Electrolux ESF66810X User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

user manual
Dishwasher
ESF 66810 X

Advertisement

Table of Contents
loading

Related Manuals for Electrolux ESF66810X

Summary of Contents for Electrolux ESF66810X

  • Page 1 user manual Dishwasher ESF 66810 X...
  • Page 2 We were thinking of you when we made this product...
  • Page 3 welcome to the world of Electrolux electrolux 3 Welcome to the world of Electrolux Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable.

  • Page 4: Table Of Contents

    4 electrolux contents Contents Safety information Product description Control panel First use Daily use Washing programmes Care and cleaning Something not working Technical data Hints for test institutes Installation Environment concerns Guarantee/Customer Service The following symbols are used in this manual: Important information concerning your personal safety and information on how to avoid damaging the appliance.

  • Page 5: Safety Information

    safety information electrolux 5 Safety information Do not take any dishes out of the dishwasher before the end of the dishwashing cycle. In the interest of your safety and to After use, isolate the appliance ensure the correct use, before from the power supply and turn off installing and first using the the water supply.
  • Page 6 6 electrolux safety information Child safety This appliance is designed to be operated by adults. Don’t allow For electrical and water connection children to use the dishwasher carefully follow the instructions unsupervised. given in specific paragraphs. Keep all packaging well away from children.

  • Page 7: Product Description

    product description electrolux 7 Product description Upper basket Water hardness dial This dishwasher has an internal Salt container light that turns on and off when the opening and closing of the Detergent dispenser dishwasher’s door occurs. Rinse aid dispenser Internal light equipped with led lamp CLASS 1 in accordance with Rating plate EN 60825-1: 1994 + A1:2002 +...

  • Page 8: Control Panel

    electrolux control panel Control panel On/Off button Digital display The digital display indicates: the level of hardness to which the Programme selection buttons water softener is set, the approximate remaining time of Delay start button the running programme, activation/deactivation of the rinse Indicator lights aid dispenser (ONLY with 3 in 1...
  • Page 9 control panel electrolux 9 Indicator lights Salt Illuminates when the special salt has run out. Rinse aid Illuminates when the rinse aid has run out. 3 in 1 function Indicates the activation/deactivation of the "3 in 1 function" (see "3 in 1 function"). The salt and rinse aid indicator lights are never illuminated while a washing programme is running...
  • Page 10 10 electrolux control panel Setting mode To cancel a set programme or a programme in progress Simultaneously press and hold the two programme buttons positioned over the word Cancel, until all the Always remember that when: programme button lights will setting the water softener, illuminate.
  • Page 11 control panel electrolux 11 Audible signals Audible signals have been introduced to help indicate which operations the dishwasher is performing: - setting of the water softener 4. To change the current setting, - end of programme press again button 3, the digital - intervention of an alarm due to display will indicate the new malfunction...

  • Page 12: First Use

    12 electrolux first use First use Before using your dishwasher for the Set the water softener first time: The dishwasher is equipped with a Ensure that the electrical and water softener designed to remove water connections comply with the minerals and salts from the water installation instructions supply, which would have a detrimental or adverse effect on the...
  • Page 13 first use electrolux 13 The water softener must be set in 3. Press button 1, the lights of both ways: manually, using the water buttons 2 and 3 turn off while the hardness dial and electronically, using light of button 1 goes on flashing. some of the programme buttons on In the digital display is visible the the control panel...
  • Page 14 14 electrolux first use Filling with dishwasher salt 4. Replace the cap making sure that there is no trace of salt on the screw thread or on the gasket. 5. Replace the cap tightly turning it Only use salt specifically designed for clockwise until it stops with a click.

  • Page 15: Filling With Rinse Aid

    first use electrolux 15 Filling with rinse aid According to the finish and drying results obtained, adjust the dose of Rinse aid ensures thorough rinsing, rinse aid by means of the 6 position and spot and streak free drying. selector (position 1 minimum dosage, Rinse aid is automatically added position 6 maximum dosage).

