Summary of Contents for Pharos iGPS-BT

  • Page 1 User Manual...
  • Page 2 • Consult the dealer or an experienced radio/television technician for help. FCC ID# Q7M-IGPS-BT CE Notices This device has been tested and found to comply with CE marking according to the R&TTE Directive, 99/5/EEC. The test standards are listed below:...

  • Page 3: On/Off Switch

    2-3 hours before initial use. On/Off Switch Turns the iGPS-BT on or off. Blue LED’s will light up when powered. Bluetooth Status Indicator (Internal Blue LED) Blinking: Searching for Bluetooth signal Steady: Bluetooth communication established, ready to use.
  • Page 4 II. iGPS-BT Setup (see walkthrough guides at the end of this section) 1. The iGPS-BT will need to be charged for two to three hours before initial use. 2. Turn on the iGPS-BT. The status indicator will blink as it searches for a Bluetooth connection.
  • Page 5 Setup for Pocket PCs with built-in Bluetooth Technology running the Windows Mobile Pocket PC OS Steps 1 – 10: How to Pair the iGPS-BT with your Pocket PC’s Bluetooth Manager Steps 11 – 15: Establishing a Bluetooth Connection using Ostia 1.
  • Page 6 5. Provided that your iGPS-BT is turned 12345678 6. Enter the Passkey: , and on and fully charged, it will be discovered. select “OK” in the upper right-hand Tap on the “Pharos iGPS-BT” icon to corner select it 7. Select “GPS RFcom” so that it 8.
  • Page 7 9.Tap and hold on the “Pharos iGPS- 10. Once the GPS has a connection, the BT: GPS RFcom” icon, select icon will change to Green. You will also “Connect” from the Menu that appears notice that the Blue light on the GPS itself is now a solid, steady Blue.
  • Page 8 13. Now that the COM Port is setup, you 14. Select “YES” to Enable the GPS can Enable the GPS by tapping on the RED Smiley face For Bluetooth setup on other devices, please visit: www.pharosgps.com walkthrough guides under the Support section.

  • Page 9: Battery Charging Instructions

    III. Battery charging instructions The Pharos Bluetooth Dock (BT Dock) for the GPS receiver includes a rechargeable and replaceable Li-Polymer battery. The optional Power Accessory Kit (PXT02), which contains a spare battery, battery charging holder, and an AC battery charger can be purchased from Pharos.
  • Page 10 2. Charging both battery and PDA at the home simultaneously Plug the DC plug (black) from the DC charging adapter into the DC jack on the BT Dock (or the battery charging holder with the battery loaded – PXT02) then make sure the PDA AC charger is plugged into the AC wall outlet and is connected to the DC charging adapter.
  • Page 12 Battery Precautions (w: WARNING!) Reverse charging is not acceptable. Charge before use. The cells/batteries are delivered in an uncharged state. Do not charge/discharge with more than our specified current (400mA). Do not short circuit the cell/battery, permanent damage to the cell/battery may result.
  • Page 13 IV. iGPS-BT GPS Receiver Specifications Performance Chipset SiRF StarIIe/LP Antenna Integrated patch antenna Frequency L1, 1575.42 MHz Sensitivity -140 dBm (typical) Channels 12 Channel all-in-view tracking Acquisition time (Avg.) Cold Start: 60 sec Warm Start: 40 sec Hot Start: 5 sec Reacquisition 0.1 sec...
  • Page 14 • GPS satellites are under the control of the U.S. Department of Defense. Therefore, services provided for general consumers are subject to change without prior notice. Pharos is not liable for losses caused by such changes. • Do not touch the connectors of the Bluetooth Dock with fingers or insert foreign substances;...
  • Page 15 VII. Quick Start Guide for Ostia Navigation Software(for PT200/PT300) 1. Install the Pharos Ostia & MapFinder Software • Insert the CD-ROM. If Auto-Run is enabled for your CD-ROM, the Setup program will run automatically. If not, run the Setup program on the CD- ROM.

  • Page 16: Additional Tips

    Create a Route Using the Pharos Pocket GPS Navigator Start in a safe area with a clear view of the open sky (GPS does not work well indoors), then proceed with the following steps: • On the PDA, start running the Pharos Ostia program.

  • Page 17: Warranty

    IX. Warranty The iGPS-BT Receiver is warranted by Pharos to the original purchaser to be free from defects in material workmanship under normal use for a period of one year from the date of purchase (three months for the battery). During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with the same or a similar model) at Pharos' option without charge for parts or labor.
