Garmin GPSMAP 176 Specifications page 2

GPSMAP ® 176 and 176C specifications
Navigation features
Waypoints/icons: 3000 with name, symbol and comments,
as well as proximity support
Routes: 50 reversible routes with up to 254 points
each, plus MOB and TracBack
Tracks: 2500 point automatic track log; 15 saved
tracks; 500 points per saved track; lets
you retrace your path in both directions
Trip computer: Trip odometer, stopped time, moving
average, moving time, total average,
total time, maximum speed, odometer
Alarms: Anchor drag, arrival, off-course,
proximity waypoint, clock,
shallow water and deep water
Tables: Built-in celestial tables for best times
to fish and hunt, sunrise and sunset,
sun and moon by date and position
Map datums: More than 100 plus user datum
Position format: Lat/Lon, UTM/UPS, Maidenhead, MGRS,
Loran TDs and other grids, including
user grid
GPS performance
Receiver: WAAS enabled, 12 parallel channel GPS
receiver continuously tracks and uses up
to 12 satellites to compute and update
your position
Acquisition times:
Warm: Approximately 15 seconds
Cold: Approximately 45 seconds
AutoLocate ™ : Approximately 2 minutes
Update rate: 1/second, continuous
GPS accuracy:
Position: < 15 meters, 95% typical*
Velocity: 0.05 meter/sec steady state
DGPS (USCG) accuracy:
Position: 3-5 meters, 95% typical
Velocity: 0.05 meter/sec steady state
DGPS (WAAS) accuracy:
Position: < 3 meters, 95% typical
Velocity: 0.05 meter/sec steady state
Dynamics: 6 g's
Interfaces: RS232 with NMEA 0183, RTCM 104 DGPS
data format and proprietary GARMIN
Antenna: Removable quad-helix
GPSMAP 176
0501
Differential:
Moving map features
Basemap:
® modes
Uploadable maps:
Power
Source:
Battery life:
Physical
Size:
Weight:
Display:
(GPSMAP 176)
(GPSMAP 176C)
Case:
Temperature range:
User data storage:
Accessories
Standard:
Optional:
GPSMAP 176C
GPSMAP
USCG and WAAS capable
Detailed Americas basemap with cities,
highways, interstates, exit info, rivers, lakes
and U.S. tide data
Accepts optional data cards for
detailed maps, including GARMIN
BlueChart ™ marine cartography
Four "AA" batteries (not included)
4 to 16 hours based on backlight setting
6.18"W x 3.4"H x 2.25"D
(15.7 x 8.64 x 5.72 cm)
1.5 lbs (680 g) with batteries
3.8" diagonal (9.65 cm) 320 x 240 pixels,
12-level gray high contrast FSTN with
backlighting
3.8" diagonal (9.65 cm) 320 x 240 pixels,
16-color transflective display with
backlighting
Fully gasketed, high impact plastic alloy,
waterproof to IEC 529 IPX7 standards
5ºF to 158ºF (-15ºC to 70ºC)
Indefinite, no memory battery required
PC interface cable
Power/data cable
Marine mount
Owner's manual
Quick reference guide
Automotive mounting adapter
Beanbag mount
Remote antennas
Deluxe carrying case
12-volt adapter cable
Preprogrammed data cards with
BlueChart ™ marine cartography
MapSource ™ CD-ROMs
8, 16, 32, 64 and 128 MB data cards
USB data card programmer
PC interface cable with 12-volt adapter
M01-10112-00
® 176 and 176C
Pointer page provides steering guidance
as you navigate and displays your speed,
distance to destination and more.
The GPSMAP 176 and GPSMAP 176C
feature built-in tide data for the U.S.A.
GARMIN's optional BlueChart ™ marine
cartography includes navaids, depth
contours and more.
©2001 GARMIN Corporation
GARMIN International
1200 East 151st Street
Olathe, Kansas 66062, U.S.A.
913/397.8200 fax 913/397.8282
GARMIN (Europe) Ltd.
Unit 5, The Quadrangle
Abbey Park Industrial Estate
Romsey, SO51 9AQ, U.K.
44/1794.519944 fax 44/1794.519222
GARMIN (Asia) Corporation
No. 68, Jangshu 2nd Rd.
Shijr, Taipei County, Taiwan
886/2.2642.9199 fax 886/2.2642.9099
www.garmin.com
Specifications are preliminary and subject to change
without notice.
* Subject to accuracy degradation to 100m
2DRMS under the U.S. Department of Defense
imposed Selective Availability Program.
