The model number will be found on a plate attached to frame. Always mention the model number in all correspondence
regarding your PRESSURE WASHER or when ordering replacement parts.
KEY P/N
DESCRIPTION
1 678774002
Lock Nut (M8 x 1-1/4 in.) ........... 7
2 310742004
Front Frame (Inc. Key. Nos. 3,
8, 39, and 50) ............................. 1
3 661501007
Screw (1/4-20 x 2 in.) ................. 6
4 638671004
Detergent Tank Cover ................ 1
5 941532001
Logo Label (Homelite) ................ 1
6 580875010
Detergent Tank........................... 1
7 660962001
Bolt (M8 x 55 mm) ..................... 4
8 638128004
Washer (1/4 in.) .......................... 5
9 308451019
Wheel ......................................... 2
10 620599007
Axle ............................................ 2
11 310704005
Main Frame Assembly (Right,
Inc. Key Nos. 14, 16,
and 51-53) ................................. 1
12 678899001
Spring pin .................................. 2
13 310703005
Main Frame Assembly (Left) ...... 1
14 308910005
Handle Release Knob ................ 1
15 678406010
Bolt (1/4-20 x 3.5 in.) ................. 2
16 678610002
Flange Nut (M4 x 0.7) ................ 1
17 518724002
Spacer ....................................... 2
18 570410003
Cap ............................................ 2
19 678041007
Output Shaft Key ....................... 1
20 NOTE A
Engine (Honda 190cc) ............... 1
21 940680027
Hot Surface Label ...................... 1
22 940654089
Trigger Handle Warning Label ... 1
23 660592006
Screw (1/4-20 x 2.27 in.) ............ 1
NOTE A: Homelite Consumer Products, will not provide engines as replacement parts. Engines are covered through the engine manufacturer's warranty. Consult the
accompanying engine manual or contact our service department for assistance.
HOMELITE PRESSURE WASHER − MODEL NO. UT80432A
FIGURE A PARTS LIST
QTY
KEY P/N
DESCRIPTION
24 940779064
Performance Label .................... 1
25 660592005
Screw (1/4-20 x 1.65 in.) ............ 1
26 570718001
Bungee Cord Assembly ............. 1
27 310673013
Hose Storage ............................. 1
28 308638032
Handle Assembly ....................... 1
29 518929002
Trigger Handle Holder ................ 1
30 940654083
Trigger Handle Warning Label ... 1
31 940705088
Logo Label ................................. 1
32 308760028
Trigger Handle Assembly ........... 1
33 308494003
Spray Wand ............................... 1
34 940872001
E85 Label ................................... 1
35 940894004
Danger Label ............................. 1
36 940617097
Engine Control Label ................. 1
37 661501001
Bolt (1/4-20 x 1.85 in.) ............... 1
38 518931004
Spray Wand Holder ................... 1
39 678016006
Lock Nut (1/4-20) ..................... 11
40 308653035
Pump (Incl. Key Nos. 63-66) ...... 1
41 660962003
Bolt (M8 x 60 mm) ..................... 3
42 678169004
Thermal Release Valve .............. 1
43 638662021
Engine Plate ............................... 1
44 940786020
Trigger Handle Spec Label ........ 1
45 308835036
High Pressure Hose (25 ft.) ........ 1
46 310448004
5-in-1 Change Over Nozzle ....... 1
47 941505001
Release Water Label .................. 1
48 310650004
Cap ............................................ 1
* Standard Hardware Item – May Be Purchased Locally
QTY
KEY P/N
49 570728007
50 561307005
51 661555001
52 678600002
53 570712001
54 940473002
55 940836012
56 940617096
57 940947003
58 940803018
59 940778002
60 940517007
61 940871002
62 940324014
63 308862001
64 308861003
65 308862003
66 308452002
67 678518002
68 638275002
3
DESCRIPTION
Injection Hose ............................ 1
Rubber Foot ............................... 1
Bolt (M4 x 12 mm) ..................... 1
Washer (M4) ............................... 1
Rubber Bumper ......................... 1
Warning Hang Tag ..................... 1
Data Label ................................. 1
Pump Quick Start Label ............ 1
Combustion Warning Label ....... 1
EMC Label ................................. 1
Hot Surface Label ...................... 1
Lubricant Label .......................... 1
Oil Dipstick Label ....................... 1
Inquiries Label ........................... 1
Filter Screen ............................... 1
Inlet Tube ................................... 1
Outlet Tube ................................ 1
Detergent Suction Kit ................ 1
Lock Nut (1/2-20) ....................... 1
Washer (1/2 in.) .......................... 2
Not Shown:
*
Oil (SAE 10W30, 18 oz) .............. 1
988000732
Operator's Manual ..................... 1
120900147
Pump Protector (4 oz.) ............... 1
987823001
Pump Protector (12 oz.) ............. 1
