Generac Power Systems 005040-2 Owner's Manual page 52

19
6
ITEM PART NO. QTY.
1 0E9769 REF
0F0779 REF
2 0E9837 1
3 0F0123 1
4 0F0118 1
5 099502 4
6 0C2454 REF.
7 052250 2
8 022097 8
9 022473 12
10 022127 8
11 046627 1
12 060035 4
50 Generac ® Power Systems, Inc.
Section 8 - Exploded Views and Parts
Guardian Liquid-cooled 25 kW Generator
Radiator — Drawing No. 0E9965-D
1
18
12
18
7
25
9
DESCRIPTION
SUPPORT,RADIATOR 2.5L FORD
SUPPORT RADIATOR 2.5L AL
RADIATOR, 2.5L FORD
VENTURI, 16" FAN 2.5L FORD
GUARD, FAN 2.5L FORD
CLAMP HOSE #24 B1.06-2.00
SCREW THF M6-1X16 N WA Z/JS
TAPE FOAM 1 X 1(17"LG)
WASHER LOCK M6-1/4
WASHER FLAT 1/4 ZINC
NUT HEX 1/4-20 STEEL
CAP RADIATOR
SPACER .41 X .75 X .87 ST/ZNC
5
11
2
8
10
TO BASE OF
WATER INLET
5
7
15
16
17
ITEM PART NO.
14 0F0127
15 0E9833
16 035461
17 069860C
18 0A7275
19 031669
20 065852
21 0A2111
24 0C2454
25 022287
14
3
9
10
QTY. DESCRIPTION
1 HOSE, UPPER RADIATOR 174MM
TAL
1 HOSE, 2.5L FORD LOWER
RADIATOR
1 BARBED STR 1/4NPT X 3/8
1 HOSE OIL DRAIN ASSY 21"
4 FOAM 1.5 X 1 ADHESIVE BACKING
(21.5" LG)
4 BOLT CARR 1/4-20 X 1-3/4 JS500
1 SPRING CLIP HOLDER .37-.62
1 SCREW SWAGE 10-32 X 5/16 Z/YC
6 SCREW TH-FRM M6-1X16 N WA Z/JS
4 SCREW HHC 1/4-20 X 3/4 G5
24
4
24
