Device Codes ......36-39 This Universal Remote Control is already programmed for most GE, RCA and ProScan TVs, VCRs, DBS Systems, DVD Players, and Audio/Video Receivers.
ON•OFF The ON•OFF button operates the same as your origi- nal remote. NOTE: Some GE, RCA and ProScan models require you to press the device button to turn the device on and the ON•OFF button to turn the device off.
Page 4
94940 Revised Size 10/18/02 MENU Brings up the Main Menu. If you already in the menu system, press SELECT to select a highlighted choice. Use the arrows buttons to move through the Menu Selection. CLEAR Removes the on screen display to return to normal viewing.
94940 Revised Size 10/18/02 12:22 PM Page 5 Learning Function The learning feature is used as a supplement to the standard prepro- grammed library. The standard code library provides most of the functions needed, but you can add a small number of additional functions of your choice.
94940 Revised Size 10/18/02 Clearing A Learned Button To clear a learned button sequence, use the procedure below. Note: No functions may be stored under the LEARN, SLEEP, CODE SEARCH or any of the device buttons. 1. Press and hold the CODE SEARCH button until the INDICATORLIGHT lights, then release the CODESEARCH button.
94940 Revised Size 10/18/02 Programming For TV Most GE, RCAand ProScan TVs will not require pro- gramming. Check to see if your TV responds to the remote before you begin programming. 1. Manually turn on the TV. Find the three digit code for your TV in the code list at the back of the instruc- tions.
94940 Revised Size 10/18/02 Programming For VCR Most GE, RCAand ProScan VCRs will not require programming. Check to see if your VCR responds to the remote before you begin programming. 1. Manually turn on the VCR. Find the three digit code for your VCR at the back of the instructions.
94940 Revised Size 10/18/02 Programming For DVD Most GE, RCAand ProScan DVD systems will not require programming. Check to see if your DVD sys- tem responds to the remote before you begin pro- gramming. 1. Manually turn on the DVD system. Find the three digit code for your DVD system at the back of the instructions.
94940 Revised Size 10/18/02 Programming For DBS Satellite System Most GE, RCAand ProScan Satellite systems will not require programming. Check to see if your DBS Satellite system responds to the remote before you begin programming. 1. Manually turn on the DBS system. Find the three digit code for your DBS system at the back of the instructions.
94940 Revised Size 10/18/02 Programming For Cable 1. Manually turn on the Cable Box. Find the three digit code for your Cable Box at the back of the instructions. 2. Press and hold the CODESEARCH button until the INDICATOR LIGHT lights, then release the CODE SEARCH button.
94940 Revised Size 10/18/02 Programming For CD 1. Manually turn on the CD player. Find the three digit code for your CD player you wish to control at the back of the instructions. 2. Press and hold the CODESEARCH button until the INDICATOR LIGHT lights, then release the CODE SEARCH button.
94940 Revised Size 10/18/02 Programming For AUX 1 or AUX 2 Buttons With the AUX 1 and AUX2 buttons, you can assign a second TV, DVD, CD player, VCR, Satellite System, or Cable Box to it. 1. Manually turn on the device you wish to control.
94940 Revised Size 10/18/02 Sleep Function The Sleep Function will turn off your TV automatically after the user programs the time interval from one (1) to ninety-nine (99) minutes. Press and hold the SLEEPbutton. The INDI- CATOR LIGHT will stay lit.
5. When your device turns off, press ENTER, the INDICATOR LIGHT will turn off. Identifying Codes From Your Universal Remote If you need to find the three-digit code for your TV, DVD, VCR, DBS System, Cable Box or CD player after your device is set-up, use this procedure.
94940 Revised Size 10/18/02 3. Press and release CODE SEARCH. The INDICATOR LIGHTwill turn off. 4. Starting with 0 on the keypad, press the number buttons in order (0-9) until the INDICATOR LIGHT blinks. 5. The number which causes the INDICATOR LIGHT to blink is the first digit of your code.
Page 17
94940 Revised Size 10/18/02 Trouble Shooting (con’t.) PROBLEM SOLUTION Problems changing channels If your original remote required ENTER after a channel, press ENTER after you select a channel. No response after pressing a A) Make sure you have new batteries and you are aiming your remote at your device.
Page 18
94940 Revised Size 10/18/02 90 Day Limited Warranty Jasco Products Company warrants this product to be free from manufacturing defects for a period of ninety days from the original date of consumer purchase. This warranty is limited to the repair or replacement of this product only and does not extend to conse- quential or incidental damage to other products that may be used with this unit.
Este Control Remoto Universal ya se encuentra pro- gramado para la mayoría de los televisores, videograbadoras, sistemas DBS, sistemas DVD, y receptores de video o audio de las marcas GE, RCA y ProScan. NOTA: Para los usuarios de productos DBS GE, RCA, o ProScan, los modelos antiguos de DBS requieren que el Botón DISPLAY en este control remoto se utilice...
