Summary of Contents for Pharos iGPS-BT II
- Page 1 II User Manual...
- Page 2 FCC Notices This device complies with Part 15(b and c) of the FCC Rules. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation.
- Page 3 II will need to be charged for approximately 3 hours before initial use. On/Off Switch Turns the iGPS-BT II on or off. Blue LED’s will light up when powered. Bluetooth Status Indicator (Internal Blue LED) Blinking: Searching for Bluetooth signal.
- Page 4 II. iGPS-BT II Setup (see walkthrough guides at the end of this section) 1. The iGPS-BT II will need to be charged for two to three hours before initial use. 2. Turn on the iGPS-BT II. The status indicator will blink as it searches for a Bluetooth connection.
- Page 5 “Pharos II” on your Pocket PC.) Steps 1 – 10: How to Pair the iGPS-BT II with your Pocket PC’s Bluetooth Manager Steps 11 – 15: Establishing a Bluetooth Connection using Ostia 1. Make sure that the iGPS-BT II is turned on (the blue light will be flashing).
- Page 6 5. Provided that your iGPS-BT II is turned on and fully charged, it will be discovered. Tap on the “Pharos iGPS-BT” icon to select it 7. Select “GPS RFcom” so that it becomes highlighted, and tap on “Next” 12345678 6. Enter the Passkey: select “OK”...
- Page 7 9.Tap and hold on the “Pharos iGPS- BT: GPS RFcom” icon, select “Connect” from the Menu that appears 11. Open Pharos Ostia on your Pocket PC, click through the Warning screens, and tap on “Tools”, “Options”… 10. Once the GPS has a connection, the icon will change to Green.
- Page 8 13. Now that the COM Port is setup, you 14. Select “YES” to Enable the GPS can Enable the GPS by tapping on the RED Smiley face Bluetooth setup for Windows Mobile 5.0 OS...
- Page 9 2. iGPS-BT II Setup for Pocket PCs with built-in Bluetooth Technology running the Windows Mobile 5.0 OS (the following screen shots show the device as “Pharos iGPS-BT”, it might be shown as on your Pocket PC.) 2. Click the small Bluetooth icon the bottom right-hand side of the screen.
- Page 10 6. Enter the passkey: 12345678 8. Next select the “COM Ports” tab at the bottom of the screen. Then select “New Outgoing Port” 7. Put a check mark in the box next to “serial port” and tap Finish 9. Select the “Pharos iGPS-BT” and tap, Next.
- Page 11 10. Select Com 7, and make sure that there is a check in the “Secure Connection” box and tap Finish. 12. When Ostia is opened, tap Go > Menu > Options > Select Comm Port > Change > Com7 > OK > Done 11.
-
Page 12: Battery Charging Instructions
III. Battery charging instructions The Pharos Bluetooth Dock (BT Dock II) for the GPS receiver includes a rechargeable and replaceable Li-Ion battery. A car charger is included for you to charge the battery in the car (shown in fig. A). You can also charge the battery via your notebook computer by the USB charging cable (shown in fig. - Page 13 Battery Precautions (w: WARNING!) Reverse charging is not acceptable. Charge before use. The cells/batteries are delivered in an uncharged state. Do not charge/discharge with more than our specified current (400mA). Do not short circuit the cell/battery, permanent damage to the cell/battery may result.
- Page 14 II GPS Receiver Specifications Performance Chipset Antenna Frequency Sensitivity Channels Acquisition time Reacquisition Position update Accuracy Electrical Power Battery Battery charger Operation time Interface Connection Protocol Data rate NMEA message WAAS/EGNOS Trickle power Bluetooth spec Physical Dimension Weight Environmental...
- Page 15 Package contents PT250: Bluetooth Pharos GPS Navigator Ostia software and street level maps iGPS-500 receiver iGPS-BT II Dock with Li-Ion battery Car charger Vent mounted PDA Holder PT120: Bluetooth iGPS Receiver iGPS-500 receiver iGPS-BT II Dock with Li-Ion battery Car charger Note: Contents may vary - see the box or contents list.
-
Page 16: Troubleshooting
Questions section at www.pharosgps.com. Warranty The iGPS-BT II Receiver is warranted by Pharos to the original purchaser to be free from defects in material workmanship under normal use for a period of one year from the date of purchase (three months for the battery). During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with the same or a similar model) at Pharos' option without charge for parts or labor.
