- Page 1 1 User manual Gas built-in oven EOG 21302 X...
- Page 3 Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable.
-
Page 4: Table Of Contents
4 electrolux Contents For the User Important safety information ................5 Description of the appliance ................8 Controls ......................9 Before using the oven for the first time ............. 11 Using the oven ....................12 Using the gas oven ..................13 Cooking chart-Gas oven .................. -
Page 5: Important Safety Information
5 ENGLISH Important safety information These warnings are provided for the safety of the users and those living with them. So read them carefully before connecting and/or using the appliance. Always keep these user instructions with the appliance. Should the... - Page 6 6 electrolux • Always stand back from the oven when opening the oven door during cooking or at the end of it to allow any build up of steam or heat to release. • Do not block any of the oven vents.
-
Page 7: Maintenance And Cleaning
This appliance conforms with the following ECC Directives : (Low Voltage Directive); 2006/95 (EMC Directive); 2004/108 (Gas Appliances); 90/396 and subsequent modifications. MANUFACTURER: ELECTROLUX ITALIA S.p.A. C.so Lino Zanussi 30 33080 Porcia (PN) - Italy... -
Page 8: Description Of The Appliance
8 electrolux Description of the appliance Control panel Minute minder Oven function (Light, Grill & Fan) control knob Gas oven control knob Grill control light Mains on light Grill Oven lamp Turnspit hole 10. Oven fan 11. Oven cavity bottom plate... -
Page 9: Controls
9 Controls Oven function control knob (Light, Grill & Fan) The oven is off. Oven Light - The oven light will be on without any cooking function. Electric grill and rotisserie operation Range of temperature adjustment for the electric grill (from a minimum of about 50ºC to a maximum of about... -
Page 10: Minute Minder
10 electrolux Gas oven control knob Oven burner off min. - 240 Range of temperature adjustment for conventional cooking Minute minder The minute minder will mark the end of a timed period with an acoustic alarm. The maximum timing is 60 minutes. -
Page 11: Before Using The Oven For The First Time
11 Before using the oven for the first time Remove all packaging, both inside and outside the oven, before using the oven. Before using for the first time, the oven should be heated up without food. During this time, an unpleasant odour may be emitted. -
Page 12: Using The Oven
12 electrolux Using the oven The oven is supplied with an exclusive system which produces a natural circulation of air and the constant recycling of steam. This system makes it possible to cook in a steamy environment and keep the dishes soft inside and crusty outside. -
Page 13: Using The Gas Oven
13 Using the gas oven Always cook with the oven Oven safety device door closed. The gas oven features a thermocou- ple; if for any reason the flame should To ignite the oven gas burner: extinguish, the device will stop the gas 1. - Page 14 14 electrolux Manual ignition (in case of lack of electrical supply) 1. Open the oven door. 2. Hold a flame near the hole in the bottom of the oven cavity as shown in the relevant picture. 3. At the same time press the gas oven...
-
Page 15: Cooking Chart-Gas Oven
15 Cooking chart - Gas oven Cooking times do not include pre-heating time. A short oven pre-heating (about 10 minutes) is necessary before any cooking. TEMP. SHELF COOKING FOOD (°C) TIME POSITIONS MEAT & POULTRY Beef with bone min. -
Page 16: Using The Fan Oven
16 electrolux Using the fan oven Always cook with the oven door closed. The air inside the oven is heated by the gas burner and the fan circulates hot air to maintain an even temperature inside the oven. To use the fan oven: 1. -
Page 17: Cooking Chart-Fan Oven
17 Cooking chart-Fan oven Cooking times do not include pre-heating time. A short oven pre- heating (about 10 minutes) is necessary before any cooking. TEMP. COOKING SHELF FOOD (°C) POSITIONS TIME MEAT & POULTRY Beef with bone min. 2 or 3... -
Page 18: Grilling
18 electrolux Grilling Grilling must be carried out Hints and Tips with the oven door closed. - Most foods should be placed on the grid in the grill pan to allow maximum How to use the grill circulation of air to lift the food out of 1. -
Page 19: Cooking Chart-Grilling
19 Cooking chart - Grilling Cooking times do not include pre-heating time. A short oven pre-heating (about 10 minutes) is necessary before any cooking. Cooking time in Quantity Grilling TYPE OF DISH minutes 1st side Pieces temp.°C 2nd side... -
Page 20: Turnspit
20 electrolux Turnspit The forks and the spit of the turnspit are pointed and sharp. When using, manipulate them with caution to avoid any injury. To use the turnspit, proceed as follows: 1. Insert the spit frame on the second guide from the bottom, as shown in the figure. -