  • Page 16: Daily Use

    16 electrolux daily use Daily use Check if it’s necessary to refill with - Lay small objects in the cutlery dishwasher salt or rinse aid basket. Load cutlery and dishes into the Plastic items and pans with non dishwasher. stick coatings have a tendency to Fill with dishwasher detergent .
  • Page 17 daily use electrolux 17 For washing in the dishwasher the following cutlery and dishes are not suitable: - Cutlery with wooden, horn, china or mother-of-pearls handles. - Plastic items that are not heat resistant. - Older cutlery with glued parts that are not temperature resistant.
  • Page 18 18 electrolux daily use Open the door and slide out the The rows of prongs on the lower baskets to load the dishes. basket can be easily lowered to allow you to load pots, pans and bowls. The lower basket The lower basket is designed to take saucepans, lids, plates, salad bowls, cutlery etc.
  • Page 19 daily use electrolux 19 The cutlery basket To make loading of the cutlery basket easier, lower the cutlery basket handle (fig.2). Long bladed knives stored in an fig. 2 upright position are a potential hazard. Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the upper basket.
  • Page 20 20 electrolux daily use The cutlery basket is in two parts which can be separated to give greater loading flexibility. To separate the two parts, slide them horizontally in opposite directions and pull them apart (fig. 4). fig. 4 To reassemble, reverse the procedure.
  • Page 21 daily use electrolux 21 The upper basket The central rows of prongs can be easily lowered to improve loading The upper basket is designed for flexibility. saucers, salad bowls, cups, glasses, pots and lids. Arrange items on and underneath the cup racks so that water can reach all surfaces.
  • Page 22 22 electrolux daily use Adjusting the height of the upper basket If washing very large plates you can load them in the lower basket after moving the upper basket to the higher position. Maximum height of the dishes in the lower basket With upper basket raised 31 cm With upper basket lowered...
  • Page 23 daily use electrolux 23 Use of detergent 20 = approximately 20 g of detergent 30 = approximately 30 g of detergent Only use detergents specifically 3. All programmes with prewash designed for use in dishwashers. need an additional detergent dose (5/10 g) that must be placed in the Please observe the manufacturer’s prewash detergent chamber (2).
  • Page 24 24 electrolux daily use "3 in 1 function" Activation/deactivation of the 3 in 1 function This appliance is equipped with the "3 in 1 function", that allows the use of Press simultaneously the two buttons the "3 in 1" combi detergent tablets. positioned over the writing 3 in 1, until the "3 in 1 function "indicator light These products are detergents with a...
  • Page 25 daily use electrolux 25 Activation/deactivation of the rinse aid dispenser 1. Press the On/Off button. The If you decide to turn back to the dishwasher must be in setting use of standard detergent system mode. we advise that you: 1. Deactivate the 3 in 1 function. 2.
  • Page 26 26 electrolux daily use Select and start a washing Setting and starting the programme programme with "delay start" 1. After having selected the washing programme, press the delay start button until the number of hours for the delay start will appear in the Select the washing programme and digital display.
  • Page 27 daily use electrolux 27 If a new washing programme is to be selected, check that there is detergent in the detergent dispenser. End of the washing programme Cancelling a delay start involves The dishwasher will automatically also the cancelling of the washing stop and an audible signal informs programme set.

  • Page 28: Washing Programmes

    28 electrolux washing programmes Washing programmes Programme Degree of Type of load Programme description soil Prewash Main wash up to 70°C Intensive Crockery, 2 intermediate rinses cutlery, pots Heavy soil Final rinse and pans Drying Prewash Auto (1) Main wash up to 50°C or 65°C Crockery, 1 or 2 intermediate rinses cutlery, pots...

  • Page 29: Care And Cleaning

    care and cleaning electrolux 29 Care and cleaning Cleaning the filters 4. Take hold of the coarse filter (A) by the handle with the hole and The filters must be checked and remove from the microfilter (B). cleaned from time to time. Dirty filters will degrade the washing result.
  • Page 30 30 electrolux care and cleaning Frost precautions Avoid placing the machine in a location where the temperature is NEVER try to remove the spray below 0°C. If this is unavoidable, arms. empty the machine, close the If residues of soil have clogged the appliance door, disconnect the water holes in the spray arms, remove them inlet pipe and empty it.

  • Page 31: Something Not Working

    something not working electrolux 31 Something not working The dishwasher will not start or stops during operation. Certain problems are due to the lack of simple maintenance or oversights, which can be solved with the help of the indications described in the chart, without calling out an engineer.
  • Page 32 32 electrolux something not working Malfunction Possible cause and solution The dishwasher’s door has not been The programme does not start properly closed. Close the door The main plug is not plugged in. Insert the main plug. The fuse has blown out in the household fuse box.
  • Page 33 something not working electrolux 33 The wash results are not satisfactory The dishes are not clean The wrong washing programme has been selected. The dishes are arranged in such a way as to stop water reaching all parts of the surface. The baskets must not be overloaded.

