- Page 1 OWNER’S MANUAL UltraCool Space Saver EVAPORATIVE AIR COOLER MODEL: N30G READ AND SAVE THIS INSTRUCTION MANUAL Date purchased: ___________________ Purchased from: ___________________ P/N 71213 REV. 3/05...
- Page 2 THIS PAGE BLANK...
-
Page 3: Installation
It is exhausted out open windows or doors, carrying heat, smoke and odors along with it. Essick evaporative coolers are 80% less costly to operate than refrigerated air conditioners. -
Page 4: Maintenance
INSTALL OVERFLOW AND DRAIN NOTE: There are two overflow assemblies supplied with this unit. Install one in each of the openings in the bottom pan. One overflow assembly is to route water tubing to the float. 1. Slide the Rubber Washer over the Drain Bushing and push through the hole in the bottom of the cooler from the topside. -
Page 5: Wiring Diagram
DO NOT GET WATER ON MOTOR OR PUMP MOTOR NOTE: Depending on the mineral content of the water or the amount of air borne dust in your area, pad life may vary. When it comes time to replace your pads, It is best to replace filter pads at the end of the season. Old filter pads soak up lime and salts, which can rust the louvers and the cabinet during the winter months. - Page 6 Item Description Part No. Item Description Part No. Grille Frame 70658 Water Distributor 71212 Sub-Vent Assembly 70741 71204 Duct Front 71219 Blower Housing 70367 Duct Back 71207 Blower Wheel 70424 Knob 70664 Motor 70423 Switch Bracket 70798 Inlet Ring 70425 Switch 524299 Motor Mount Bushing...
-
Page 7: Limited Warranty
Essick Air Products recommends is used in the unit. Essick Air Products is not responsible for the cost of service calls to diagnose cause of trouble, or labor charge to repair and/or replace parts. - Page 8 THIS PAGE BLANK...
