D845GLVA Quick Reference
This guide is written for technically qualified personnel with experience
installing and configuring desktop board.
Warning and Caution........................................................................................... 3
Safety and Regulatory Notice.............................................................................. 3
1
Installing the I/O Shield............................................................................... 7
2
Installing the Desktop Board ....................................................................... 7
3
Installing the Processor................................................................................ 8
4
Installing Memory Modules ........................................................................ 9
5
Attaching IDE Drives ................................................................................ 10
6
Connecting Internal Headers ..................................................................... 11
7
Connecting Fans and Power Cables .......................................................... 14
....................................................................................... 16
®
Items on the Intel
Express Installer CD-ROM
•
Product warranty
•
Intel Express Installer
•
Intel
®
Desktop Board D845GLVA Product Guide
•
Software utilities and drivers
•
Software license agreement
•
Readme file
Part Number: C30685-001
.............................................................. 4
........................................................................ 6
...................................................... 15
..................................................................... 17
...................... 15
Advertisement
Table of Contents
Related Manuals for Intel D845GLVA
Summary of Contents for Intel D845GLVA
-
Page 1: Table Of Contents
..............17 ® Items on the Intel Express Installer CD-ROM • Product warranty • Intel Express Installer • Intel ® Desktop Board D845GLVA Product Guide • Software utilities and drivers • Software license agreement • Readme file Part Number: C30685-001... - Page 2 CHANGES TO SPECIFICATIONS AND PRODUCT DESCRIPTIONS AT ANY TIME, WITHOUT NOTICE. The Desktop Board D845GLVA may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.
-
Page 3: Before You Begin
Safety and Regulatory Notice See the Intel Desktop Board D845GLVA Product Guide for all applicable regulatory compliance statements, product certification markings, and safety and electromagnetic compatibility (EMC) standards and regulations the desktop board is compliant with. -
Page 4: Desktop Board Components
Desktop Board Components Line USB 2.0 Devices HD LED Power LED Reset No Connection OM15853 Figure 1. Desktop Board Components continued Intel Desktop Board D845GLVA Quick Reference... - Page 5 CAUTION Failure to use an ATX12V or SFX-12V power supply, or not connecting the additional power supply lead to Desktop Board D845GLVA may result in damage to the desktop board and/or power supply. For more information on the ATX12V and SFX -12V power supply, refer to the Intel Desktop Board D845GLVA Product Guide on the Intel Express Installer CD-ROM.
-
Page 6: Supported Components
Specification. To view or download these specifications, refer to this Intel World Wide Web site: http://www.intel.com/technology/memory/pcsdram/ For information about vendors that support these memory requirements, refer to the Desktop Board D845GLVA link on the Intel World Wide Web site at: http://support.intel.com/support/motherboards/desktop/ Intel Desktop Board D845GLVA Quick Reference... -
Page 7: Installation Steps
Secure the desktop board to the chassis standoffs using the screws. Desktop Board D845GLVA is secured to the chassis with six screws. Refer to Figure 1 on page 4 for the location of the mounting screw holes. -
Page 8: Installing The Processor
Figure 3. Installing the Processor The desktop board comes with an integrated processor heatsink retention mechanism (RM). For instructions on how to install the processor fan heatsink, refer to the boxed processor manual or the Intel customer support World Wide Web site at: http://support.intel.com/support/processors/pentium4/intnotes478.htm... -
Page 9: Installing Memory Modules
1 to avoid interference with the memory retention mechanism. The two DIMM sockets on Desktop Board D845GLVA are arranged as banks 0 and 1, as shown in Figure 4. If installing a single DIMM, install it in bank 0. -
Page 10: Attaching Ide Drives
Attach the cable end with the single blue connector (A) to the desktop board. Attach the cable end with the two closely spaced black and gray connectors (B) to the drives. OM15856 Figure 5. Connecting the IDE Cable Intel Desktop Board D845GLVA Quick Reference... -
Page 11: Connecting Internal Headers
6 Connecting Internal Headers Figure 6 shows the location of internal headers. J8A1 J9F2 J9G1 J8H3 OM15858 Label Description Front panel audio header USB 2.0 header Power LED Front panel header Figure 6. Location of Internal Headers Intel Desktop Board D845GLVA Quick Reference... - Page 12 Installing a Front Panel Audio Solution The table below shows the pin assignments for the front panel audio header. Front Panel Audio Header Signal Names Signal Name Signal Name AUD-MIC AUD-GND AUD-MIC-BIAS AUD-VCC AUD-FPOUT-R AUD-RET-R HP-ON AUD-FPOUT-L AUD-RET-L Intel Desktop Board D845GLVA Quick Reference...
- Page 13 AC power cord. Remove the cover. Remove the front panel audio cable. Install a jumper on pins 5-6 (rear R channel). Install a jumper on pins 9-10 (rear L channel). Replace the cover. Intel Desktop Board D845GLVA Quick Reference...
-
Page 14: Connecting Fans And Power Cables
Failure to use an ATX12V power supply, or not connecting the 12 V processor core voltage power supply connector to Desktop Board D845GLVA may result in damage to the desktop board and/or power supply. For more information on the ATX12V power supply, refer to the Intel Desktop Board D845GLVA Product Guide on the Intel Express Installer CD-ROM. -
Page 15: Using The Bios Setup Program
BIOS Setup Program and enables BIOS recovery in the event of a failed BIOS update (see Figure 8 for the location of the jumper block). J9H2 OM15857 Figure 8. Location of the BIOS Configuration Jumper Block Intel Desktop Board D845GLVA Quick Reference... -
Page 16: Troubleshooting
The BIOS recovers data from a recovery None diskette in the event of a failed BIOS update.* *To update or recover the BIOS, see the instructions in the Intel Desktop Board D845GLVA ® Product Guide on the Intel Express Installer CD-ROM For a complete list of BIOS Setup settings, see: •... -
Page 17: Customer Support Links
