Garmin NavTalk Pilot Specification page 2

NavTalk Pilot
Cellular Specifications
Type: AMPS
Frequency Range: 824.04-848.97 MHz Transmit,
869.04-893.97 MHz
Channel Spacing: 30 kHz
Frequency Stability: +/- 2.5 ppm
RF Output Power: Class III
GPS Performance
Receiver: Differential-ready
12 parallel channel
Acquisition Time: Approx. 15 seconds (warm start)
Approx. 45 seconds (EZinit/cold start)
Approx. 5 minutes (AutoLocate™)
Update Rate: 1/second, continuous
Position Accuracy: 1-5 meters (3-15 ft) with
DGPS corrections
15 meters (49 ft) RMS*
Velocity Accuracy: 0.1 knot RMS steady state
Dynamics: Performs to specification to 6 g' s
Interfaces: NMEA 183, RTCM
(for DGPS corrections) and
RS-232 for PC interface
Antenna: Built-in. Remote external
antenna optional.
Plotter/Moving Map Features
Database: Built-in Jeppesen
worldwide airports and VORs,
plus Americas, or Atlantic
International, or Pacific
International NDBs,
Intersections, special use and
controlled airspace, runway
data, plus airport, FSS, and
ARTCC frequencies
Base Map: Americas or International;
includes: state/country bound-
aries, lakes, rivers, railroads,
cities, coastlines, U.S., state,
and interstate highways, and
local thoroughfares
Plotting Scales: 500 ft to 5000-mile screen width
with push-button zoom control
REV 0799
Navigation Features
Waypoints:
Total:
Nearest:
Routes:
Track Log:
Map Datums:
Coordinates:
Physical
Size:
Weight:
Battery Life:
NiMH Battery: 160 minutes talk time, 12-14**
Water Resistance:
Standard Components
Phone Kit:
Phone
NiMH Battery
Trickle Charger
Power Cable
® ; includes
PC Interface Cable
Quick Reference Guide
User's Manual
Lanyard
Install/Mounting Kit:
Antenna
Interface Module
Mounting Cradle
Interconnect Cables
GA26 Low-profile Antenna
Optional Accessories:
Carrying Case
Desktop Rapid Charger
Vehicular Adapter
Adapter Box
Remote GPS and Cellular Antennas
MapSource ™ CD-ROMs
NAVTALK PILOT
™
250 each with name, symbol and
map display option
9 (automatic) continuously updated
20 reversible routes with up to
30 waypoints each, plus MOB
and TracBack ™ modes
Over 2,000 points
106
Lat/Lon, UTM/UPS, plus 7 grids,
including Maidenhead
2.25" x 7.1" x 1.35"
13.3 oz. with battery & antenna
hours standby (GPS on); 26 hours
standby (cellular only)
Immersion for 30 minutes at
depth of 1 meter
™
NavTalk Cellular Features
•Airborne phone service by AirCell ®
•Audio panel interface
•DTMF Location Reporting with Peer-to-Peer
Display on Map
•Phone Book for 100 Names and Numbers with
Spell and Find
•3 Phone Numbers
•One Button Speed Dial
•Last Number Redial/Store
•Automatic Retry
•Auto Answer with Call-In-Absence Indication
and Time Stamp
•DTMF Numeric Paging
•Signal Strength and Battery Indicators
•Intelligent Security Lock
•Audio, Beep and Ring Volume Adjustments
with Sliding Indicators
•Lifetime and Resettable Call Timers
•Preferred SID Lists
•Call Restrictions
•Minute Reminder Beeps
•Mute Control
Specifications are preliminary and subject to change without notice.
* Subject to accuracy degradation to 100m 2DRMS under
the United States Department of Defense imposed
Selective Availability Program.
** With GPS Power Saver feature enabled.
FCC ID IPH-00228
GARMIN International
1200 East 151st Street
Olathe, Kansas 66062, U.S.A.
913/397.8200 FAX 913/397.8282
GARMIN (Europe) Ltd.
Unit 5, The Quadrangle, Abbey Park Industrial Estate
Romsey, SO51 9AQ, U.K.
44/1794.519944 FAX 44/1794.519222
GARMIN (Asia) Corporation
3rd Floor, No. 1, Lane 45, Pao-Hsing Road
Hsin-Tien, Taipei, Taiwan
886/2.2917.3773 FAX 886/2.2917.1758
www.garmin.com
© 1999 GARMIN Corporation
M 02-10039-00
