- Page 1 PEDAL POWER MONDO User’s Manual www.voodoolab.com...
- Page 2 Copyright ©2012-2018 by Digital Music Corporation. This publication is protected by copyright and all rights are reserved. Voodoo Lab and Pedal Power are registered trademarks of Digital Music Corp. rev 1.1 - 8/2018...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Unpacking Connections DIP Switches DC Power Cables Strymon Boss Line 6 TC Electronic Eventide . Additional Cables About Isolation Specifications . Warranty . How to Reach Us... -
Page 4: Introduction
Introduction Pedal Power MONDO is a high-current capable supply that can power the largest and most diverse pedalboards. With twelve independent, filtered and regulated output sections, Pedal Power MONDO can properly power modern DSP-based effects and all 9V battery operated pedals and accessories. -
Page 5: Unpacking
3.5mm right angle mini plug (1) 9V battery snap (1) Connections Pedal Power MONDO is powered directly from mains using the supplied AC line cord. This is a standard computer-type IEC line cord, so it’s easy to obtain a replacement or different length. - Page 6 All 9V outputs can also power ordinary low-current battery operated pedals. (3) 9V and 12V high-current output pairs. Each pair is an isolated output section providing up to 400mA. Note: The 9V and 12V outputs within a pair are not isolated from each other. It is preferred to use only one from each pair.
-
Page 7: Dip Switches
DIP Switches On the bottom of MONDO is an 8 position DIP switch numbered 1-8. These switches correspond to outputs labeled 1-8 and select the output voltage. The switches should be in the OFF position for standard 9V operation. Setting a switch to ON enables the alternate voltage. -
Page 8: Strymon
“center positive” are the Fulltone ‘69, SoulBender, and Octafuzz pedals and Moogerfoogers. Reverse polarity cables are available from Voodoo Lab to properly power these pedals. Strymon All Strymon pedals (including the larger format Timeline) can be powered from any of the high-current 400mA 9V outputs using a standard black 5.5x2.1mm... -
Page 9: Tc Electronic
Line 6 adapter, but does correctly power these pedals. Note that PODxt & HD, M9, M13 and the JM4 Looper cannot be directly powered by Pedal Power MONDO. However, you can power the Line 6 supplied adapter with MONDO's courtesy AC outlet. -
Page 10: Additional Cables
Additional Cables The DC power cables supplied with your Pedal Power MONDO are suitable for most common pedal effects. If you need additional cables, different lengths, reversed polarity, or a special connector, these are available from Voodoo Lab at our online store and most Voodoo Lab retailers. -
Page 11: About Isolation
24V. Occasionally, a pedal requires a bipolar supply, using two batteries for +9V and -9V. Isolated outputs work fine for this, non-isolated supplies do not. Voodoo Lab has been the pioneer of isolated power supplies for guitar pedal effects since 1996. - 9 -... -
Page 12: Specifications
Specifications Input: Standard IEC connector 120V 60Hz (North America model) 100V 50/60Hz (Japan model) 220-240V 50Hz (Europe/Australia model) Model and input power are marked on bottom of unit. Outputs: 5.5x2.1mm barrel connectors center negative Linear regulation Short circuit protected Two 9VDC + 12VDC (400mA) Two 9VDC (400mA) Two selectable 9VDC (250mA) or 12VDC (200mA) Four selectable 9VDC (100mA) or 12VDC (60mA) -
Page 13: Warranty
Should you experience any difficulty with this Voodoo Lab product, contact us as described below. If it is determined that the product must be returned to the factory for repair, you will be issued an RMA and given shipping and packaging instructions.
