- Page 1 Cooker EH L2-3 / L2-4...
-
Page 2: Table Of Contents
2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com Contents Safety instructions........3 Cleaning and Care......... 21 Description of the Appliance ....4 What to do if …........26 Before Using for the first time ....6 Installation Instructions ...... -
Page 3: Safety Instructions
electrolux 3 Safety instructions Electrical safety How to avoid damage to the appliance • This appliance must be only connected • Do not line the oven with aluminium foil by a registered electrician. and do not place baking trays, pots, etc. on the oven floor, as the heat that builds •... -
Page 4: Description Of The Appliance
4 electrolux Description of the Appliance General Overview Control panel Door handle Oven door Appliance drawer Control Panel EH L2-4 Oven Power Indicator Temperature selector Oven Functions Temperature Pilot Light Hob Cooking Zone Control Knobs Hob Cooking Zone Control Knobs... -
Page 5: Oven Features
5 Control Panel EH L2-3 Oven Power Indicator Temperature Pilot Temperature selector Light Hob Cooking Zone Control Knobs Oven Functions Oven Features Top heat and heating elements Fat trap Oven lighting Shelf positions Fat Filter Oven lighting Fan heating element... -
Page 6: Before Using For The First Time
6 electrolux Oven accessories Oven shelf Baking tray For cookware, cake tins, roasts and grilled For cakes and biscuits. foods. Before Using for the first time Initial Cleaning Turn the oven function switch to oven lighting Before using the oven for the first time you Remove all accessories and the shelf should clean it thoroughly. -
Page 7: Setting The Heat Setting
electrolux 7 front left rear left rear right front right Hob Cooking Zone Control Knobs Setting the heat setting Switching on the dual fry/cook area (EH L2-4) 1. Select the heat setting. The control for the dual fry/cook area is switched on by turning to the right, and cannot be turned past the stop! Turn the dual fry/cook control to the... -
Page 8: Using The Oven
8 electrolux Using the Oven Switching the Oven On and Off Oven Power Indicator Temperature selector Oven Functions Temperature Pilot Light 1. Turn the oven functions dial to the de- sired function. 2. Turn the temperature selector to the de- sired temperature. -
Page 9: Oven Functions
electrolux 9 Oven Functions The oven has the following functions: Oven function Application Light Using this function you can light up the oven interior, e.g. for cleaning. Convection with ring To bake on three oven levels maximum at the same time. heating element Decrease the oven temperatures (20-40 °C) compared with Conven- tional. - Page 10 10 electrolux Inserting the oven shelf: Inserting/Removing the Fat Filter Only use the fat filter when roasting to protect the rear heating elements from fat splashes. Insert the oven shelf so that the feet point downwards. Push the oven shelf between the guide bars of the selected oven level.
-
Page 11: Uses, Tables And Tips
electrolux 11 Uses, Tables and Tips Cooking table The information given in the following table is for guidance only. Heat Cooking- Cooking set- suitable for Tips/Hints process time ting Residual heat, Off position Keeping Keeping cooked foods warm as required Cover food warm Hollandaise sauce,... - Page 12 12 electrolux Baking 3 baking trays: Oven function: Convection with ring heating element or Conventional Baking tins • For Conventional dark metal and non-stick tins are suitable. • For Convection with ring heating element bright metal tins are also oven levels 1, 3 and 5 suitable.
-
Page 13: Baking Table
electrolux 13 • Cakes and pastries at different heights With longer baking times, the oven can may brown at an uneven rate at first. If be switched off about 10 minutes before this occurs, please do not change the the end of baking time, to make use of temperature setting. - Page 14 14 electrolux Type of Oven Temperature Time Oven function baking level °C Mins. Buttered almond cake/sugar cakes Conventional 190-210 20-30 Butter plait Convection with ring 170-180 40-50 heating element Fruit flans Convection with ring 40-50 (made with yeast dough/sponge heating element mixture) Fruit flans Conventional...
-
Page 15: Tips On Baking
electrolux 15 Baking on more than one oven level Convection Convection with ring with ring heating heating Temperature Time element element Type of baking in °C Mins. Shelf positions from bottom 2 levels 3 levels Cakes/pastries/breads on baking trays Cream puffs/Eclairs 1 / 4 160-180 35-45... - Page 16 16 electrolux Baking results Possible cause Remedy Cake browns unevenly Oven temperature too high and baking Set a lower oven temperature and a time too short longer baking time Mixture is unevenly distributed Spread the mixture evenly on the baking tray Cake is not done within the Temperature too low Use a slightly higher oven setting...
