Owner's Manual
WARNING: Follow all leak check
procedures carefully in this manual prior
to barbecue operation. Do this even if
barbecue was dealer assembled.
NOTICE TO INSTALLER: These
instructions must be left with the owner
and the owner should keep them for
future use.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
GENESIS
Propane Fixed Piping System
®
2000 Series
®
Serial Number
Please use this number in registering your warranty
and any correspondence with the factory.
WARNING: Do not try to light this
appliance without reading "Lighting"
instructions section of this manual.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call
your gas supplier or your fire
department.
© 1992, Weber-Stephen Products Co.
62714
GAS
BARBECUE
®
gama
3/94

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Genesis 2000 LP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weber Genesis 2000 LP

Summary of Contents for Weber Genesis 2000 LP

  • Page 1 Do not store or use gasoline or other 4. If odor continues, immediately call flammable vapors and liquids in the your gas supplier or your fire department. vicinity of this or any other appliance. © 1992, Weber-Stephen Products Co. 62714 3/94...

  • Page 2: Warnings

    Weber Gas Barbecue. Your Weber Gas Barbecue should never be used by children. You should exercise reasonable care when operating your Weber Gas Barbecue. It will be hot during cooking or cleaning, and should never be left unattended. Should the burners go out during operation, turn all gas valves off. Open the lid and wait five minutes before attempting to relight, using the lighting instructions.
  • Page 3 There are no other express warrants except as warrants to the ORIGINAL PURCHASER of set forth herein and any applicable implied this Weber Gas Barbecue that it will be free of warranties of merchantability and fitness are defects in material and workmanship from the...

  • Page 4: Patents And Trademarks

    , Genesis, Flavorizer and Crossover are registered U.S. trademarks; Spirit, Perma-Mount, Gas Catcher, FlameCheck, Steam-N-Chips, Spider Stopper, and Warm-Up are U.S. trademarks of Weber-Stephen Products Co., 200 East Daniels Road, Palatine, IL 60067-6266. Spirit 500, 700, and Genesis 1000-5500 Gas Barbecues are covered under one or more of the following patent nos.: U.S.

  • Page 5: Table Of Contents

    Troubleshooting ..........32 Parts Listing .............. 35 FEATURES: a) Convenient tables and racks. e) Weber Warm-Up Basket for additional cooking or warming space. b) Heavy gauge porcelain-on-steel lid seals in heat. Separate burners for temperature control. c) Rapid read thermometer for precision cooking...

  • Page 6: General Instructions

    When the Weber Gas Barbecue is stored indoors, flavor in the food. the gas supply must be disconnected. The Weber Gas Barbecue is portable so you can easily change its location in your yard or on your patio. Operating area Portability means you can take your Weber Gas Barbecue with you if you move.

  • Page 7: Assembly

    While we give much attention to our products, unfor- tunately an occasional error may occur. If a part is missing, do not go back to the store. Call the Weber Customer Service Center toll free 1-800-446-1071 to receive immediate assistance. Have your owner’s manual available for reference.
  • Page 8 Control panel Right frame Front panel Caster frame Left frame Two casters Wheel frame Two cooking grates Two frame connectors Warming rack Five long Flavorizer Bars Warm-Up Basket Eight short Flavorizer Bars Thermometer Two wheels Left hand slide bar assembly Two aluminum drip pans Assembly consists of: Catch pan...
  • Page 9 Catch pan holder Two 10-24 x 1 3/4 machine screws (actual size) Manifold bracket Eighteen 1/4 inch nylon washers (actual size) Check contents of hardware packs 1/4-20 acorn nut (actual size) Three burner control knobs 1/4-20 x 1 1/4 inch bolt (actual size) 1/4-20 hex nut Three tool holders...
  • Page 10 Tap on one hubcap. the boxes) to protect the finish during frame assembly. Put one wheel on the axle, WEBER side toward the hubcap. Slide the axle through the frame. Add the other Put the frame pieces so the leg tabs are up. Put the wheel, WEBER side out.
  • Page 11 Step 4 Step 5 Continue frame assembly Complete frame assembly You will need: frame assembly, wheel frame assembly, You will need: partial frame assembly, two frame front panel, caster frame, four 1/4-20 x 1/2 inch bolts, connectors, four 1/4-20 x 2 inch bolts, four nylon four nylon washers and a 7/16 inch wrench.
  • Page 12 Step 7 Your Weber Gas Barbecue burner assembly has been factory assembled, pressure and flame tested. As a Add cooking box safety precaution we recommend you check the burner alignment: You will need: frame assembly, cooking box assembly, 1/4-20 x 2 inch bolt, 1/4 inch nylon washer, 1/4-20 acorn a) Do the valves fit into the ends of the burners? nut, pliers and a 7/16 inch wrench.
  • Page 13 Step 9 Typical propane gas supply installation. Figure 10. Install gas supply General Specifications for Piping Note - Contact your local municipality for building codes regulating outdoor gas barbecue installations. In absence of Local Codes, you must conform to the latest edition of ANSI Z223.1. WE RECOMMEND THAT THIS INSTALLATION BE DONE BY A PROFESSIONAL.
  • Page 14 Step 10 Step 12 Check that all burner valves are off Install igniter You will need: one burner control knob. Note - The igniter wires are already attached to the Gas Catcher Ignition Chamber and the igniter. This was done (Valves are shipped in the OFF position, but you should to factory test the ignition system.
  • Page 15 The burners have the source and rinse connections with water. been flame tested. As a safety precaution you should recheck all fittings for leaks before using your Weber Genesis Gas Barbecue. Shipping and handling may have loosened or damaged a gas fitting.
  • Page 16 Step 14 Step 15 Install the bottom tray Install Flavorizer Bars and Cooking Grates You will need: bottom tray, catch pan holder, catch pan You will need: five long Flavorizer Bars, eight short and one drip pan. Flavorizer Bars and two cooking grates. Set the long Flavorizer Bars side to side in the lower position, then set the short Flavorizer Bars front to back in the upper position in the cooking box.

