C L A R K S Y N T H E S I S TACTILE SOUND ® Installation Guide • TST429-Platinum Transducer • TST329-Gold Transducer • TST239-Silver Transducer • AW339-All Weather Transducer For accessories and other helpful information, visit our web site www.clarksynthesis.com... -
Page 2: Important Product Information
IMPORTANT PRODUCT INFORMATION DO NOT DROP THE TRANSDUCER- The Transducer can be damaged both internally and externally if dropped. Damage caused by dropping the Transducer is not covered under the warranty. DO NOT EXPOSE THE TRANSDUCER TO HIGH DISTORTION LEVELS- Exposing the Transducer to high levels of distortion may damage the unit. -
Page 3: Introduction
Then plan out the steps you’ll need to take for your particular application. This will save you time in the end and reduce the possibility of errors and/or damage to the Transducer. Thank you for purchasing a Clark Synthesis Tactile Some of the most common applications for Tactile Sound ®... -
Page 4: Supplied Parts
Supplied Parts SUPPLIED PARTS (ILLUSTRATED BELOW) REQUIRED TOOLS AND MATERIALS A. (1) TST209 Transducer Depending on your application, you will need B. (1) Unimount Bracket some or all of these tools and materials for your C. (1) 3/8”-16 x 3” Hanger Bolt installation: D. -
Page 5: General Information
Transducer mounted inside platform or riser Transducer mounted beneath floor NOTE: The TST329 and AW339 Transducers are designed to be mounted in any orientation. The TST239 and TST429 transducers are designed to be mounted in a horizontal orientation ONLY. Correct for all... -
Page 6: Installation: Overview
Installation: Overview Installation Type: Unimount Bracket Installation Type: Hanger Bolt Screws into the bottom of the mounting surface. Screws into the bottom of the mounting surface (into a Requires access only to the bottom of the mounting 5/16” drilled hole. Requires access only to the bottom surface. - Page 7 Installation: Overview Installation Type: T-Nut Installation Type: Hex Bolt Requires initial access to the top of the material to For use with metal or other high-tensile mounting insert the T-Nut, which installs flush to the surface. surfaces no thicker than 1/4”. Requires access to the (Drill a 7/16”...
-
Page 8: Installation: Chairs And Couches
Installation: Chairs & Couches As a general rule, most chairs and couches have an underlying wooden frame. The Transducer can be mounted directly to a frame member or to a hardwood bridge that is rigidly secured to chair or couch’s bottom frame. - Page 9 Recommendation: Clark Synthesis recommends using only 6” Jam Nut TST429 Platinum Transducers for platforms. Use of (1) TST429 Platinum Transducer for every 4 ft. by 8 ft. area of the platform is suggested. Platforms are a great alternative to mounting a Transducer directly to a chair.
- Page 10 Installation: Laminated I-Beam Floors Laminated I-Beam Joists The Transducer mounts on 1"x 6" hardwood bridge spanning two joists, using the Unimount Bracket (shown) or the threaded stud with T-Nut. Attach the bridge to the bottom face of the joists using adhesive and screws.
- Page 11 Notes www.clarksynthesis.com Tactile Sound Transducers...
-
Page 12: Installation: Wood Decks
Installation: Wood Decks Measure the overall dimensions of the deck. For best results, it is recommended that one (1) AW339 be installed for every 10 ft. by 10 ft. (3 m by 3 m) section of deck. For example, if you have a deck that is 10 ft. - Page 13 Installation: Wood Decks If you are using the joist mount, determine the general mounting location and then find the closest joist support for that location. Drill a 5/16” (.79 cm) pilot hole that is approximately 2 inches (5 cm) deep into the joist. Place two (2) Jam Nuts on the Hanger Bolt and tighten the nuts together (see the joist style diagram on the previous page).
-
Page 14: Wiring And Connections
Wiring & Connections HOME THEATER There are several different ways to hook up your system in terms of which source material (signal) is delivered to the amplifier(s) and Transducer(s). Since our inception, we have discovered that approximately half of our customers prefer using the LFE/SUB signal with their Transducers. The other half prefer using the Right Front (RF) and Left Front (LF) signals. Additionally, there are a few people who like to use multiple signals concurrently. - Page 15 Wiring & Connections Right Front (RF) and Left Front (LF) Hookup For this hookup, connect the RF and LF Pre-Amp Outputs to the amplifier inputs. NOTE: Not all receivers have Pre-Amp outputs for the Right Front and Left Front outputs. If you have a question about your receiver’s outputs, please consult your owner’s manual or contact your receiver’s manufacturer.
- Page 16 Wiring & Connections Two Transducers with a Stereo Amplifier Amplifier Input (100 - 150 Audio Input Signal Watts per Channel into Output 4 ohms) – – Transducer Transducer Two Transducers with a Mono Amplifier Amplifier Audio Input Signal (120 - 150 Watts into OUT IN 8 ohms)
- Page 17 Notes www.clarksynthesis.com Tactile Sound Transducers...
-
Page 18: Troubleshooting
Troubleshooting Symptom Troubleshooting Question Remedy No Tactile Sound Is the Transducer connected? Connect the Transducer properly. Is the input source connected to the Connect the input source. amplifier input? Is the source outputting a signal? Connect the source to another amplifier to verify the source is working. Is the Gain (Volume) Control turned up? Slowly turn up the Gain (Volume) Control. -
Page 19: Warranty And Returns
United States Warranty and Return Policy TST429, TST329, TST239, AW339 Transducer WARRANTY Clark Synthesis, Inc. warranties the TST239, TST329, TST429, and AW339 Transducers to be free from defects and workmanship under normal use for a period of two (2) years from date of original purchase. - Page 20 © 2009 Clark Synthesis, Inc. All Rights Reserved. Clark Synthesis, Inc. Telephone: 303.797.7500 Fax: 303.797.7501 Email: info@clarksynthesis.com www.clarksynthesis.com www.clarksynthesis.com...
