- Page 1 EM-412 2-Slot 10GBase-CX4 10Gigabit Module User’s Guide Version 1.00 8/2008 Edition 1 Copyright © 2008. All rights reserved...
- Page 2 EM-412 User’s Guide Overview The EM-412 is an uplink module with two slots for 10GBase- CX4. It works up to a distance of 15 meters (49 feet) with the advantage of having the lowest cost per port of all 10Gb interconnects.
-
Page 3: Hardware Installation
EM-412 User’s Guide 1 Hardware Installation Follow these steps to install the EM-412 in a switch. Modules are NOT hot swappable! 1 Turn off your switch and unplug all power supply cords (including any backup power supply cords) from the switch. - Page 4 EM-412 User’s Guide 4 Insert the EM-412 into an available expansion slot on the switch. Press it firmly until the EM-412 snaps into place. Never force, bend or twist the EM-412s into the expansion slots. 5 Secure it to the switch with the retaining screws.
- Page 5 EM-412 User’s Guide 2 Cable Connectivity Use the correct 10GBase-CX4 cable with the correct PIN assignment. The following table lists the components on the main board. Pin Number Signal Name Pin Number Signal Name RX+0 TX-3 RX-0 TX+3 RX+1 TX-2 RX-1 TX+2 RX+2...
- Page 6 EM-412 User’s Guide The EM-412 uses a high-speed 10GBase-CX4 cable as pictured below. The image on the left gives a full view of the cable. On the right is a close up of the CX4 connector. Use the following steps to attach the 10GBase-CX4 cable. 1 Inject the cable firmly into the 10GBase-CX4 slot until it clicks into place.
-
Page 7: Troubleshooting
EM-412 User’s Guide 3 LEDs The following table describes the LEDs on the EM-412 panel. Color Status Description LNK/ Blue The port is connected to an Ethernet device. Blinking The port is transmitting or receiving data. The port is not connected to an Ethernet device. -
Page 8: Specifications
EM-412 User’s Guide 5 Specifications Specifications are accurate at the time of writing. Feature Specification Dimensions (mm) 80 (Wide) x 168 (Deep) x 28 (High) mm Weight 152.4 g Operating Temperature: 0º C ~ 45º C Environment Humidity: 10% ~ 90% RH Storage Temperature: -10º... -
Page 9: Related Documentation
EM-412 User’s Guide over them. Do NOT allow anything to rest on the power cord and do NOT locate the product where anyone can walk on the power cord. • Do NOT install nor use your device during a thunderstorm. There may be a remote risk of electric shock from lightning. -
Page 10: Customer Support
• Sales E-mail: sales@zyxel.com.tw • Telephone: +886-3-578-3942 • Fax: +886-3-578-2439 • Web: www.zyxel.com • Regular Mail: ZyXEL Communications Corp., 6 Innovation Road II, Science Park, Hsinchu 300, Taiwan China - ZyXEL Communications (Beijing) Corp. • Support E-mail: cso.zycn@zyxel.cn • Sales E-mail: sales@zyxel.cn •... - Page 11 Czech Republic • E-mail: info@cz.zyxel.com • Telephone: +420-241-091-350 • Fax: +420-241-091-359 • Web: www.zyxel.cz • Regular Mail: ZyXEL Communications, Czech s.r.o., Modranská 621, 143 01 Praha 4 - Modrany, Ceská Republika Denmark • Support E-mail: support@zyxel.dk • Sales E-mail: sales@zyxel.dk •...
- Page 12 EM-412 User’s Guide • Sales E-mail: sales@zyxel.fi • Telephone: +358-9-4780-8411 • Fax: +358-9-4780-8448 • Web: www.zyxel.fi • Regular Mail: ZyXEL Communications Oy, Malminkaari 10, 00700 Helsinki, Finland France • E-mail: info@zyxel.fr • Telephone: +33-4-72-52-97-97 • Fax: +33-4-72-52-19-20 • Web: www.zyxel.fr •...
- Page 13 • Support Telephone: +1-800-978-7222 • Sales E-mail: sales@zyxel.com • Sales Telephone: +1-714-632-0882 • Fax: +1-714-632-0858 • Web: www.zyxel.com • Regular Mail: ZyXEL Communications Inc., 1130 N. Miller St., Anaheim, CA 92806-2001, U.S.A. Norway • Support E-mail: support@zyxel.no • Sales E-mail: sales@zyxel.no...
- Page 14 EM-412 User’s Guide • Fax: +47-22-80-61-81 • Web: www.zyxel.no • Regular Mail: ZyXEL Communications A/S, Nils Hansens vei 13, 0667 Oslo, Norway Poland • E-mail: info@pl.zyxel.com • Telephone: +48-22-333 8250 • Fax: +48-22-333 8251 • Web: www.pl.zyxel.com • Regular Mail: ZyXEL Communications, ul. Okrzei 1A, 03-715 Warszawa,...
- Page 15 • Support E-mail: support@zyxel.se • Sales E-mail: sales@zyxel.se • Telephone: +46-31-744-7700 • Fax: +46-31-744-7701 • Web: www.zyxel.se • Regular Mail: ZyXEL Communications A/S, Sjöporten 4, 41764 Göteborg, Sweden Taiwan • Support E-mail: support@zyxel.com.tw • Sales E-mail: sales@zyxel.com.tw • Telephone: +886-2-27399889 •...
-
Page 16: User Guide Feedback
• Telephone: +44-1344-303044, 0845 122 0301 (UK only) • Fax: +44-1344-303034 • Web: www.zyxel.co.uk • Regular Mail: ZyXEL Communications UK Ltd., 11 The Courtyard, Eastern Road, Bracknell, Berkshire RG12 2XB, United Kingdom (UK) User Guide Feedback Help us help you. E-mail all User Guide-related comments, questions or suggestions for improvement to techwriters@zyxel.com.tw or send regular mail... - Page 17 ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved.
- Page 18 EM-412 User’s Guide Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patent rights of others. ZyXEL further reserves the right to make changes in any products described herein without notice.
