers Before any maintenance or Before any maintenance or cleaning can be carried out, cleaning can be carried out, cleaning can be carried out,...
  • Page 22: Cleaning The Oven Door

    22 electrolux Cleaning the Oven Door Before cleaning the oven door, we recommend you to remove it from the oven. Proceed as follows: 1. open the oven door completely; Fig. A 2. find the hinges linking the door to the oven (Fig.
  • Page 23: Replacing The Oven Light

    23 possibility of the panel shattering. Contact your local Service Centre who will be pleased to advise further. Replacing The Oven Light Disconnect the appliance from the Disconnect the appliance from the Disconnect the appliance from the Disconnect the appliance from the...
  • Page 24: Something Not Working

    24 electrolux Something not working If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee.
  • Page 25: For The Installer Technical Data

    Electrolux Service Force Centre. the fault is not a mechanical or Please note that it will be necessary to electrical breakdown.
  • Page 26: Important Safety Requirements

    26 electrolux Important safety requirements Installation Installation Installation Installation Installation to gas combustion can naturally flow in the room. (The installer must follow the The following instructions about in- rules in force). stallation and maintenance are meant for The air flow into the room must come...
  • Page 27: Gas Connection

    27 Gas connection flexible View The use of rubber flexible hoses from metallic pipe is not permitted. above gasket Connecting the appliance to the gas supply The gas supply connection ramp is located in the upper side of the oven, gas supply ramp right behind the control panel.
  • Page 28 28 electrolux connection using leak detection fluid. Never use a flame for the leak- proof test ! Check the gas supply ramp and the gas connection pipe are not squeezed while the oven is positioned into the recess. The use of a gas cooking...
  • Page 29: Adaptation To Different Types Of Gas

    29 Adaptation to different types of gas IMPORTANT The adaptation to different types of gas should only be undertaken by a competent and qualified engineer. It is important to note that this model is designed for use with natural gas but can be converted for use with LPG providing the correct injectors are fitted.
  • Page 30 30 electrolux Gas Oven Burner Data INJECTOR NOMINAL NOMINALGAS REDUCED BY-PASS NOMINAL TYPE MARK FLOW NEEDLE 1/100 mm POWER POWER (1/100 mm) PRESSURE (kW) (kW) (mbar) Natural Gas 0,257 Reg. (G20) Liquid Gas (G30/G31) Minimum level adjustment of gas oven burner...
  • Page 31: Instructions For Building In

    31 gas oven control knob from 240 to 150. 8. Should the oven gas burner flame fail when performing point 7, repeat the whole procedure from point 1 to point 7, until a small regular flame is obtained on the complete gas oven burner crown.
  • Page 32 32 electrolux Please ensure that when the oven is installed it is easily accessible for the engineer in the event of a breakdown. BUILDING IN BUILDING IN BUILDING IN BUILDING IN BUILDING IN The surround or cabinet into which the oven...
  • Page 33: Electrical Connection

    33 an omnipole switch, with a minimum gap Electrical connection between contacts of 3 mm, suitable for the required load and in compliance with The instructions given below The instructions given below The instructions given below The instructions given below The instructions given below rules in force.
  • Page 34: Service And Spare Parts

    • The appliance is installed and used in accordance with instructions issued by Electrolux and is only used within the home, i.e. is not used for commercial pur- poses. • The appliance is installed in accordance with all relevant regulations in force within your new country of residence.
  • Page 35 35...
