Jenn-Air JMD2124W Product Dimensions

Built-In Microwave Oven
PRODUCT MODEL NUMBERS
JMD2124W
ELECTRICAL REQUIREMENTS
A 120-volt, 60 Hz, AC-only, 15 or 20 amp fused electrical supply with a fuse or circuit
breaker is required. It is recommended that a separate circuit serving only this
appliance be provided.
LOCATION REQUIREMENTS
The microwave oven may be located in a cabinet or below the counter, and/or below a
built-in oven. Check the opening where the microwave oven will be installed. The
location must provide:
Wood cabinetry.
Cutout opening that is plumb and square. See "Minimum Cutout Dimensions"
section.
Cutout floor that is solid, level and flush with bottom of cabinet cutout.
Support for weight of at least 100 lbs (45.4 kg), which includes microwave oven and
items placed inside.
Grounded electrical outlet. See "Electrical Requirements" section.
Minimum installation clearances for installation location. See "Minimum Clearances"
section.
Complete enclosure around the recessed portion of the microwave oven.
MINIMUM CUTOUT DIMENSIONS
23 " (59.72 cm)*
28" (71.1 cm)**
22 " (56.2 cm)
14 "
(37.6 cm)
*With flush receptacle.
**With non-flush receptacle.
Width 22
"
Height
14
23 " (59.7 cm) with flush receptacle;
Depth
28" (71.1 cm) with non-flush receptacle
Cutout Top View
A B
A. Flush receptacle located in upper left corner only
B. Non-flush receptacle
C. Microwave oven
D. Anti-tip block located in upper right corner only
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
(59.7 cm)
" (37.6 cm) for all installations
C D
28"
(71.1 cm)
¹⁄₂
23 "
(59.7 cm)
PRODUCT DIMENSIONS
1 " (4.4 cm)
15 "
(39.1 cm)
*Measurements include
front facing of microwave
oven drawer.
MINIMUM CLEARANCES
2"
(5.1 cm)
2"
(5.1 cm)
2"
(5.1 cm)
2"
(5.1 cm)
A. Upper oven B. Lower cabinet C. Counter
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
21 "
(54.9 cm)
" (11.9 cm)
23 "
(60.4 cm)*
The drawer opens
15"
15" (38.1 cm)
A B
19"
(48.3 cm)
C B
(91.4 cm)
19"
(48.3 cm)
14 "
(37.1 cm)
24 "
(62.4 cm)*
(38.1 cm).
36"
Ref. W10306037A
5/25/10
