Dry Vacuum - DeLonghi PENTAVAP Instruction Booklet

16/28 GB 3-01-2003 10:36
CAUTION: unplug the appliance from the
mains before effecting any set-up operations
or maintenance.

1. DRY VACUUM

PENTAVAP is first and foremost a powerful
vacuum cleaner.
Release the
motor unit by
pulling the
hooks out
(fig. A).
A
Lift off motor
unit by the easy-
grip handle
(fig.B). Remove
tools from of the
tank.
B
Make sure that the motor-protection paper bag
(36) is fitted over the motor housing (36).Secure
the paper filter with the special elastic ring (40)
or an ordinary elastic band (fig. C). Position the
large dustbag (37) inside the tank by fitting the
cardboard collar onto the suction inlet port
(fig. D).
C
Pagina 19
Attach motor unit to the tank, refastening the
two catches (fig. A). Connect the flexible hose to
the inlet port of your cleaner by rotating the hose
coupling (17)clockwise until securely attached
(fig. E).
Connect the
solution
dispenser by
pressing in until
it clicks into
place.
DRY VACUUM TOOLS AND
ACCESSORIES
Attach one end of the extension tubes (39) to
the handgrip (10) and the appropriate tool to the
other end.
Carpet/floor power brush (28)
Effectively picks up dust from hard floors and
carpets or rugs.
To vacuum hard floors, depress the beater
brush lever to show the bristles extended
symbol (
To vacuum carpets or rugs, depress the beater
brush lever on the opposite side to show the
bristles withdrawn symbol (
Crevice tool (34)
You can use this tool to
pick up crumbs, dust,
and other fine debris.
Ideal for cleaning those
hard-to-reach places
D
like radiators, car
interiors, awkward
corners, and so on.
19
E
).
) (fig. F).
F
