Genelec 1030A Operating Manual page 4

1030A Operating Manual
AUDIO PRECISION 1030anec LEVEL(dBr)
100
95
90
85
80
75
70
65 100
60 95
55 90
20 100
Figure 4. The upper curve group shows the horizontal directivity
characteristics of the 1030A in vertical configuration measured at 1 m.
The lower curve is a 1/3 octave band power response, measured in an
IEC approved reverberation chamber.
SYSTEM SPECIFICATIONS
Lower cut-off frequency, -3 dB:
Upper cut-off frequency, -3 dB:
Free field frequency response of system:
55 Hz - 18 kHz (± 2.5 dB)
Maximum short term sine wave acoustic output on
axis in half space, av er aged from 100 Hz to 3 kHz:
@ 1m > 105 dB SPL
@ 0.5m > 111 dB SPL
Maximum long term RMS acoustic output in same
conditions with IEC weighted noise (limited by
driver unit pro tec tion cir cuit):
@ 1m > 99 dB SPL
@ 0.5m > 105 dB SPL
Maximum peak acoustic output per pair above
console top, @ 1 m from the engineer with music
ma te ri al:
Self generated noise level in free field @ 1m
on axis: < 10 dB (A-weighted)
Harmonic distortion at 90 dB SPL @ 1m on axis:
Freq: 60...150 Hz
> 150 Hz
Drivers: Bass 170 mm (6 1/2") cone
Treble 19 mm (3/4") metal dome
Both drivers are magnetically shielded.
Weight: 7,6 kg (17 lb)
Dimensions:
Height 312 mm (12 1/4")
Width 200 mm ( 7 7/8")
Depth 240 mm (9 7/16")
Genelec Document D1030AR001 Copyright Genelec Oy 3.2003. All data subject to change without prior notice
vs FREQ(Hz) 14 JAN 94 12:34:40
0
15
30
45
1k 10k 20k
CROSSOVER SECTION
< 52 Hz Input connector XLR female:
> 20 kHz
Input impedance:
Input level for 100 dB SPL output @ 1m:
Input level for maximum short term sine wave output
of 105 dB SPL @ 1m:
Subsonic filter below 50 Hz :
Ultrasonic filter above 25 kHz:
Crossover frequency, Bass/Treble:
> 115 dB
Crossover acoustical slopes:
Treble tilt control operating range in 2 dB steps:
< 3%
< 0.5% Bass roll-off control operating range in 2 dB steps:
Bass tilt control operating range in 2 dB steps:
The 'CAL' position is with all tone con trols set to 'off'
and the input sensitivity con trol to maximum (fully
clockwise).
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email genelec@genelec.com
AUDIO PRECISION 1030anec LEVEL(dBr)
100
95
90
BASS TILT
85
80
75
BASS ROLL-OFF
70
65
60
55
50
20 100
Figure 5. The curves show the effect of the bass tilt, treble tilt and
bass roll-off controls on the free field response.
Bass amplifier short term output power with a
pin 1 gnd 4 Ohm load:
pin 2 +
pin 3 -
Treble amplifier short term output power with an
10 kOhm bal anced 8 Ohm load:
variable from +6 to -6 dBu Long term output power is limited by driver unit
protection circuitry.
Amplifier system distortion at
variable from +11 to -1 dBu nominal out put:
18 dB/octave
12 dB/octave
3.5 kHz Signal to Noise ratio, referred to full out put:
24 - 32 dB/octave
Mains voltage:
from +2 to -4 dB & MUTE
Voltage operating range:
from 0 to -8 dB @ 50 Hz
Power consumption:
from 0 to -6 dB @ 100 Hz
& MUTE
In the U.S. please contact:
Genelec, Inc., 7 Tech Circle
Natick, MA 01760, USA
Phone +1 508 652 0900
Fax +1 508 652 0909
Email genelec.usa@genelec.com
vs FREQ(Hz) 14 JAN 94 12:09:56
TREBLE TILT
1k 10k
AMPLIFIER SECTION
80 W
50 W
THD < 0.08%
SMPTE-IM < 0.08%
CCIF-IM < 0.08%
DIM 100 < 0.08%
Bass > 95 dB
Treble > 95 dB
230, 100/200 or 115/230V
according to region
±10%
Idle 10 VA
Full output 100 VA
www.genelec.com
In China please contact:
Genelec China Representative Office
Soho New Town, 88 Jianguo Road
D-1504, Chaoyang District
Beijing 100022, China
Phone +86 10 8580 2180
Fax +86 10 8580 2181
