- Page 1 ..................... ESF 66814 EN DISHWASHER USER MANUAL...
-
Page 2: Table Of Contents
2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com CONTENTS Safety information Washing programs Product description Care and cleaning Control panel What to do if… Use of the appliance Technical data Setting the water softener Installation... - Page 3 3 • Always close the door when you do not • Remove all packaging before first use. use the appliance to prevent injury and • A qualified and competent person must not to stumble over the open door. do the electrical installation.
-
Page 4: Product Description
4 electrolux PRODUCT DESCRIPTION Upper basket Upper spray arm Air vent and water hardness dial INTERNAL LIGHT Salt container This appliance has an internal light that Detergent dispenser comes on when you open the door and goes off when the door is closed. -
Page 5: Control Panel
5 CONTROL PANEL The controls are on the top of the con- trol panel. To operate with the controls keep the appliance door ajar. On/off button Display Delay start button Program button (down) Program button (up) Energy saver button... - Page 6 6 electrolux THE DISPLAY RESET BUTTON The display shows: Press this button to cancel a washing pro- • The electronic adjustment of the level of gram in operation. Refer to 'Setting and the water softener starting a washing program'. • The activation and deactivation of the...
-
Page 7: Use Of The Appliance
7 • You adjust electronically the level of the • The indicator of button (5) continues water softener. to flash. • The appliance has a malfunction. • The display shows the setting of the acoustic signals. Factory setting: acoustic signals active. -
Page 8: Use Of Dishwasher Salt
8 electrolux Water hardness Water hardness setting mg/l mmol/l manually electronically < 70 < 70 < 0.7 1) No use of salt required. You must set the water softener man- 1. Switch on the appliance. Make sure that ually and electronically. -
Page 9: Use Of Detergent And Rinse Aid
9 It is normal that water overflows from the salt container when you fill it with salt. USE OF DETERGENT AND RINSE AID lets do not have the best cleaning re- sults during short washing programs. Use long washing programs when you use detergent tablets to fully remove the detergent. -
Page 10: Multitab Function
10 electrolux MULTITAB FUNCTION The multitab function is for combi detergent – When you activate the multitab func- tablets. tion, it stays on until you deactivate it. These tablets contain agents as detergent, To deactivate the multitab function and rinse aid and dishwasher salt. Some types use separately detergent, salt and rinse of tablets can contain other agents. -
Page 11: Setting And Starting A Washing Program
11 SETTING AND STARTING A WASHING PROGRAM STARTING THE WASHING PROGRAM 3. Close the appliance door, the washing WITHOUT DELAY START program starts. 1. Switch on the appliance. Make sure that Warning! Only interrupt or cancel a the appliance is in setting mode. -
Page 12: Washing Programs
12 electrolux WASHING PROGRAMS Program Type of soil Type of load Program description Function Crockery, cutlery, Prewash Energy saver pots and pans Wash 45 °C or 70 °C Rinses Heavy soil Crockery, cutlery, Prewash Energy saver pots and pans Wash 70 °C... -
Page 13: Care And Cleaning
13 Program Program time (mi- Energy (kWh) Water (litre) nute) 105 - 115 0.67 - 0.81 9.6 - 11.6 50 - 60 1.0 - 1.2 10 - 11 70 - 80 0.8 - 0.9 11 - 12 0.05 The water pressure and temperature,... -
Page 14: What To Do If
14 electrolux Use detergent, but do not put dishes in the appliance. WHEN THE APPLIANCE IS NOT TO BE USED FOR A LONG PERIOD 1. Disconnect the mains plug from the mains socket. 2. Close the water tap. 3. Leave the door open to prevent un- pleasant smells. - Page 15 15 Malfunction Possible cause Possible solution The water tap is blocked or restric- Clean the water tap. ted with limescale. The water pressure is too low. Contact your local water authority. The appliance does There is a blockage in the sink spi- Clean the sink spigot.
- Page 16 16 electrolux Problem Possible cause Possible solution The salt container cap is not Ensure that the salt container closed correctly. cap is correctly closed. There are streaks, milky stains, Rinse aid dosage is too high. Decrease the rinse aid dosage.
-
Page 17: Technical Data
17 TECHNICAL DATA Dimensions Width 596 mm Height 818 - 878 mm Depth 580 mm Electrical connection Voltage 220-240 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Water supply pressure min. 50 kPa (7 psi) max. - Page 18 18 electrolux After the adjustment of the level of the ap- ADHESIVE STEAM PROTECTION FOIL pliance, assemble the adjustable plinth on Fit the steam protection on the front part of the appliance. the kitchen counter along the entire width. INSTALLING THE APPLIANCE UNDER...
- Page 19 19 2. Fix laterally the appliance with the spacers and the screws supplied. Make sure that the screws are tight. Once the installation is completed, make A notched continuous panel is necessary to sure that the bottom of the adjustable plinth prevent door swing interference and to is aligned with the ground.
-
Page 20: Water Connection
BSP thread spout of 3/4”. additional lengths and connectors. These For best washing performance it is recom- must be purchased from Electrolux Spare mended to connect the appliance to a cold Parts. The extension length must not ex- water supply. - Page 21 21 Caution! Make sure that the water Once connected the inlet hose to the couplings are tight to prevent water water tap, turn the tap on and check leakage. that there are no leaks. Ensure that hoses are not bent or squashed under or behind the appli- ance.
-
Page 22: Electrical Connection
22 electrolux ELECTRICAL CONNECTION Warning! can constitute a fire hazard through • The manufacturer accepts no liability overheating. for failure to observe the below safe- • If necessary, have the domestic wir- ty precautions. ing system socket replaced. If the •... -
Page 23: Warranty
New Zealand; travel and delivery of the Appliance to f) ‘major failure’ as referred to in and from Electrolux or its ASC. If you clause 10 of this warranty has the reside outside of the service area, you same meaning referred to in the... - Page 24 Australian Consumer Law. You are en- due to faulty or defective parts or work- titled to a replacement or refund for a manship. Electrolux is not liable in the major failure and for compensation for following situations (which are not ex-...
- Page 25 25 FOR SERVICE SERVICE AUSTRALIA FOR SPARE PARTS or to find the address of your or to find the address of your nearest state service centre in nearest state spare parts cen- ELECTROLUX HOME Australia tre in Australia PRODUCTS...
- Page 26 26 electrolux...
- Page 27 27...
- Page 28 117934893-A-192012...