  • Page 17: Control Knobs

    Step 16 Step 17 Install the lid Install tool holders, control panel and burner control knobs You will need: lid, two hinge pins and two hair pin cotters. You will need: three tool holders, control panel and three Set the lid in place from the rear of the barbecue. Close burner control knobs.
  • Page 18 Step 18 Insert one end of the hinge rod into the hole in the frame. Figure 24 (a). Install swing table Insert the other end into the hole in the swing table end You will need: swing table end bracket, two 10-24 hex bracket.
  • Page 19 Warm-Up Basket, warming rack, thermometer, three tubing plugs and a hammer. Notch to the front Insert one end of the Weber Warm-Up Basket into the hole in the right end of the lid and the other end into the Slide bar slot in the left end of the lid.

  • Page 20: Operating Instructions

    Note - Always light the FRONT burner first. The other found to be damaged in any way, do not use the burners ignite from the FRONT burner. barbecue. Replace using only Weber authorized replacement hose. Order from Weber-Stephen Products Co., Customer Service Center or To Extinguish authorized dealer.

  • Page 21: Manual Lighting

    Manual Lighting WARNING: If the burner does not light, turn the Front burner control knob to OFF and wait 5 minutes to let the gas clear before you try again or try to light with a DANGER match. Failure to open lid while igniting the barbecue, or not waiting 5 minutes to 7) After the FRONT burner is lit you can turn on the allow the gas to clear if the barbecue does...

  • Page 22: Cooking

    CAUTION: Do not use oven cleaner, abrasive cooking you would use (MOM) (FRONT at medium, cleansers (kitchen cleansers) cleaners that contain CENTER off, and BACK at medium). See your Weber citrus products or abrasive cleaning pads on cookbook for detailed cooking instructions.

  • Page 23: Annual Maintenance

    OFF the gas. DO NOT OPERATE THE BARBECUE. found to be damaged in any way, do not use the Contact your dealer. barbecue. Replace using only Weber authorized replacement hose. Order from Weber-Stephen b) Valves to manifold connections. Figure 3 (b).

  • Page 24: General Maintenance

    General Maintenance Main Burner Flame Pattern Weber Spider Stopper Guards Your Weber Genesis Gas Barbecue, as well as any The Weber Genesis Gas Barbecue burners have been outdoor gas appliance, is a target for spiders and other factory set for the correct air and gas mixture. The correct insects.
  • Page 25 d) Unlatch the Spider Stopper Guards and remove. g) Lift and twist the burner assembly slightly, to Figure 7. separate the crossover tube from the burners. Figure 10. Remove the burners from the cooking box. Crossover tube Figure 10 Figure 7 h) To reinstall burners, reverse steps c) through g).
  • Page 26 Crossover Ignition System Operations If the Crossover Ignition System fails to ignite the Front burner, light the Front burner with a match. If the Front burner lights with a match, then check the Crossover Ignition System. Check that both the white and black ignition wires are attached properly.

  • Page 27: Troubleshooting

    TROUBLESHOOTING & MAINTENANCE Troubleshooting Problem Check Cure Burners burn with a yellow or orange flame, in Inspect Weber Spider Stopper Clean Weber Spider Stopper conjunction with the smell of gas. Guards for possible obstructions. Guards. (See Section "Annual (Blockage of holes.) Maintenance".)
  • Page 28 14-15 51-55 17-18, 15 21-22 26 27 28 29 30 31...

  • Page 29: Parts List

    Palatine, IL 60067-6241 Products Company by phone or mail. (708) 705-8660 Note - Do not return parts to Weber-Stephen Products (800) 446-1071 Co. without first contacting the Customer Service Center by phone or mail. Returning the part may not be necessary.
  • Page 30 INAL HANKS hank you for choosing a Weber Barbecue. Our family here at Weber has worked hard to produce the highest quality products for your satisfaction. While we give much attention to our products, an occasional error may occur. Our knowledgeable Customer Service staff is prepared to help you with any problems with parts or assembly.
