Installation Layout; Interconnections - Generac Power Systems Guardian Elite 05402 Specification Sheet

INTERCONNECTIONS

INSTALLATION LAYOUT

CONTROL PANEL R TYPE
BATTERY CHARGER IS
ENCLOSED WITHIN
46 46
DOOR TYP DOOR TYP
AUTO
OFF
OFF
ON
MANUAL SET
EXERCISE
TIME
OVER CRANK
OVER SPEED
LOW COOLANT LEVEL
HI COOLANT TEMPERATURE
LOW OIL PRESSURE
LOW BATTERY
LOW FUEL PRESSURE
SYSTEM READY
FUSES
LOCATED
INSIDE
30.7 30.7
UNIT WEIGHT: Steel 935 lbs.
GENERAC ® POWER SYSTEMS, INC. • P.O. BOX 297 • WHITEWATER, WI 53190
Bulletin 0174260SBY / Printed in USA 04.07
18 - 30 kW
R - SERIES
CONTROL PANEL
62.2 62.2
DANGER
High voltage.
Contact with terminals
may result in personal
injury or death.
0F3215
RIGHT SIDE VIEW
FUEL LINE CONNECTION
3/4" NPT FEMALE COUPLING
WEBSITE: www.guardiangenerators.com
STANDBY 30 kW
VISE ACTION LATCH,
ONE PER DOOR, ONE LIFT-OFF
DOOR PER SIDE OF GENERATOR
EXHAUST AND AIR DISCHARGE
LOUVERS - FRONT AND SIDES
27.4
DOOR
TYP
6 6
MIN. MIN.
CONCRETE BASE
NOT INCLUDED
© 2007 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice.
30
150
18 70
33.5 33.5
FRONT VIEW
EXHAUST MUFFLERS
ENCLOSED WITHIN,
#6-300 mcm
#8-#4
29 29