  • Page 34: Technical Data

    34 electrolux technical data Technical data Dimensions Width 60 cm Height 85 cm Depth 60 cm Electrical connection Information on the electrical connection is given Voltage - Overall power - on the rating plate on the inner edge of the Fuse dishwasher’s door Water supply pressure...
  • Page 35 technical data electrolux 35 Consumption values Programme Programme Energy Water duration consumption consumption (in minutes) (in kWh) (in litres) Intensive 1.99 25.1 Auto 1.1 - 1.53 12 - 23 Quick 1.05 (Test programme for test institutes) Glass 0.93 15.3 The programme duration is visible in the digital display when the washing programme is selected.

  • Page 36: Hints For Test Institutes

    36 electrolux hints for test institutes Hints for test institutes Testing in accordance with EN 60704 Test in accordance with EN 50242 must be carried out with appliance must be carried out when the salt fully loaded and using the test container and rinse aid dispenser programme (see "Consumption have been filled with salt and rinse aid...

  • Page 37: Installation

    installation electrolux 37 Installation Proceed as follows: Remove the machine’s worktop by unscrewing the two rear retaining Any electrical and/or plumbing screws, pull the worktop from the work required to install this back of the machine and slide out appliance should be carried out by the front slots, lifting the worktop.
  • Page 38 38 electrolux installation Water supply connections This dishwasher may be fed with either hot (max. 60°) or cold water. This appliance has been fitted with Nevertheless we advise you a cold safety features which will prevent the water supply. water used in the appliance from A hot water supply is not always returning back into the drinking water efficient with very soiled crockery as it...
  • Page 39 installation electrolux 39 Water inlet hose with safety valve After connecting the double-walled water inlet hose, the safety valve is Warning! next to the tap. Therefore the water Dangerous voltage inlet hose is only under pressure while the water is running. If the water inlet hose starts to leak during this operation, the safety valve cuts off the running water.
  • Page 40 40 electrolux installation Water outlet hose connection Likewise the internal diameter of the couplings used for connections to the The end of the drain hose can be waste outlet must be no smaller than connected in the following ways: the diameter of the hose provided. 1.
  • Page 41 installation electrolux 41 Electrical connection Safety standards require the appliance to be earthed. Prior to using the appliance for the first time, ensure that the rated voltage and type of supply on the rating plate match that of the supply where the appliance is to be installed.

  • Page 42: Environment Concerns

    42 electrolux environment concerns Environment concerns Packaging material Old appliance The packaging materials are The symbol on the product or on environmentally friendly and can be its packaging indicates that this recycled. The plastic components are product may not be treated as identified by markings, e.g.

  • Page 43: Guarantee/Customer Service

    guarantee/customer service electrolux 43 Guarantee/Customer Service Belgium 3. So as to avoid more severe damage, the defect must be DECLARATION OF GUARANTEE brought to our attention TERMS. immediately. Our appliances are produced with the 4. Applying the guarantee is subject greatest of care.
  • Page 44 44 electrolux guarantee/customer service 9. Defects that result from repairs or 15. Except in the event where liability measures carried out by people is legally imposed, this declaration who are not qualified or expert or of guarantee terms excludes any defects that result from the compensation for damage outside addition of non-original...
  • Page 45 guarantee/customer service electrolux 45 Luxembourg European guarantee Grand-Duché de Luxembourg This appliance is guaranteed by ELECTROLUX HOME PRODUCTS Electrolux, in each of the countries Rue de Bitbourg. 7 listed in the following page, for the L-1273 Luxembourg-Hamm period specified in the appliance Consumer services guarantee or otherwise by law.
  • Page 46 46 electrolux guarantee/customer service www.electrolux.com Česká republika +420 2 61 12 61 12 Budějovická 3, Praha 4, 140 21 Lietuva +370 5 27 80 609 Verki˜ 29, LT-09108 Vilnius Slovenija +38 61 24 25 731 Electrolux Ljubljana, d.o.o. Gerbičeva 98, 1000 Ljubljana Slovensko +421 2 43 33 43 22 Electrolux Slovakia s.r.o., Electrolux...
  • Page 48 www.electrolux.com 117997 25/0-00-24082006...
