Icom IC-F50 Instruction Manual page 57

D Rapid charging with the BC-121N+AD-100
The optional BC-121N allows up to 6 battery packs to be charged
simultaneously. The following are additionally required.
• Six AD-100.
• An AC adapter (BC-157) or the DC power cable (OPC-656)
AC adapter
(Purchase
separately.)
Transceiver
Turn power OFF
Battery pack
DC power cable (OPC-656)
(Connect with the DC power supply;
13.8 V/at least 7 A)
BATTERY CHARGING
AD-100 charger
adapters are installed
in each slot.
6
6
50
