Summary of Contents for Electrolux EWC 1050
-
Page 2: Table Of Contents
Contents For the User For the Installer Safety information Technical specifications Disposal Unpacking the machine - Damages Your new washing machine - When lifting the machine - Transit locking devices Description of the appliance Installation 18-19 - Machine front, Machine rear - Control panel - Levelling the machine - Water inlet... -
Page 3: Safety Information
Safety information Before installing and first using the washing machine, read this instruction booklet carefully, including it’s hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the washing machine are thoroughly familiar with it’s operation and safety features. Save these instructions and make sure they remain with the dishwasher if it is moved or sold, so that everyone using it through it’s life can be properly informed on appliance use and safety. -
Page 4: Disposal
Disposal - the packing material: - energy saving tips: To save water, energy and help protect the environment, Never leave packaging material in a place we recommend that you follow these hints: where children may play with it. The washing machine is especially economical when All materials used in packaging this machine are environ- you fully utilise the stated filling quantities. -
Page 5: Description Of The Appliance
Description of the appliance Machine front Control panel Door latch Door 4 adjustable feet Machine rear Inlet hose Power cord Discharge hose Transit locking devices - 5 -... -
Page 6: Detergent Dispenser
Description of the appliance Control panel 5 6 7 1 Detergent dispenser 3 Button ”Vorwäsche” With separate compartments for detergent and fabric If the laundry is heavily soiled, you can choose a conditioner. The detergent is poured in the larger programme with pre-wash. -
Page 7: Programme Progress Display
6 Button ”Start/Pause” ”Spülstopp” (rinse hold), when selecting this position the water of the last rinse is not drained to prevent the laundry This button has two functions: from creasing. The lights ”Ende” and ”Tür” on the programme Start: Press the button in order to start the required progress display are lit when the programme is finished programme. -
Page 8: General Washing Information
General washing information Sorting the laundry How much laundry per load? Do not allow moist laundry to lay for any longer period Since it’s difficult to weigh the laundry we suggest that of time. Moist laundry becommes mouldy and begin you appriciate the weight by looking to see how full the to smell. -
Page 9: Detergent And Fabric Conditioner
Detergent and fabric conditioner This washing machine has a washing system which uses a minimum amount of water in order to make the laundry Good washing result depends on among other things of clean. It is therefore a risk that the detergent will not de- the choice of detergent and the correct dosage. -
Page 10: Programme Chart
Programme chart Cotton 3.0 kg dry load weight Synthetics and Delicate 1.5 kg dry load weight Consumption * Load Temperature Programme Option Energy Water Time type °C content buttons litres minutes Extra Kurz White Koch-/Bunt- Wash programme 95°C Kurz heavily soiled without pre-wash. - Page 11 Wool 1.0 kg dry load weight Special programmes 3.0 kg dry load weight Consumption * Load Temperature Programme Option Energy Water Time type °C content buttons litres minutes Woollens Wolle Wash programme Cold, garments with wool- 30°C without pre-wash. 0,20 ~ 45 Cold symbol or marked...
-
Page 12: Using The Appliance
Using the appliance Have you removed all the transit locking devices? The very first time the machine is used, you should run a wash programme without any load, to clear any residues which may have been left by the manufacturing process. Pour approx. 100 ml of de- tergent straight into the drum and run a programme at 60°. -
Page 13: Interrupting A Programme
Interrupting a programme Press the Start/Pause button to interrupt a programme which is running. The corresponding light starts to flash. After approx. 1 minute the door can be opened. The pro- gramme continues when you press the button again. Cancelling a programme Turn the programme selector to the ”Aus”... -
Page 14: Maintenance
Maintenance The cabinet Clean the outside surfaces of the appliance using a mild (non-abrasive) household cleaning product. Finish by re- moving remaining traces of the product with a damp cloth. Do not use cleaning products which contain alcohol (spirits), thinners and similar substances. The detergent dispenser In time, residues of detergent and fabric conditioner are likely to build up inside the detergent dispenser. -
Page 15: If The Machine Is Not Working
If the machine is not working Before calling out an engineer, please check through the details below because some faults can be rectified easily without the need to call out an engineer. If an engineer is called to resolve a problem listed below or to repair a fault caused by incorrect installation or mis-use a charge will be made, even if the appliance is under guarantee. -
Page 16: Service
Water pressures Minimum 50 kPa (0,5 bar) Maximum 1000 kPa (10 bar) Drum volume 27 litres Spin speed Maximum 1000 rpm/min (EWC 1050) Maximum 1300 rpm/min (EWC 1350) Electrical data Power supply 230V / 50 Hz Power rating 1600 W Fuse... -
Page 17: Unpacking The Machine
Unpacking Damages If the machine has been damaged during transport, you should immediately notify the company responsible for delivering it. Check that the machine is undamaged. If you discover any damage, faults or that anything is missing, you should notify the dealer immediately. Never leave packaging material in a place where children may play with it. -
Page 18: Installation
Installation Levelling the machine The machine must be installed on a sound and firm surface and must not be touching walls or furniture. Adjust the two front feet to level the machine. Make sure the machine is resting on all four feet (Fig. 1). Some vibration is normal and unavoidable when the machine is spinning the load, particularly if the floor is not a concrete one. -
Page 19: Water Discharge
Installation Water discharge The discharge hose can be placed in these three ways: Over the top edge of a washtub: Use this option only if you can be sure that the hose will not move when the machine is draining. The hose can be fixed to the wall on a hook or tied to the tap with a string (Fig.