ON-OFF (ENCENDIDO-APAGADO) El botón ON-OFF opera de la misma manera que su control remoto original. NOTA: Algunos modelos GE, RCAy ProScan requieren que usted presione el botón del aparato para encender el aparato y el botón ON- OFF para apagarlo.
Page 22
94940 Revised Size 10/18/02 12:22 PM Page 22 MENU (MENU/PROGRAMAR) Muestra en la pantalla el Menu Principal. Si usted ya se encuentra en el sistema del menu, presione SELECT para seleccionar la opción resaltada. Utilice los botones con flechas para moverse dentro del Menu. CLEAR (DESPEJAR) Remueve lo que está...
94940 Revised Size 10/18/02 Función Que aprende: Se utiliza la característica que aprende como un suplemento a la biblioteca preprogramada estándar. La biblioteca estándar del código proporciona a la mayoría de las funciones necesi- tadas, pero usted puede agregar un número pequeño de funciones adicionales de su opción.
94940 Revised Size 10/18/02 Borrando un botón aprendido Para ser claro una secuencia del botón aprendido, utiliza el procedimiento abajo. Nota: Ningunas funciones se pueden salvar bajo el APRENDER, el SUEÑO, la BÚSQUEDAdel CÓDIGO (LEARN, SLEEP, CODE SEARCH) o la cualquiera de los botones del dispositivo.
94940 Revised Size 10/18/02 Programación para el televisor La mayor parte de los televisores GE, RCAy ProScan no requerir n ser programados. Verifique para ver si su televisor responde al control remoto antes de comenzar la programación. 1. Manualmente encienda el televisor. Encuentre el código de tres dígitos para su televisor en la parte...
94940 Revised Size 10/18/02 Programación para VCR1 y VCR2 La mayor parte de las videograbadoras GE, RCA y ProScan no requerirán ser programadas. Verifique para ver si su videograbadora responde al control remoto antes de comenzar la programación. Manualmente encienda la videograbadora.
94940 Revised Size 10/18/02 Programación para el sistema DVD La mayor parte de los sistemas DVD GE, RCA y ProScan no requerirán ser programados. Verifique para ver si su sistema DVD responde al control remoto antes de comenzar la programación.
94940 Revised Size 10/18/02 Programación para el Sistema de Satélite DBS La mayor parte de los sistemas de Satélite GE, RCA y ProScan no requerirán ser programados. Verifique para ver si su sistema de Satélite DBS responde al con- trol remoto antes de comenzar la programación.
94940 Revised Size 10/18/02 Programación para Cable Manualmente encienda su rectángulo del cable. Encuentre el código de tres dígitos para su rectángulo del cable en la parte posteriora de las instrucciones. Mantenga presion- ado el botón CODE SEARCH hasta que la LUZ INDICADORAse encienda, entonces suelte el botón CODE...
94940 Revised Size 10/18/02 Programación para CD Manualmente encienda su jugador del CD. Encuentre el código de tres dígitos para su CD en la parte posteriora de las instrucciones. Mantenga presionado el botón CODE SEARCH hasta que la LUZ INDICADORAse encienda, entonces suelte el botón CODE SEARCH.
94940 Revised Size 10/18/02 12:22 PM Page 31 ProgramaciÛn para Botón AUX 1 o AUX 2 Con los botones del AUX 1 o AUX 2 pueden asignar una TV, VCR o sistema de sátelite segunda o caje de cable a la botón "AUX".
94940 Revised Size 10/18/02 Función de apagado automático La función de apagado automático apagará su televi- sor automáticamente después de que el usuario pro- grame un intervalo de tiempo entre uno (1) y noventa y nueve (99) minutos. Mantenga presionado el botón SLEEP.
94940 Revised Size 10/18/02 Programación con B˙squeda de Códigos Si usted necesita encontrar el código de tres dígitos para su televisión, videograbadora, sistema DBS, Caja del Cable o sistema de audio después de que se ha progra - mado su aparato, utilice este pro- cedimiento: Manualmente encienda el aparato que desee programar.
Page 34
94940 Revised Size 10/18/02 Comenzando con el numero 0, presione los botones numéricos en orden (0-9) hasta que la LUZ INDICADORAparpadee. El numero que cause que la LUZ INDICADORA parpadee, es el primer dígi- to en su código. Repita el paso 4 hasta que haya obtenido los tres numeros en el código.
94940 Revised Size 10/18/02 GuÌa de Problemas y Soluciones SOLUCION PROBLEMA A) Reemplace las pilas con La luz roja no parpadea unas alcalinas nuevas AAA. cuando presiona B) Verifique que las pilas cualquier tecla. estén instaladas correcta- mente. A) Trate todos los códigos listados para su marca.
Page 36
94940 Revised Size 10/18/02 SOLUCION PROBLEMA Código no válido para el La luz Indicadora aparato. Verifique la lista Parpadea de códigos y vuelva a pro- gramar el Control Remoto. El telecontrol debe seguir La característica del siendo dirigida al televisión sueño no trabaja después de que elsueño se fije en la orden para que tra-...
