Chapter 1 – Getting Started
1.1 Subject
The GROM AUX adapter – an integration between an MP3 player and a factory installed car
stereo. Equipped with the specific vehicle harness and standard RCA jack the GROM AUX
interface will allow you to connect your MP3 player or iPod / iPhone to the car stereo system
easily.
1.2 Introduction
Thank you for purchasing the GROM AUX adapter, which has been designed to provide endless
hours of listening pleasure through most vehicles factory radios. To insure that your AUX
interface performs correctly in your car or truck, we recommend that you read this entire manual
before attempting install the GROM interface.
1.3 Precautions
Proper mounting location
Securely install the interface in a location that is free from heat, humidity, moving parts, or direct
sunlight. Beware of hot airflow from your vehicle's climate control system. We recommend
securing the interface to a suitable location, free of sharp metal edges, using double-sided tape,
Velcro, or wire ties.
1.4 Disclaimer
This product is not affiliated with any of the OEM manufactures
Modifying the radio may void any outstanding warranty.
The purchase of this product carries with it no warranties, either expressed or implied.
While every care has been taken to provide a quality product, we cannot guarantee that
the GROM AUX adapter to function correctly if installation is not done according to the
instructions in this guide. We also cannot guarantee that the GROM AUX adapter will
function correctly with an MP3 player if the MP3 player is broken or damaged or not
supported
Keep your eyes on the road while driving!
We are not liable for the misuse of this product. Misuse includes improper installation,
damage to the board or radio while trying to install it, and the illegal use of the radio.
3.1
User Manual
AUX
Advertisement
Table of Contents
Related Manuals for GROM Audio AUX adapter
Summary of Contents for GROM Audio AUX adapter
-
Page 1: Chapter 1 - Getting Started
Chapter 1 – Getting Started 1.1 Subject The GROM AUX adapter – an integration between an MP3 player and a factory installed car stereo. Equipped with the specific vehicle harness and standard RCA jack the GROM AUX interface will allow you to connect your MP3 player or iPod / iPhone to the car stereo system easily. -
Page 2: Completeness And Connection Of Set
1.5 Completeness and connection of set a) GROM Audio AUX adapter set consists of GROM AUX interface, RCA cable, 3.5 mm phone jack, and vehicle specific cable (see figure 1). GROM AUX interface (1) RCA cable (2) 3.5 mm phone jack (3) Vehicle specific cable (4) Figure 1. -
Page 3: Tools Needed
Connect the other end to the interface. In some Toyota/Lexus/Scion and Honda/Acura vehicles, the CD changer port is occupied with a factory harness (such as NAV or audio harness). The GROM package for Toyota/Lexus/Scion and Honda/Acura includes a Y shaped vehicle cable. In order to connect interface properly please follow to the scheme below. - Page 4 9. Once the operation of the interface is confirmed, you may continue with the installation. If you experience difficulties with the installation, please see our troubleshooting section. 10. Find a place where you can place the GROM AUX adapter. In many cars, there is enough room in the dash to place GROM.
-
Page 5: Chapter 3. Support
After connecting the adapter turn the recognizing GROM stereo have to be restarted before stereo on, and then turn the ignition AUX adapter the radio catches the signal off and back on Radio is not External CD changer is present...
