MP
TRAY
The multi-purpose tray is used for media sizes additional to those
of the standard trays, heavier media weights and special media.
The multi-purpose tray can handle the same sizes as the
standard trays but in weights up to 512g/m². For very heavy
paper stock use the face-up paper stacker. This ensures that the
paper path through the printer is almost straight.
The multi-purpose tray can feed paper widths as small as
76.2mm and lengths up to 1200mm. For banner printing,
recommended sizes are A4 wide, 900mm and 1200mm long.
Since paper of width less than 100mm does not auto feed,
you have to press the ONLINE button to cause it to
feed.
Use the multi purpose tray for printing on envelopes and
transparencies. Up to 100 sheets of transparencies or 25
envelopes can be loaded at one time, subject to a maximum
stacking depth of 25mm.
Paper or transparencies should be loaded print side up and top
edge into the printer. Do not use the duplex (two-sided printing)
function for transparencies.
F -
ACE DOWN STACKER
The face-down stacker on the top of the printer can hold up to
500 sheets of 80g/m² standard paper, and can handle paper
stocks from 55 – 240g/m². Pages printed in reading order
(page 1 first) will be sorted in reading order (last page on top,
facing down).
F -
ACE UP STACKER
The face-up stacker should be opened and the tray extension
pulled out when required for use. (With the face-up stacker either
open or closed, the driver setting of Face Down will successfully
direct prints to the Face-Down stacker.)
The face-up stacker can hold up to 200 sheets of 80g/m²
standard paper and can handle stocks up to 512g/m².
Always use this stacker and the multi-purpose feeder for paper
stocks heavier than 240g/m².
Printer and paper overview > 23
