- Page 1 Ceramic glass hob EHS 90260 X...
- Page 2 We were thinking of you when we made this product...
- Page 3 electrolux 3 Welcome to the world of Electrolux Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable.
-
Page 4: Table Of Contents
4 electrolux contents Contents Safety instructions Description of the Appliance Operating the appliance Tips on cooking and frying Cleaning and care What to do if … Disposal Installation Instructions Assembly Guarantee/Customer Service Service and Spare Parts The following symbols are used in this user information: Warning! This must be read! Important advice for the safety of persons and information on avoiding damage to the appliance General information and advice... -
Page 5: Safety Instructions
safety instructions electrolux 5 General safety • The appliance may only be installed and connected by trained, registered service engineers, or competent per- sons. Safety instructions • Built-in appliances may only be used after they have been built in to suita- ble built-in units and work surfaces Please comply with these instructions. - Page 6 6 electrolux safety instructions How to avoid damage to the appli- ance • The ceramic glass can be damaged by objects falling onto it. • The edge of the ceramic glass can be damaged by being knocked by the cookware. •...
-
Page 7: Description Of The Appliance
description of the appliance electrolux 7 Description of the Appliance Cooking surface layout Single cooking zone Multi-purpose zone 1200W 1400/2200W Triple ring cooking zone Control panel Double ring cooking zone 1050/1950/2700W 700/1700W Control panel layout Cooking zone indicators Timer function Outside Middle/outer ring Multi-purpose... - Page 8 8 electrolux description of the appliance Touch Control sensor fields The appliance is operated using Touch Control sensor fields. Functions are controlled by touching sensor fields and confirmed by displays and acoustic sig- nals. Touch the sensor fields from above, without covering other sensor fields.
- Page 9 description of the appliance electrolux 9 Residual heat indicator Warning! Risk of burns from residu- al heat. After being switched off, the cooking zones need some time to cool down. Look at the residual heat indicator Residual heat can be used for melt- ing and keeping food warm.
-
Page 10: Operating The Appliance
10 electrolux operating the appliance Operating the appliance Switching the appliance on and off Control panel Display Pilot light Switch on Touch for 2 seconds lights up Switch off Touch for 1 second / none goes out After switching on, within approx. 10 seconds a heat setting or a func- tion must be set, otherwise the ap- pliance automatically switches... -
Page 11: To Switch The Outside Ring On And Off
operating the appliance electrolux 11 To switch the outside ring on and off By switching the outside rings on or off, the effective heating surface can be matched to the size of the cookware. Before an outside ring can be switched on, the inside ring must be switched on. -
Page 12: Locking/Unlocking The Control Panel
12 electrolux operating the appliance Locking/unlocking the control panel The control panel, with the exception of the “On/Off” sensor field, can be locked at any time in order to prevent the set- tings being changed e.g. by wiping over the panel with a cloth. Control panel Display Switch on... - Page 13 operating the appliance electrolux 13 If during the automatic warm up a higher heat setting is selected, e.g. from , the automatic warm up is adjusted. If there is still residual heat on the cooking zone (display ), the auto- matic warm up is not performed.
- Page 14 14 electrolux operating the appliance Using the child safety device The child safety device prevents unin- tentional use of the appliance. Setting the child safety device Step Control panel Display/Signal Switch on the appliance (Do not set a heat setting) Touch until the signal sounds Acoustic signal...
-
Page 15: Using The Timer
operating the appliance electrolux 15 Using the timer All cooking zones can use each use one of the two timer functions at the same time. Function Condition Outcome after the time has elapsed Automatic cut-out a heat setting is set acoustic signal flashes Cooking zone switches... - Page 16 16 electrolux operating the appliance Selecting a cooking zone Step Control panel Display Touch once Pilot light of the first cooking zone flashes Touch once Pilot light of the second cook- ing zone flashes Touch once Pilot light of the third cooking zone flashes Touch once...
- Page 17 operating the appliance electrolux 17 Setting the time Step Control panel field Display Select cooking zone Pilot light of the cooking zone selected flashes Touch for the 00 to 99 minutes cooking zone selected After a few seconds the pilot light flashes more slowly. The time is set.
- Page 18 18 electrolux operating the appliance Displaying the time remaining for a cooking zone Step Control panel field Display Select cooking zone Pilot light of the cooking zone selected flashes faster The time remaining is displayed After a few seconds the pilot light flashes more slowly. Switching off the acoustic signal Step Control panel field...
