- Page 1 E4H SERIES WATER PURIFICATION MACHINES OPERATION AND MAINTENANCE MANUAL...
-
Page 3: Table Of Contents
2.2.2 Valves Required for Clean-In-Place ... 10 2.2.3 Concentrate Outlet Connection ... 10 2.2.4 Permeate Outlet Connection... 10 Electrical ... 10 2.3.1 Economy Electrical System... 11 2.3.2 Deluxe Electrical System... 11 FOR GE OSMONICS E4H SERIES TABLE OF CONTENTS Page... - Page 4 PREPARATION AND START-UP ... 12 Pretreatment for Water Purification... 12 Start-Up... 12 OPERATION AND MAINTENANCE ... 18 Daily Log Sheets... 18 Pre-Filter Cartridge ... 18 Flushing ... 19 Cleaning ... 19 Draining Machine for Shipment ... 21 Membrane Element Installation... 22 Membrane Element Replacement...
- Page 5 LIST OF FIGURES Normal Versus Cross Flow Filtration ... Membrane Element with Interconnectors... Cross Sectional View of Membrane Element... Principles of Operation ... LIST OF TABLES Feed Water Requirements ... Typical Membrane Element Rejections/Passages... Machine Recovery ... 16 Dry Chemical Cleaners ... 20 Page...
-
Page 7: Description
/ dissolved impurities occurs during the RO process. Unlike a filter, which separates by “normal” filtration, the General Electric (GE) Osmonics membrane element sep- arates using a process called cross flow filtration. Feed water solution is separated into two streams, permeate and concentrate, and collected from both sides of the membrane element. -
Page 8: Membrane Element With Interconnectors
Figure 1.2 - Membrane Element with Interconnectors Figure 1.3 Cross Sectional View of Membrane Element... -
Page 9: Principles Of Operation
Some operating definitions are provided to help you further understand your machine: Permeate Rate [Product Water Rate (Q passed through the membrane element and out of the membrane element housing; expressed in gal/min (gpm) or gal/hr (gph) [in metric, liter/min (Lpm) or cubic meters/hour (m /h)]. -
Page 10: Machine Nomenclature
Machine Nomenclature GE Osmonics E-Series water purification machines are numbered in such a way as to indi- cate the permeate flow and quality you can expect from the machine. -
Page 11: Machine Permeate Quality
Example: E4H-21K/ECN, 230, 6, 50-75 • E4H indicates the machine series • H indicates horizontal membrane element housing configuration • 21K indicates the rated permeate flow in thousands of gallons per day @ 77ºF (25ºC),(i.e., 21K = 21,000 gallons per day) •... -
Page 12: Deluxe Model Options
• Digital concentrate and permeate flow meters • Digital conductivity monitor, panel-mounted, for permeate quality monitor- • Autoflush System - programmable, automated high-velocity membrane ele- ment flushing for the longest membrane element life; set at the factory and adjustable in the field •... -
Page 13: Specifications For E-Series Machines
• Alarms included: low inlet pressure, high amp draw, high / low pH Specifications for E-Series Machines 1.5.1 Feed Water Requirements Temperature Inlet Pressure Chlorine (continuous feed) Operating pH Pre-filter Inlet Connections 1.5.2 Permeate (Product Water) Flow Rate Stated on the serial number label (assumes no permeate back pressure, 2000 mg/L TDS maximum feed concentration, and rated temperature). -
Page 14: Concentrate Flow Rate
1.5.3 Concentrate Flow Rate Factory set as stated on serial number label Concentrate Outlet: 1.5.4 Typical Pure Water Recovery: 1.5.5 Final Operating Pressure Minimum: Maximum: 1.5.6 Pump Multi-stage centrifugal, approximate primary operating pressure of 190 psig (13.1 barg), excluding line pressure. 1.5.7 Reverse Osmosis Membrane Element Rejection Osmo HR(PA) -
Page 15: Typical Membrane Element Rejections/Passages
SALTS CATIONS Percent Percent Passage Concentration Name Symbol Rejection (Avg) Sodium 94-96 Calcium 96-98 Magnesium 96-98 Potassium 94-96 I r o n 98-99 Manganese 98-99 Aluminum Ammonium 88-95 Copper 98-99 Nickel 98-99 Zinc 98-99 Strontium 96-99 Hardness Ca & Mg 96-98 Cadmium 96-98... -
Page 16: Installation
[Maximum back pressure is 60 psig (4.1 barg).] Models. GE Osmonics has installed a plugged pipe tee in the inlet line of the E4H units. This plug, when removed, will facilitate cleaning of the unit. A tee with (two) -
Page 17: Electrical
2.2.4 Permeate Outlet Connection Install the CIP valve on the permeate outlet tee. The pure water (permeate) should be transported to the point of use via non-corroding-type tubing, pipe, or hose. Examples are: food-grade flexible nylon tubing, stainless steel tubing, or PVC hose. -
Page 18: Preparation And Start-Up
If the machine is to be run at a different location than was originally intended, a new water analysis is required for warranty consideration and should be sent to GE Osmonics for review and recommenda- tions for operation of the machine. - Page 19 STEPS Re-check the function and integrity of your pretreatment equipment. Ensure that your water softener, activated carbon filters and iron filters (where applicable) have been leak-checked, backwashed, and thoroughly rinsed for service before starting up your RO unit. Attach the feed water pipe to the inlet of the machine. Check for leaks at all connection points.
