Genelec 7050B Operating Manual page 6

7050B Operating Manual
SYSTEM SPECIFICATIONS
Free field frequency response (± 3 dB)
Maximum short term sine wave SPL output
averaged from 30 to 85 Hz, measured in half
space at 1 meter
Self generated noise level in half space at 1 m
on axis (A-weighted)
Harmonic distortion at 90 dB SPL
at 1 m on axis in half space 30... 85 Hz
2nd
3rd
Driver, magnetically shielded
Weight
Dimensions
Height
Width
Depth
CROSSOVER SECTION
Subsonic filter (18 dB/octave) below
Input channels
Low pass frequency for 5 main channels
LFE cutoff frequency
Midband rejection >400 Hz
Bass Roll-Off control in 2 dB steps
Phase matching control in 90° steps
Input sensitivity control
LFE input sensitivity control
Genelec Document D0061R001 Copyright Genelec Oy 5.2005. All data subject to change without prior notice
7050B
25 Hz...85 Hz
LFE 85/120 Hz
100 dB
≤ 15 dB
≤ 4%
≤ 1 %
205 mm (8")
18 kg (39.6 lb)
410 mm (16 1 / ")
8
350 mm (13 3 / ")
4
319 mm (12 9 / ")
16
7050B
25 Hz
5 main + LFE
85 Hz
85 or 120 Hz selectable
≥ 50 dB
0 to -6 dB @ 26 Hz
0 to -270°
+12 to -6 dBu
0 or +10 dB selectable
International enquiries:
In the U.S. please contact:
Genelec, Olvitie 5
Genelec, Inc., 7 Tech Circle
FIN-74100, Iisalmi, Finland Natick, MA 01760, USA
Phone +358 17 83881
Phone +1 508 652 0900
Fax +358 17 812 267
Fax +1 508 652 0909
Email genelec@genelec.com Email genelec.usa@genelec.com
AMPLIFIER SECTION
Amplifier short term output power
(Long term output power is limited by driver
unit protection circuitry)
Amplifier system THD at nominal output
Mains voltage
Power consumption (average)
Idle
Full output
INPUT SECTION
Input connectors XLR female
pin 1
pin 2
pin 3
Input impedance
Input level for 100 dB SPL output @ 1 m
OUTPUT SECTION
Input connectors XLR male
pin 1
pin 2
pin 3
Main loudspeaker Out gain
Main loudspeaker Out connectors carry an unfiltered copy of the signal
arriving into their respective Input connectors.
In China please contact:
Genelec China Representative Office
Soho New Town, 88 Jianguo Road
D-1504, Chaoyang District
Beijing 100022, China
Phone +86 10 8580 2180 Fax +86 10 8580 2181
Email genelec.china@genelec.com
7050B
70 W
≤ 0.08 %
100, 120 or 230 V
11 VA
120 VA
7050B
gnd
+
-
10 kohm balanced
Variable from +12 to -6
dBu
7050B
gnd
+
-
0 dB
