Summary of Contents for Rosewill B2 SPIRIT

  • Page 1 User's Manual...

  • Page 2: Table Of Contents

    Please register your product at: www.rosewill.com for complete warranty information and future support for your product. If you have any questions while using our products, please visit our website: www.rosewill.com for latest driver & user manual. Support Phone Number: 800-575-9885 Support Email: techsupport@rosewill.com...

  • Page 3: Product Diagram

    CASE B2 SPIRIT User Manual Product Diagram (Components vary by country) Top Panel 140mm Fan × 2 Panel R 140mm Fan Panel L Dust Filters 140mm Fan × 2 Bottom Dust Filters...

  • Page 4: Front I/O Pinout

    CASE B2 SPIRIT User Manual Front I/O Pinout USB 3.0 CONNECTOR USB2.0 CONNECTOR HD Audio CONNECTOR VBUS None USB+5V USB+5V AUD GND PORT1L SSRX1- VBUS SSRX1+ SSRX2- PRESENCE# PORT1R ground SSRX2+ SSRX1- ground SENSE1 RETURN PORT2R SSRX1+ SSTX2- NO PIN...

  • Page 5: Accessory Kit

    CASE B2 SPIRIT User Manual Accessory Kit Figure Part's Name Function Screw-A Screw-B Motherboard Screw-C Screw-D Screw-E 3.5" HDD Screw-F 2.5" HDD/SSD Standoff Motherboard Nut Setter Standoff Installation Cable Tie Cables/Wires...

  • Page 6: Installation Guide

    CASE B2 SPIRIT User Manual Installation Guide 1. Open the Unit 1-1. Untwist the thumbscrews and slide out panels R and L (Figure 1). 2. Install the Power Supply 2-1. Seat the power supply unit (PSU) to the bottom of the case and secure with Screw-A (Figure 2).

  • Page 7: Install The Motherboard

    CASE B2 SPIRIT User Manual 3. Install the Motherboard 3-1. Line up the standoffs with the screw 3-2. Screw the motherboard down with holes on the motherboard (Figure 3a). Screw-B (Figure 3b). 4. Install the Add-in Card 4-1. Untwist the screws and remove the slot 4-2.

  • Page 8: Install An External 5.25" Device

    CASE B2 SPIRIT User Manual 5. Install an External 5.25" Device 5-2. Remove the slot cover (Figure 5b). 5-1. Pull the front panel out and remove it (Figure 5a). 5-3. Insert the 5.25” drive and push it back into the case. Make sure it’s secured.

  • Page 9: Install A 3.5" Or 2.5" Drive

    CASE B2 SPIRIT User Manual 6. Install a 3.5” or 2.5” Drive 6-1. Pull the HDD tray out from the cage 6-2. 3.5" Drives: Install a 3.5" HDD onto the (Figure 6a). tray (secure with Screw-E if desired) (Figure 6b).

  • Page 10: Care

    CASE B2 SPIRIT User Manual 7. Care To prevent damage, it is recommended to keep all panels closed and secured. 7-1. Slide the side panels back into place and 7-2. Clean the dust filter regularly to ensure secure with thumbscrews (Figure 7a).

  • Page 11: Options

    The B2 SPIRIT has massive capacity for fan installation. Please refer to the Specification Table on page 14 for options. 8-2. Liquid-Cooling Radiator Install The B2 SPIRIT gives you the option of installing a 280 mm radiator to cool your system. 8-2-1. Front location installation: a. Unscrew and remove the fan cage b.
  • Page 12 CASE B2 SPIRIT User Manual 8-2-2. Top location installation: a. Remove the top panel b. Screw the radiator plus fans with screws (Figure 9a). (Figure 9b).

  • Page 13: Specification Table

    CASE B2 SPIRIT User Manual 9. Specification Table Model Model Name B2 SPIRIT Item Number 11-147-245 Specifications Type Full Tower Color Black Case Material SPCC Steel Power Supply Included Motherboard Compatibility E-ATX, XL-ATX, HPTX With Side Panel Window Expansion External 5.25" Drive Bays External 3.5"...