- Page 20 inlet stream to the RO pump. It is important to balance the operating pres- sure and the respective flows of these valves to ensure that your machine is operating correctly. It is also important to understand the relationship of these two valves, the pressure gauge, and your RO pump. The pump has a fixed amount of flow produced, and the valves are the control devices to distribute this fixed flow amount.
- Page 21 NOTE: Do not allow the pressure to exceed 250 psi (17.2 bar). If the pressure exceeds 250 psi (17.2 bar), open the concentrate flow control valve until the pressure gauge shows 250 psi (17.2 bar) or less. As the machine purges the air and fills with water, the pressure will grad- ually increase.
-
Page 22: Machine Recovery
Once the desired flow rate is achieved [250 psi (17.2 bar) operating pres- sure] no further valve adjustment is needed. The table below shows flow rates at 50%, 66% and 75% recovery for the E4H models. Use this table in adjusting flow rates. NOTE: Permeate flow rates are dependent upon temperature and con- ditions at your site. - Page 23 A Daily Log Sheet (Section 10.0) which includes general operating con- ditions (pressures, flows, concentrations, pH, and pretreatment condi- tions), and routine or special maintenance (flushing or cleaning as need- ed) must be kept. This Daily Log Sheet will be required by GE Osmonics if a warranty question arises.
-
Page 24: Operation And Maintenance
OPERATION AND MAINTENANCE The operation and maintenance of your GE Osmonics E4H Machine is relatively simple but requires regular data recording and routine preventative maintenance. We cannot emphasize too strongly the importance of filling out the daily log sheet during each operating shift. A data sheet was filled out upon start-up containing pertinent facts on the operation of your machine. -
Page 25: Flushing
GE Osmonics recommends cleaning at least every month to ensure good membrane ele- ment performance and long membrane element life. GE Osmonics offers a full line of chemical cleaners for specific cleaning needs. See Table 4.4 (Dry Chemical Cleaners). Do not operate the machine below the designated pressure without approval from GE Osmonics. -
Page 26: Dry Chemical Cleaners
Cleaner Osmo AD-20 Dry acid-surfactant for cleaning TLC, PA and CA membrane elements. Osmo AK-110 High pH alkaline cleaner for PA membrane elements. where microbial fouling is a problem. DO NOT use on CA membrane elements. Osmo ET-70 Cleaner intended to deal with sulfate or iron precipitation fouling. -
Page 27: Draining Machine For Shipment
The RO is now ready for operation. Draining Machine for Shipment Prior to shipping or outside storage of a GE Osmonics E4H Machine, the system should be cleaned with the appropriate cleaner, flushed with water, and protected from biological attack with the appropriate solution for TLC membrane. -
Page 28: Membrane Element Installation
Remove the tubing connections on the inlets and outlets of the membrane element housings. Open the concentrate valve. Remove the drain plugs from all PVC manifolds. Be sure the flow meters are drained by disconnecting the bottom fitting of each flow meter. -
Page 29: Membrane Element Replacement
Inspect the membrane element housing and clean as necessary to remove any con- taminants, obstructions, etc. Apply a small amount of O-ring lubricant to all O-rings on the end caps, and the brine seal on the membrane element. Insert the downstream end of the membrane element in the upstream end of the membrane element housing (i.e., load in the direction of flow;... - Page 30 Remove all the membrane elements from the membrane element housings in the direction of flow, where possible. If necessary, a membrane element can be removed against the direction of flow. A heavy duty pliers or channel lock pliers may be necessary to pull the old membrane element our of the membrane element housing.
