- Page 1 Gebrauchs- und Montageanleitung Instructions for installation and use Wichtig: Unbedingt lesen und aufbewahren! Important: Read these instructions carefully and then store them in a safe place Integrierte Kühl-Gefriergerät Integrated Fridge -Freezers Modell: KG 122 2223 246-21...
-
Page 2: General Safety
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Environment Protection
• Do not place carbonated or fizzy drinks in the is advisable to wait at least two hours before freezer as it creates pressure on the container, connecting the appliance to allow tl¦e oil to flow which may cause it to explode, resulting in back in the compressor. -
Page 4: Temperature Regulation
Temperature regulation Storage of frozen food The temperature is automatically regulated and can When first starting-up or after a period out of use, be increased to achieve a higher temperature before putting the products in the compartment let (warmer) by rotating the thermostat knob toward the appliance run for at least two hours on the lower settings or reduced (colder) rotating the knob coldest setting, then turn the thermostat knob to the... -
Page 5: Movable Shelves
Movable shelves The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired. Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be placed at different heights. To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows until it comes free, then reposition as required. -
Page 6: Maintenance
Freezing Calendar The symbols show different types of frozen goods. The numbers indicate storage times in months for the appropriate types of frozen goods. Whether the upper or lower value of the indicated storage time is valid depends on the quality of the foods and pre- treating before freezing. -
Page 7: Customer Service And Spare Parts
It is important to periodically clean the defrost water drain hole in the middle of the refrigerator compartment channel to prevent the water overflowing and dripping onto the food inside. Use the special cleaner provided, which you will find already inserted into the drain hole. The freezer compartment, however, will become progressively covered with frost. -
Page 8: Door Reversibility
The Manufacturer declines all responsibility if ATTENTION! the above safety precautions are not observed. It must be possible to disconnect the appliance from This appliance complies with the following the mains power supply; the plug must therefore be E.E.C. Directives: easily accessible after installation. - Page 9 It is necessary that the niche is provided with a conduct of ventilation having the following dimensions: Depth 50 mm Width 540 mm Fit the appliance in the niche by making sure that it stands against the interior surface of the unit on the side where the door hinges of the appliances are fitted.
- Page 10 Separate parts Ha, Hb, Hc, Hd as shown in the figure. Place guide (Ha) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes. After having drilled holes, fix the guide with the screws supplied.
- Page 11 Place the small square on the guide again and fix it with the screws supplied. Should the lining up of the furniture door be necessary, use the clearance of slots. At the end of operations, it is necessary to check if the door of the furniture closes properly.
