Summary of Contents for Rosewill Galaxy
-
Page 2: Table Of Contents
Disassemble Chart Accessory Box Installation Guide Opening Chassis Installing Power Supply Installing Motherboard Installing Add On Card Installing External 5.25"/3.5” Device (Galaxy 01) Installing External 5.25"/3.5” Device (Galaxy 02/03) Installing 3.5”/2.5” HDD/SSD Closing Chassis Information © All rights reserved by Rosewill... - Page 3 Front I/O Pin Define...
-
Page 4: Accessory Box
11 x screw-C Add-on Card 1 x 5.25” to 3.5” bay External 3.5” converter (Galaxy 2/3 only) Device 1 x PC Speaker Motherboard 5 x Cable tie Cables 2 x PCI cover Expansion Slot © All rights reserved by Rosewill... -
Page 5: Opening Chassis
-If your power supply is equipped with single fan (120mm, 135mm or 140mm), please have the fan face to the bottom. -Please remember to clean the PSU dust filter regularly. To Remove PSU dust filter for Cleaning: Unclip Remove * screw-C © All rights reserved by Rosewill... -
Page 6: Installing Motherboard
Installing Add On Card *Screw C Step 1- Unscrew and remove add-on card cover. Step 2- Install VGA card and secure with screw. Step 3- Put back add-on card cover and secure with screws. © All rights reserved by Rosewill... - Page 7 User Manual Installing External 5.25"/3.5” Device (Applies to Galaxy-01) *Please refer to the next page for Galaxy-02/03 external drive installation -Confirm which bay(s) you want to install -Remove front panel by pulling from the bottom as shown. device(s) then remove the bay cover.
-
Page 8: Installing External 5.25"/3.5" Device (Galaxy 01)
CASE Galaxy User Manual Installing External 5.25"/3.5” Device (Applies to Galaxy-02/03) -For Galaxy 2/3, 5.25” bay cover can be removed by releasing the locking mechanism on the cover. Installing External 5.25"/3.5” Device (Applies to Galaxy-02/03) * screw-A Secure external 3.5” device onto adapter with screws. -
Page 9: Installing 3.5"/2.5" Hdd/Ssd
CASE Galaxy User Manual Installing 3.5”/2.5” HDD/SSD * Screw-A * Screw-B Put the 3.5”/2.5” HDD/SSD onto the HDD tray then secure with screws. © All rights reserved by Rosewill... -
Page 10: Closing Chassis
Please register your product at : http://www.rosewill.com for complete warranty information and future support for your product. If you have any question while using our products, please visit our website : www.rosewill.com for latest driver & user manual or feel free to contact us.
