  Summary of Contents for Electrolux EDE 5300

  • Page 1 T U M B L E D RY E R S E C A D O R A S E C A D O R INSTRUCTION BOOKLET INSTRUCTION BOOKLET INSTRUCCIONES PARA EL USO INSTRUCCIONES PARA EL USO INSTRUÇÕES DE UTILISAÇÃO INSTRUÇÕES DE UTILISAÇÃO EDE 5300 125994850 125 994 852...
  • Page 2: Dear Customer

    Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. Transport damages After unpacking the machine please check it is not damaged.
  • Page 3: Table Of Contents

    Contents Important safety information Maintenance and Cleaning ....4 ....14 External cleaning ..........14 Disposal ............5 Cleaning the door..........14 Cleaning the filters ..........14 Tips for environmental protection Something not working? ....15 Description of the appliance ....6 Installation ............7 Unpacking ............7 Positioning ............7 Fitting the vent hose ..........7-8 Electrical connection ..........8 Stacking kit............8...
  • Page 4: Important Safety Information

    • This tumble dryer is designed to be vented through malfunctioning. Contact your local Electrolux to the open air. It should have its own ventilation Service Centre. Always insist on genuine system which should not be joined with any other Electrolux spare parts.
  • Page 5: Disposal

    Disposal • Old appliance • Packaging materials The materials marked with the symbol The symbol on the product or on its packaging recyclable. indicates that this product may not be treated as This means that they can be recycled by disposing of household waste.
  • Page 6: Description Of The Appliance

    Description of the appliance 01 Control panel 02 Fluff filters 03 Rating Plate 04 Adjustable feet 05 Side vent outlets 06 Ring nut 07 Rear vent outlet...
  • Page 7: Installation

    Installation Warning! Unpacking Slide out the polythene bag with the polystyrene stuffing before using the appliance. Pull off adhesive strips from inside machine on top of drum. P0046 The feet must never be removed. Do not restrict the floor clearance through deep- pile carpets, strips of wood or similar.
  • Page 8: Electrical Connection

    “exhaust” at least beyond the kitchen Please contact the nearest Electrolux Service units; preferable outside the kitchen. Centre. In order to prevent the appliance from overheating, it is important that the steam exhaust is unobstructed.
  • Page 9: Use

    The control panel 1 Programme chart 6 Start button This will help you to select the correct programme for Press this button for about 2 seconds to start the drying. dryer after having selected the programme. If the door is opened while the programme is running, this button must be pressed again after 2 Mains-ON light closing the door in order to restart the programme...
  • Page 10 “Anti-creasing phase” light This light flashes alternately with the light at the end of the drying phase (after cooling) and during the anti-creasing phase. If only light flashes, this means that the anti- creasing phase has finished. 8 Programme/Time selector dial Allows you to select electronically controlled or time controlled drying.
  • Page 11: Programme Chart

    Programme chart Automatic drying (electronic programmes) Degree of drying Max-load Type of laundry Programme required extra dry Cotton B (*) store dry slightly damp D (*) iron dry machine iron dry Synthetics extra dry G (*) store dry slightly damp (*) According to CEI 1121 Standards.
  • Page 12: Operating Sequence

    Release the ON/OFF button (the mains-ON light Operating sequence goes out) and immediately remove the laundry. Before using your tumble dryer for the first time, we recommend to place a few damp cloths inside the After each use appliance and dry for 30 minutes. There may be dust inside a brand new tumble dryer.
  • Page 13: Useful Hints

    • Avoid drying dark clothes with light coloured fluffy Useful hints items such as towels as they could attract the fluff. • Try to load to the maximum capacity of the • The laundry must be thoroughly spun before machine as small loads are uneconomical. tumble drying.
  • Page 14: Maintenance And Cleaning

    Maintenance and Cleaning You must disconnect the appliance from the If necessary the filters can be cleaned under running electricity supply, before you can carry out any water using a brush. In this case remove the filter in cleaning or maintenance work. the door opening as per picture (it can be positioned with the tooth facing to the left or to the right).
  • Page 15: Something Not Working

    Something not working? Before contacting your local Electrolux Service Centre, please make the following checks: Problem Possible cause • The door is open. • The dryer does not work: • The plug is not fitted into the wall socket. • There is no electricity supply from the wall socket.
