2-01-2003 14:37 Pagina 2 ENGLISH Dear Customer, Each one of our products is the result of consolidated experience in the design and production of appliances for household cleaning, and has been subject to meti- culous technical testing. We have prepared this manual to help you make the most of your deep-cleaner and to fully appreciate its su- perb quality.
Page 3
2-01-2003 14:37 Pagina 4 Important safety instructions Read the instruction • Before using, check that the mains voltage corresponds to booklet the voltage specified on the rating plate. carefully • The appliance should be plugged into well-earthed sockets rated at 10 amps or more. In the case of appliances with double insulation (see symbol on specifications label), earthing is not necessary.
2-01-2003 14:37 Pagina 5 1. Preparing for use Remove the motor unit by releasing the catches. Your appliance is equipped with an external tank. Remove the solution injection system (A) by pulling it out. Lift off the motor unit using the handle. Remove tools out of the tank and fit the most appropriate attachment for the work to be done.
2-01-2003 14:37 Pagina 6 The large dustbag must be positioned inside the tank. Slide the cardboard collar around the suction inlet port. Connect the flexible hose to the suction inlet port, rotating the hose coupling clockwise until securely attached. Connect the solution dispenser (5) (even though not necessary for dry vacuuming) so that it does not get in the way during vacuuming.
2-01-2003 14:37 Pagina 7 Multi-purpose nozzle (17) For cleaning sofas, upholstery, car interiors, drapes, curtains etc. Fit the required accessory to the flexible hose, plug in the power cord and switch the appliance on by pushing the ON/OFF suction switch (3) ONLY. To stop vacuuming, press the same switch again.
2-01-2003 14:37 Pagina 8 3. Wet vacuuming This function is useful when coping with those little emergencies when you have to mop up liquids and spills from any surface quickly and efficiently, like, for example, such as unblocking a sink or drain or dealing with minor floods from washing machines, dishwashers, basement floors, etc.
2-01-2003 14:37 Pagina 9 Brush attachment for hard floors When using the clear plastic accessory on hard floors, fit brush attachment (13) by carefully sliding it over the runners on the accessory to avoid it coming loose during use. Crevice tool (18) Recommended for vacuuming liquids from hard-to- reach places or to unclog drains.
2-01-2003 14:37 Pagina 10 4. Extraction cleaning The extraction cleaning technique involves spraying a detergent solution (water + shampoo) followed by a vacuuming action, the so-called extraction, to remove the solution and grime and stains along with it, effectively wiping away dirt and deep-cleaning all surfaces.
2-01-2003 14:37 Pagina 11 4.1 Filling the tank for extraction cleaning To disconnect the solution injection system (A) from the motor unit, just pull it out. Release catch, remove the solution tank and fill it with a solution of shampoo and water according to the proportions shown on the shampoo bottle.
2-01-2003 14:37 Pagina 12 Advice for using appliances with separate switches With separate switches it is possible to depress the wash switch (4) only and use the spray trigger to spray the cleaning solution onto the surface to be treated. Wait one or two minutes to allow the solution to soak in.
2-01-2003 14:37 Pagina 13 5. Cleaning and maintenan- ceof the appliance CAUTION: Before carrying out any cleaning or m ai nt en a n c e o p e ra t io n , ma k e s u re t h e appliance is unplugged from the mains.
2-01-2003 14:37 Pagina 14 Periodically replace the filter inside the exhaust port hatch on the motor unit. To open the hatch, pull the small protruding lever outwards. Periodically check that the float inside the motor protection housing is free to move in its holder. Before storing, place the accessories in the tank, and wind the cord (checking that it is not damaged or worn) around its slot at the top of the appliance.
