Predator Engines PREDATOR 212 Owner's Manual & Safety Instructions page 24

68121 212cc Parts List
Part Description
1 Gasket, Cylinder Head
2 Cover Asm., Cylinder Head
3 Gasket, Cylinder Head Cover
4 Tube, Breather
5 Bolt
6 Stud
7 Stud
8 Stud
9 Pin
10 Bolt, Cylinder Head
11 Plug, Spark
12 Head Asm., Cylinder
13 Crankcase Asm.
14 Sensor, Engine Oil
15 Gear Asm., Governor
16 Arm, Governor
17 Bolt, Drain Plug
18 Washer
19 Bearing
20 Seal, Oil
21 Washer
22 Pin
23 Bolt
24 Cover, Crankcase
25 Bearing
26 Seal, Oil
27 Gasket, Crankcase
28 Pin
29 Dipstick Asm., Oil
30 Plug Asm., Engine Oil
31 Bolt
32 Crankshaft Asm.
33 Clip, Piston Pin
34 Piston
35 Pin, Piston
36 Rod, Connecting
37 Ring, The First
38 Ring, The Second
39 Ring Set, Oil
40 Camshaft Asm.
41 Valve, Exhaust
42 Valve, Intake
43 Seat, Valve Spring
44 Retainer_ Exhaust Valve
45 Rotator, Valve
46 Guide, Seal
47 Tappet, Valve
48 Lifter, Valve
49 Plate Asm., Lifter Stopper
50 Bolt, Valve Adjusting
51 Rocker, Valve
52 Nut_ Valve Adjusting
53 Nut, Valve Lock
54 Spring, Valve
Page 24
Qty.
1
1
1
1
4
1
1
2
2
4
1
1
1
1
1
1
2
2
1
1
1
1
2
1
1
1
1
2
1
1
6
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
2
2
2
2
2
For technical questions, please call 1-800-520-0882.
Part Description
55 Starter Asm., Recoil
56 Bolt
57 Shroud
58 Shroud, Cylinder Body
59 Shield,Lower
60 Protector, Oil
61 Switch Asm., Stop Engine
62 Bolt
63 Bolt
64 Collar
65 Bolt
66 Bolt
67 Carburetor Asm.
68 Gasket, Air Cleaner
69 Gasket, Carburetor
70 Plate, Carburetor Insulator
71 Gasket, Carburetor Insulator
72 Nut
73 Cleaner, Air
74 Bolt
75 Gasket, Exhaust Outlet
76 Nut
77 Muffler Asm.
78 Bolt
79 Gasket, Auxiliary Air Valve Flange
80 Valve, Muffler Auxiliary
81 Tank, Fuel
82 Strainer, Fuel
83 Cap, Fuel
84 Outlet Asm., Fuel Tank Oil
85 Clamp
86 Tube, Fuel
87 Bolt
88 Nut
89 Vent, Vapor
90 Hose, Vapor Rubber
91 Band
92 Collector, Vapor
93 Clamp
94 Hose, Air Cleaner Rubber
95 Nut, Flywheel
96 Pulley,Starter
97 Impeller
98 Flywheel Asm.
99 Bolt
100 Coil, Ignition
101 Control Asm., Throttle
102 Bolt
103 Spring, Governor
104 Rod, Governor
105 Spring, Throttle Valve Returning
106 Bolt, Governor Support
107 Nut
108 Support Asm., Governor
Qty.
1
3
1
1
1
1
1
2
1
1
1
4
1
1
1
1
1
2
1
1
1
2
1
2
1
1
1
1
1
1
4
1
1
2
1
1
2
1
2
1
1
1
1
1
2
1
1
2
1
1
1
1
1
1
Horizontal Engines