-
Page 19: Automatic Switch Off
operating the appliance electrolux 19 Automatic switch off Cooking surface • If after switching on the cooking sur- face, a heat setting is not set for a cooking zone within approx. 10 sec- onds, the cooking surface automati- cally switches itself off. •... -
Page 20: Tips On Cooking And Frying
20 electrolux tips on cooking and frying Tips on cooking and frying Information about acrylamides According to the latest scientific re- search, intensive browning of food, especially in products containing starch, may present a health risk due to acrylamide. Therefore we recommend cooking at low temper- atures and not browning foods too much. - Page 21 tips on cooking and frying electrolux 21 Energy saving Always place cookware on the cooking zone before it is switched If possible, always place lids on the pans. Switch cooking zones off before the end of the cooking time, to take ad- vantage of residual heat.
-
Page 22: Examples Of Cooking Applications
22 electrolux tips on cooking and frying Examples of cooking applications The information given in the following table is for guidance only. Heat Cooking set- suitable for Cook time Tips/Hints process ting Residual heat, Off position Keeping food Keeping cooked foods warm as required Cover warm... -
Page 23: Cleaning And Care
cleaning and care electrolux 23 Cleaning and care Take care! Risk of burns from resid- ual heat. Important Sharp objects and abra- sive cleaning materials will damage the appliance. Clean with water and washing up liquid. Important Residues from cleaning agents will damage the appliance. - Page 24 24 electrolux cleaning and care Cleaning the appliance after each use 1. Wipe the appliance with a damp cloth and a little washing up liquid. 2. Rub the appliance dry using a clean cloth. Removing deposits 1. Place the scraper on the glass ce- ramic surface at an angle.
-
Page 25: What To Do If
what to do if … electrolux 25 What to do if … Problem Possible cause Remedy The cooking zones will not More than 10 seconds have Switch the appliance on again. switch on or are not function- passed since the appliance was switched on The child safety device is Deactivate the child safety de-... - Page 26 26 electrolux what to do if … Problem Possible cause Remedy and number are displayed Electronics fault Disconnect the appliance from the electrical supply for a few minutes (Take the fuse out of the house’s wiring system) If after switching on again, is displayed again, call the customer service department and minus are displayed...
-
Page 27: Disposal
disposal electrolux 27 Disposal Packaging material The packaging materials are envi- ronmentally friendly and can be re- cycled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appro- priate container at your local waste disposal facilities. -
Page 28: Installation Instructions
28 electrolux installation instructions Installation Instructions • The appliance must be connected to the electrical supply by a qualified electrician. Risk of injury from electrical cur- rent. Safety instructions • Loose and inappropriate plug and socket connections can make the Warning! This must be read! terminal overheat. -
Page 29: Electrical Connection Diagram
installation instructions electrolux 29 Electrical Connection Diagram For UK only: 230V...240V~... -
Page 30: Assembly
30 electrolux assembly Assembly... - Page 31 assembly electrolux 31...
- Page 32 32 electrolux assembly...
-
Page 33: Rating Plate
electrolux 33 Rating Plate EHS90260X 949 592 657 55HCD68AO 230 V 50 Hz 7,8 kW ELECTROLUX... -
Page 34: Guarantee/Customer Service
34 electrolux Guarantee/Customer Service Guarantee/Customer Service • Appliances found to be in use within a commercial environment, plus those which are subject to rental Standard guarantee conditions agreements. We, Electrolux, undertake that if within • Products of Electrolux manufacturer 12 months of the date of the purchase that are not marketed by Electrolux this Electrolux appliance or any part thereof is proved to be defective by rea-... -
Page 35: European Guarantee
Guarantee/Customer Service electrolux 35 European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appli- ance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qual-... - Page 36 36 electrolux Guarantee/Customer Service Hellas +30 23 10 56 19 70 4 Limnou Str., 54627 Thessaloniki Hrvatska +385 1 63 23 338 Slavonska avenija 3, 10000 Zagreb Ireland +353 1 40 90 753 Long Mile Road Dublin 12 Italia +39 (0) 434 558500 C.so Lino Zanussi, 26 - 33080 Porcia (PN) Latvija +37 17 84 59 34...
-
Page 37: Service And Spare Parts
service and spare parts electrolux 37 Service and Spare Parts If the event of your appliance requiring service, or if you wish to purchase spare parts, please contact Service Force by telephoning: 0870 5 929 929 Your telephone call will be automatically routed to the Service Force Centre cov- ering your post code area. - Page 38 38 electrolux service and spare parts Customer Care Department For Customer Service in the Republic of Major Appliances Ireland please contact us at the address be- Electrolux low: Addington Way AEG/ Electrolux Group (Ire) Ltd Luton Long Mile Road/ Dublin 12 Bedfordshire, LU4 9QQ Republic of Ireland Tel: 08705 350350 (*)
- Page 40 www.electrolux.com www.electrolux.co.uk 822 930 632-M-260707-02...
