chapter 2
Fast Track C400 Hardware Overview

Fast Track C400 Top Panel Features

Figure 1 identifies the controls, indicators on the Fast Track C400 top panel.
Input Meters
Gain
Pad
Input Selector
Figure 1. Fast Track C400 top panel
The Fast Track C400 top panel provides the fol-
lowing:
Front/Rear Input Selectors
These buttons select either the front panel In-
strument Inputs (TS) or rear panel Mic/Line In-
puts (XLR/TRS combo) for each channel.
48V
Power LED
When these buttons are set to the "In" position,
the corresponding front panel Instrument Input
is active. When they are set to the "Out" posi-
tion, the corresponding rear panel Mic/Line In-
put will be active.
Headphone
Volume
Chapter 2: Fast Track C400 Hardware Overview
Output Selector
Volume Knob
Multi Button
3
