Predator Engines PREDATOR 212 Owner's Manual & Safety Instructions page 28

68306 420cc Parts List
Part Description
1 Gasket, Cylinder Head
2 Cover Asm., Cylinder Head
3 Gasket, Cylinder Head Cover
4 Tube, Breather
5 Bolt Asm., Cylinder Head Cover
6 Stud
7 Stud
8 Pin
9 Bolt, Cylinder Head
10 Plug, Spark
11 Head Asm., Cylinder
12 Crankcase Asm.
13 Seal, Oil
14 Sensor, Engine Oil
15 Frame, Fuel Tank
16 Plug, Rubber
17 Protector, Oil
18 Bolt
19 Washer, Flat
20 Bolt, Drain Plug
21 Clip
22 Arm, Governor
23 Seal, Oil
24 Pin
25 Bolt
26 Bolt
27 Washer_ Flat
28 Bearing
29 Cover, Crankcase
30 Gasket, Crankcase
31 Plug Asm., Engine Oil
32 Dipstick Asm., Oil
33 Pin
34 Bolt
35 Bearing
36 Gear Asm., Governor
37 Seal, Oil
38 Bearing
39 Crankshaft Asm.
40 Shaft Asm., Balancing
41 Ring Set, Oil
42 Clip, Piston Pin
43 Piston
44 Pin, Piston
45 Rod, Connecting
46 Ring, Primary
47 Ring, Secondary
48 Camshaft Asm.
49 Valve, Exhaust
50 Valve, Intake
51 Seat, Valve Spring
52 Retainer, Exhaust Valve
53 Rotator, Valve
54 Guide, Seal
55 Tappet, Valve
56 Lifter Asm., Valve
57 Plate Asm., Lifter Stopper
58 Bolt, Valve Adjusting
59 Rocker, Valve
60 Nut, Valve Adjusting
61 Nut, Valve Lock
62 Spring, Valve
Page 28
Qty.
1
1
1
1
1
2
2
2
4
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
4
2
1
1
1
1
1
1
2
7
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
2
2
2
2
2
For technical questions, please call 1-800-520-0882.
Part Description
63 Retainer, Valve Spring
64 Starter Asm., Recoil
65 Bolt
66 Shroud
67 Shroud, Cylinder Body
68 Bolt
69 Bolt
70 Carburetor Asm.
71 Gasket, Air Cleaner
72 Gasket, Carburetor
73 Plate, Carburetor Insulator
74 Gasket, Inlet
75 Nut
76 Cleaner, Air
77 Bolt
78 Nut
79 Gasket, Exhaust Outlet
80 Nut
81 Muffler Asm.
82 Gasket, Aux. Air Intake Valve
83 Valve, Aux. Air Intake
84 Bolt
85 Tank, Fuel
86 Strainer, fuel
87 Cover, Fuel Tank
88 Outlet Asm., Fuel Tank Oil
89 Collar
90 Tube, Fuel
91 Clip
92 Nut
93 Valve, One Way
94 Hose, Fuel Vapor Rubber
95 Hose, Air Cleaner Rubber
96 Collector, Fuel Vapor
97 Bolt
98 Cover, Fuel Vapor Collector
99 Nut, Flywheel
100 Pulley, Starter
101 Impeller
102 Flywheel Asm.
103 Bolt
104 Cap, Spark Plug
105 Coil Asm., Charge
106 Bolt
107 Coil, Ignition
108 Bolt
109 Control Asm., Throttle
110 Bolt
111 Spring, Throttle Returning
112 Rod, Governor
113 Support Asm., Governor
114 Nut
115 Bolt, Governor Support
116 Spring, Governor
117 Motor Asm., Starting
118 Bolt
119 Relay, Starting
120 Bolt
121 Switch, Control
122 Bolt
123 Exhaust Gasket
124 Exhaust Manifold
Qty.
1
1
4
1
1
1
5
1
2
1
1
1
2
1
1
3
1
2
1
1
1
2
1
1
1
1
5
1
1
2
1
1
1
1
2
1
1
1
1
1
1
1
1
2
1
2
1
2
1
1
1
1
1
1
1
2
1
2
1
2
1
1
REV 11k
Horizontal Engines