- Page 17 electrolux 17 Frozen Ready Meals Table Food to be Shelf Temperature Oven function Time cooked position °C as per manufactur- as per manufactur- Frozen pizza Conventional er’s instructions er’s instructions Chips Convection with ring as per manufactur- 200-220 (500 g) heating element er’s instructions as per manufactur-...
- Page 18 18 electrolux Temper- Shelf Time Type of meat Quantity Ovenfunction ature position Mins. °C Pork Convection Shoulder, neck, ham joint 1-1.5 kg 160-180 90-120 grilling Convection Chop, spare rib 1-1.5 kg 170-180 60-90 grilling Convection Meat loaf 750 g-1 kg 160-170 50-60 grilling...
-
Page 19: Grill Sizes
electrolux 19 Grill sizes Oven function: Grill or Dual grill • For grilling, place the shelf in the with maximum temperature setting recommended shelf position. • Always insert the tray into the first Important: Always grill with the oven shelf position from the bottom. door closed. -
Page 20: Making Preserves
20 electrolux Drying Oven function: Convection with ring heating element • Use oven shelves covered with grease- proof paper or baking parchment. • You get a better result if you switch the oven off halfway through the drying time, open the door and leave the oven to cool down overnight. -
Page 21: Cleaning And Care
electrolux 21 Preserves table The times and temperatures for making pre- serves are for guidance only. Cooking time until Continue to cook Temperature Preserve simmering at 100°C in°C in mins. in mins. Soft fruit Strawberries, blueberries, r 160-170 35-45 aspberries, ripe gooseberries Unripe gooseberries 160-170 35-45... -
Page 22: Fat Filter
22 electrolux Fat Filter Fitting the shelf support rails 1. Clean the fat filter in hot water and washing up liquid or in the dishwasher. 2. Badly burned on soiling can be removed by boiling the filter in a little water to which 2-3 tablespoonsful of dishwasher clean- er has been added. -
Page 23: Oven Lighting
electrolux 23 1. Pull the top heating elements out of the Oven Lighting plug connection to the front (see illustra- Warning: Risk of electric shock! Prior to tion). changing the oven light bulb: – Switch off the oven! – Disconnect from the electricity supply. Place a cloth on the oven floor to protect the oven light and glass cover. -
Page 24: Oven Ceiling
24 electrolux 4. Refit the glass cover. Warning: Only fold down the heating el- ement when the oven is switched off and there is no risk of being burnt! Remove the side shelf support rails. Grip the heating element at the front and pull it forwards and out over the support lug on the inner wall of the oven. -
Page 25: Oven Door
electrolux 25 Oven door Take hold of the oven door with a hand on each side and pull it away from the For easier cleaning of the oven interior the oven at an upwards angle (Take care: It oven door of your appliance can be taken off is heavy). -
Page 26: What To Do If
26 electrolux 3. Fold up the clamping levers (A) on both Close the oven door. door hinges back into their original positions. What to do if … Fault Possible cause Remedy The oven does not heat. The oven has not been switched on. Switch the oven on. The required settings have not Check the settings. -
Page 27: Installation Instructions
electrolux 27 Installation Instructions Built-in cooker SMS width 55 cm Installation into flammable material must comply with NIN 2005, Chapter 4.2.2 of the VKF (Association of Cantonal Fire In- surers) fire protection guidelines and regulations. 1. a) Install the hotplates according to the installation insruction no.374307900/ 374307901 so that the hotplate socket connections can be carried out before... - Page 28 28 electrolux Installation diagram 400V Electrical connection/power supply The oven must be connected to the electric- ity supply by a designated electrician. Use a H05VV-F type power cable or higher. Phase definitions: The appliance must be installed with a sock- L1, L2, L3 (or R, S,T) et supply line, otherwise the fixed home elec- trical system must include an isolating device...
-
Page 29: Disposal
electrolux 29 Disposal Packaging material The packaging materials are environ- mentally friendly and can be recycled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appropriate container at the com- munity waste disposal facilities. - Page 30 30 electrolux Garantie/Kundendienst, Garantie/service-clientèle, Garanzia/Servizio clienti, Guarantee/Customer Service Centres Servicestellen Points de Service Servizio dopo vendita Point of Service 5506 Mägenwil/Zürich 3018 Bern 1028 Préverenges 6916 Grancia Industriestrasse 10 Morgenstrasse 131 Le Trési 6 Zona Industriale E 9000 St. Gallen Zürcherstrasse 204 e 4127 Birsfelden Hauptstrasse 52...
-
