Model #: OMNIVS1500XL
OmniVS Series 1500VA Tower Line-Interactive 120V UPS with USB port and Extended-run options
Description
Tripp Lite's OMNIVS1500XL line interactive UPS system offers voltage regulation, surge suppression and long lasting, expandable battery support
for personal computers, internetworking equipment and other sensitive electronics. Internal UPS batteries support entry level PC systems for up to
75 minutes during power failures so that connected equipment can be shut down without data loss. Automatic Voltage Regulation (AVR) circuits
regulate brownouts as low as 75 and overvoltages up to 147 volts back to usable 120V levels without using battery power. Offers complete desktop
power protection in an attractive black tower configuration. Includes 6 battery supported outlets for computer, monitor and vital system peripherals,
plus 2 additional surge suppression only outlets for printers and other system accessories not requiring battery support. USB port enables optional
unattended system shutdown without data loss in the case of extended power failure (USB cable included). PowerAlert software available via free
download from www.tripplite.com. Built-in data line suppression offers protection for equipment with single line TEL/DSL or network Ethernet
connection. Built-in audible alarm and 5 front panel LEDs indicate status of line power, battery power, battery low/replace, voltage regulation and
overload. 1500VA power handling ability supports entry-level PCs, network workstations, point-of-sale equipment, small business phone systems,
audio/video equipment and home theater systems. Offers 4.5 minutes battery runtime with a full load of 1500VA and 13 minutes with a half load of
750VA. Supports hot-swappable battery replacement via built-in access panel. Extended runtime available with optional BP24V15RT2U,
BP24V28-2U, or BP24V70-3U external battery packs.
Package Includes
OMNIVS1500XL Line Interactive UPS
USB and telephone cable
Owner's manual with warranty information
Features
OMNIVS1500XL Uninterruptible Power Supply offers voltage regulation, surge suppression and long lasting battery support
Supports entry level PCs up to 75 minutes during blackouts to enable shutdown without data loss
Regulates brownouts as low as 75V and overvoltages to 147V back to usable 120V nominal levels without using battery power
6 UPS battery supported outlets, plus 2 additional surge suppression-only outlets
USB port and cable enables UPS monitoring and unattended shutdown in the case of extended power failure
PowerAlert software available via free download from www.tripplite.com
Data line surge suppression protects standard dialup/DSL or Ethernet line connection
Built-in audible alarm and 5 front panel LEDs indicate status of line power, battery power, battery low/replace, voltage regulation and
Highlights
1500VA / 1.5kVA tower 120V line interactive extended-run UPS
Corrects brownouts and overvoltages from 75 to 147V
6 UPS battery supported outlets, 2 surge-only outlets
USB port, TEL/DSL/ethernet protection, External battery pack options
NEMA 5-15P input plug and 8 NEMA 5-15R outlets
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail:
saleshelp@tripplite.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMNIVS1500XL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tripp Lite OMNIVS1500XL

  • Page 1 NEMA 5-15P input plug and 8 NEMA 5-15R outlets Description Tripp Lite's OMNIVS1500XL line interactive UPS system offers voltage regulation, surge suppression and long lasting, expandable battery support for personal computers, internetworking equipment and other sensitive electronics. Internal UPS batteries support entry level PC systems for up to 75 minutes during power failures so that connected equipment can be shut down without data loss.
  • Page 2: Specifications

    overload 1500VA power handling ability supports a variety of sensitive electronic equipment 4.5 minutes full load runtime (1500VA), 13 minutes half load runtime (750VA) Runtime is expandable with the addition of external battery packs (SEE OPTIONS & ACCESSORIES) Supports hot swappable battery replacement via built-in access panel $200,000 connected equipment insurance (USA, Puerto Rico and Canada only)
  • Page 3: Voltage Regulation

    External battery pack BP24V15RT2U (limit 1); BP24V28-2U (limit 1); BP24V70-3U (multi-pack compatible) compatibility DC system voltage (VDC) Battery recharge rate Less than 4.5 hours from 10% to 90% (included batteries) Replacement battery RBC51 (quantity 2) cartridge (internal UPS battery replacement) Battery Access Battery access door Battery replacement...
  • Page 4: Special Features

    UPS / Power Module 29.8 x 18.4 x 19 dimensions in primary form factor (height x width x depth / cm) UPS / Power Module weight (lbs) UPS / Power Module weight 12.7 (kg) UPS Shipping dimensions 15.5 x 11 x 11.2 (height x width x depth / inches) UPS Shipping dimensions...
  • Page 5: Warranty

    Copyright © 2013 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
