Installation Tips To Maximize The Built-In Look; Rough-In Dimensions And Installation Information - GE Profile PCF25MGW Datasheet

PCF25MGW
GEProfile Counter-Depth
™
Rough-In Dimensions and Installation Information (in inches)

Installation Tips to Maximize the Built-In Look

• A llwall/floormoldingshouldberemovedpriortoinstallation.
• W aterrecessonrearwallrecommendedtopreventwater
 linedamage.48"minimumlength,1/4"diameterwater
 linetubingrecommended.
• W henpossible,recessbothcopperwaterlineandelectrical
 outlet.(Seelocalcodes)
• F rontandrearlevelinglegsareadjustableforthebuilt-inlook.
 (Seeowner'smanual)
**Therough-indimensionsof70-1/4"/72-1/4"areminimumand
 measuredfromthefinishedfloortotopofopening(orthe
 undersideoftheoverheadcabinets).ForModelswithTrimKit:
 Ifframelessstylecabinetsareplannedforabovetherefrigerator,
 youmayneedtoconsideraddingamaximumof1/4"(70-1/2")
 toheightofopeningfor23cu.ft.modelsand1/8"(72-3/8")for
 25cu.ft.modelstoallowforadditionalclearancebetweenthe
 cabinetdoorsandthetopofrefrigeratortrimwhenthecabinet
 doorsareinopenposition.
ForanswerstoyourMonogram, GEProfile
®
GE ® appliancequestions,visitourwebsiteat
ge.comorcallGEAnswerCenter service,
®
800.626.2000.
ENERGYSTAR 24.6Cu.Ft.Side-By-SideRefrigerator
 ®
24"
Cabinet
or
™
FOR 24 CUBIC FOOT MODELS
Water Electrical
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
25"
Counter
Top
Fig 2A eps
Water
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
Listed by
Underwriters
Laboratories
Specification Created 2/07
Electrical
25"
Counter
Top
Trim
210239
