GROM-IPOD V3 Adapter (GROM-IPD3)
Installation and operation instructions
Chapter 1 – Getting Started
1.1 Subject
The GROM iPod V3 adapter—an integration between an iPod (and iPhone) and a car stereo. The GROM
iPod V3 adapter features are:
- iPod/iPhone© play, charge and control via iPod port.
- Bluetooth capability via additional EXT port and GROM Bluetooth Dongle for hands free and wireless
audio streaming from your mobile phone.
- AUX-IN 3.5mm connector for many other audio devices such as XM radio, MP3 or DVD player and etc.
via EXT port.
- Firmware upgradeable via micro SD card, universal adapter that fits into many car makes.
1.2 Introduction
Thank you for purchasing the GROM iPD3 adapter. It has been designed to provide endless hours of
listening pleasure through most vehicles' factory radios. You will be able to control your iPod/iPhone with
the car stereo buttons or steering wheel controls, and your iPod/iPhone will stay charged when
connected to the car stereo. Additional EXT port will allow you to connect GROM Bluetooth Dongle or
any other audio device that has 3.5mm plug. To ensure that your iPod/iPhone performs correctly in your
car or truck, we recommend that you read this entire manual before attempting install the GROM
interface.
1.3 Precautions
Proper mounting location
Securely install the interface in a location that is free from heat, humidity, moving parts, or direct sunlight.
Beware of the hot airflow from your vehicle's climate control system. We recommend securing the
interface to a suitable location that is free of sharp metal edges using double-sided tape, Velcro, or wire
ties.
The iPod/iPhone has not been designed to withstand extreme automotive temperatures. You may
damage your iPod/iPhone if you leave it inside your vehicle on a very hot or very cold day. For further
information, please refer to your iPod/iPhone manual.
1.4 Disclaimer
This product is not affiliated with any OEM manufacturers.
•
Modifying the radio may void any outstanding warranty.
•
The purchase of this product carries with it no warranties, either expressed or implied.
•
rev. 4.1
Copyright©GROM Audio, 2011
1
