Weed Eater TurboClean 2000 Parts List

Parts List No.
966782401_IPL
NEW
Date
9/06/11
= New Part Number For This IPL
NOTE : Illustration may differ from actual model due to design changes.
2
3 4
6
5
7
Ref. Part No.
1. 966782401s
2. 579177601
3. 579177501
4. 579177401
5. 579177901
6. 579178001
7. 579178101
8. 579177701
9. 579220701
10. 579177801
115431827
579178201
579178301
®

PARTS LIST

1
Description
Replacement Unit
Handle Assist / Vac Door
Nut - Hinge
Screw - Hinge
Kit - Vac Tube (Incl. 6,7)
Tube - Upper Vac
Tube - Lower Vac
Tube - Blower
Nozzle - Concentrator
Assy. - Vac Bag
Not Shown
Manual
Strap - Shoulder
Decal - Warning
= Refer to the Service Reference Indicated for more information.(Located at the END of the IPL)
TurboClean 2000
Page:
WARNING
All repairs, adjustments and
maintenance not described in
the Operator's Manual must be
performed by Qualified Service
Personnel.
8
9
10
MODEL
1