-
Page 31: Optional Accessories
OPTIONAL ACCESSORIES Level Controls Float switches, pressurized storage switches or other level controls should be wired into the control circuit line prior to the switch on the unit. The following ensures that the inlet valve, instruments, and pump are not powered when storage tanks are full: float switch assembly with cord, counterweight, and plastic float (used with an atmospheric storage tank). -
Page 32: Troubleshooting
TROUBLESHOOTING SYMPTOM Low operating pressure Low permeate flow rate TROUBLESHOOTING GUIDE POSSIBLE CAUSES Insufficient feed water pressure or flow Clogged pre-filter cartridge High flow rates Dirty or fouled membrane elements Solenoid valve not opening Pump rotating backwards (three-phase power only) Insufficient electrical power Pump not operating correctly Low operating pressure... - Page 33 SYMPTOM Low permeate flow rate (continued) Low concentrate flow rate, normal or higher than normal pressure Pressure does not drop when concentrate valve opened TROUBLESHOOTING GUIDE POSSIBLE CAUSES Dirty or fouled membrane elements Operating on cold water less than 55ºF (13ºC) Membrane elements installed backwards or damaged concentrate seal...
- Page 34 SYMPTOM High operating pressure Excessive pressure drop [over 50 psig (3.4 barg)] (high primary pressure - low final pressure) Water flowing when machine is turned OFF Declining rejection (high permeate conductivity) TROUBLESHOOTING GUIDE POSSIBLE CAUSES Recycle or concentrate valve plugged Inaccurate pressure gauge Restricted or reduced permeate flow rate...
- Page 35 Allow the machine to cool; check the feed water supply and/or AMP draw to the motor. Check the fuses or circuit break- ers, measure the voltage. See pump instructions. Contact GE Osmonics for possible repair or replacement.
- Page 36 TROUBLESHOOTING GUIDE SYMPTOM POSSIBLE CAUSES REMEDIES Electrical machine shutdown Alarm condition has turned Restart the machine by pushing machine OFF the alarm bypass. Check all possible alarm conditions: inlet pressure or motor starter overload. Motor starter overloaded, heater Turn the switch OFF; rest the tripped heater(s).
-
Page 37: Return Goods Authorization (Rga) Procedure
If you wish to return good for repair, warranty evaluation and/or credit, please have your original sales order or invoice available when you call GE Osmonics. Call (800) 848-1750 and ask to speak with Customer Service. A GE Osmonics Customer Service representative will provide instructions and a return authorization number which needs to be clearly written on the outside of the box used to ship your materials. -
Page 38: Warranty
WARRANTY Warranty Terms Subject to the terms and conditions set forth hereinafter, Seller (GE Osmonics, Inc. or any of its authorized subsidiaries) warrants to the original purchaser (hereafter the “Buyer”) that the products manufactured by Seller are free from defects in material and in work-... - Page 39 workmanship. Required or replaced products or components shall be returned to the Buyer by the Seller, freight prepaid by Seller, via UPS ground or best way surface freight. In genuine emergency situation, Seller will (at Seller’s sole option) forward replacement parts to Buyer without waiting for authorized return of the questionable part(s).
-
Page 40: Start-Up Data Sheet
START-UP DATA Customer: Model Number: Serial Number: Temperature Permeate Rate Concentrate Rate Total Flow Rate Recovery Pre-Filter Pressure Post-Filter Pressure Primary Pressure Final Pressure Feed TDS Concentrate TDS Average TDS Permeate TDS (manual) Permeate TDS (meter µ µ S) % Passage (Perm TDS / Avg TDS) Chlorine in Concentrate Low Pressure Switch... - Page 44 +33 1 64 10 3747 Fax Manufactured in the USA Asia/Pacific Operations 1044/8 SOI 44/2 Sukhumvit Road Prakanong Bangkok 10110 THAILAND +66 2 38 14213 Phone +66 2 39 18183 Fax ' Copyright 2003, GE Osmonics Printed in USA, P/N 1163955 Rev. C...