Page 21: Cleaning And Maintenance
21 Cleaning and Maintenance Before any maintenance or • Rust removers cleaning can be carried out, • Bath/Sink stain removers. you must DISCONNECT the Clean the outer and inner door glass appliance from the electrical using warm soapy water. -
Page 22: Cleaning The Oven Door
22 electrolux Cleaning the oven door Before cleaning the oven door, we recommend you to remove it from the oven. Proceed as follows: 1. open the oven door completely; Fig. A 2. find the hinges linking the door to the oven (Fig. -
Page 23: Replacing The Oven Light
23 possibility of the panel shattering. Contact your local Service Centre who will be pleased to advise further. Replacing The oven light Disconnect the appliance from the electrical supply. If the oven bulb needs replacing, it must comply with the following specifications:... -
Page 24: Something Not Working
24 electrolux Something not working If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 25: For The Installer Technical Data
Electrolux Service Force Centre. the fault is not a mechanical or Please note that it will be necessary to electrical breakdown. -
Page 26: Important Safety Requirements
26 electrolux Important safety requirements Installation to gas combustion can naturally flow in the room. (The installer must follow the The following instructions about in- rules in force). stallation and maintenance are meant for The air flow into the room must come... -
Page 27: Gas Connection
27 Gas connection View flexible The use of rubber flexible hoses from metallic pipe is not permitted. above gasket Connecting the appliance to the gas supply The gas supply connection ramp is located in the upper side of the oven, gas supply ramp right behind the control panel. - Page 28 28 electrolux connection using leak detection fluid. Never use a flame for the leak- proof test ! Check the gas supply ramp and the gas connection pipe are not squeezed while the oven is positioned into the recess. The use of a gas cooking...
-
Page 29: Adaptation To Different Types Of Gas
29 Adaptation to different types of gas IMPORTANT The adaptation to different types of gas should only be undertaken by a competent and qualified engineer. It is important to note that this model is designed for use with natural gas but can be converted for use with LPG providing the correct injectors are fitted. - Page 30 30 electrolux Gas Oven Burner Data INJECTOR NOMINAL NOMINALGAS REDUCED BY-PASS NOMINAL TYPE MARK FLOW NEEDLE 1/100 mm POWER POWER (1/100 mm) PRESSURE (kW) (kW) (mbar) Natural Gas 0,257 Reg. (G20) Liquid Gas (G30/G31) 28-30/37 Minimum level adjustment of gas oven burner...
-
Page 31: Instructions For Building In
31 gas oven control knob from 240 to min. 8. Should the oven gas burner flame fail when performing point 7, repeat the whole procedure from point 1 to point 7, until a small regular flame is obtained on the complete gas oven burner crown. - Page 32 32 electrolux Please ensure that when the oven is installed it is easily accessible for the engineer in the event of a breakdown. BUILDING IN The surround or cabinet into which the oven will be built must comply with these...
- Page 33 33 Securing the appliance to the cabinet 1. Open the oven door. 2. Fasten the oven to the cabinet placing the four distance holders "A" (supplied with the appliance) which fit exactly into the holes in the frame and then fit the four wood screws "B"...
-
Page 34: Electrical Connection
34 electrolux Electrical connection The instructions given below are designed specifically for a qualified installer and should aid him or her to perform all installation, adjustment, and maintenance operations with absolute precision and in compliance with all current legislation and regulations. We... - Page 35 35 necessary to fit between the appliance and the mains an omnipole switch, with a minimum gap between contacts of 3 mm, suitable for the required load and in compliance with rules in force. The green & yellow ground wire must not be interrupted by the switch and it should be 2-3 cm.
-
Page 36: Service And Spare Parts
36 electrolux Service and spare parts If after the checks listed in the chapter "Something working", appliance still does not work correctly, contact your local Service Centre, specifying the type of malfunctioning, the appliance model (Mod.), the product number (Prod. No.) and the serial number (Ser. -
Page 37: European Guarantee
• The appliance is installed and used in accordance with instructions issued by Electrolux and is only used within the home, i.e. is not used for commercial pur- poses. • The appliance is installed in accordance with all relevant regulations in force within your new country of residence. - Page 38 38 electrolux...
- Page 39 39...
- Page 40 35905-0802 11/08 R.A...
