TST429-Platinum, TST329-Gold, TST239-Silver, AW339-All Weather
CAUTION: THE TACTILE SOUND TRANSDUCER
CONTAINS AN EXTREMELY POWERFUL MAGNET.
DO NOT PLACE IN CLOSE PROXIMITY TO TV SETS,
VIDEO MONITORS, AND MAGNETIC MEDIA (TAPES).
tactile sound transducer
Installation Guide
Table of Contents
Installation...
Laminated I-Beam Floors
Wood Decks
Troubleshooting
Warranty
1
2
3
4
5
7
8
9
10
11
13
14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clark Synthesis AW339
Summary of Contents for Clark Synthesis AW339
-
Page 1: Table Of Contents
TST429-Platinum, TST329-Gold, TST239-Silver, AW339-All Weather CAUTION: THE TACTILE SOUND TRANSDUCER CONTAINS AN EXTREMELY POWERFUL MAGNET. DO NOT PLACE IN CLOSE PROXIMITY TO TV SETS, VIDEO MONITORS, AND MAGNETIC MEDIA (TAPES). tactile sound transducer Installation Guide Table of Contents Introduction Related Products... -
Page 2: Introduction
TACTILE SOUND TRANSDUCER WARRANTY Clark Synthesis, Inc. warranties Transducers TST239, TST329, TST429, and AW339 to be free from defects and workmanship under normal use for a period of two (2) years from date of original purchase. For industrial or commercial use, the warranty period is six (6) months. -
Page 3: Troubleshooting
Clark Synthesis, Inc. wants to help make every installation the best it can be because we are proud of our superior technical support. However, before calling us directly to discuss any technical issues, please consult the following troubleshooting information. Clark Synthesis technical support can be reached by calling 303.797.7500, weekdays from 9am to 5pm, Mountain Standard Time or by emailing us at info@clarksynthesis.com. -
Page 4: Supplied/Required/Optional Items
• Power amplifier: ...for the TST239, rated between 75 and 125 watts @ 4 ohms..for the TST329, TST429, and AW339, rated between 125 and 150 watts @ 4 ohms. OPTIONAL AUDIO COMPONENTS • Equalizer to tailor the frequency response of the Transducer(s) -
Page 5: General Installation Tips
Wiring & Connections Wiring the Transducer is essentially the same as wiring speakers: • Use 16AWG or heavier speaker wire. • Make sure all audio components are OFF before connecting the Transducer. The diagrams on the following pages show a stereo amplifier powering two Transducers. If only one Transducer is being used –... -
Page 6: Installation Overview
Installation Type: Hanger Bolt Installation Type: Hanger Bolt The AW339-All Weather Transducers are recommended for use on outdoor installations, including decks, boat docks, etc. For decks, we recommend using one (1) All Weather Transducer for every 10 ft. by 10 ft. section of deck. For example, if you have a deck that measres 10 ft. - Page 7 Installation: Laminated I-Beam Floors LAMINATED I-BEAM FLOORS Laminated I-Beam Joists The Transducer will be mounted to a bridge that spans adjacent floor joists and is parallel to the floor. Steps for installation using the Unimount Bracket 1. Attach the Unimount Bracket to the mounting surface using machine screws with flat washers and lock washers.
-
Page 8: Traditional Floors & Platforms
Bridge should be min. 3/4" thick and 6" – 8" wide. platform and the floor (see Page 2). MOUNTING DETAIL NOTE: Clark Synthesis does not recommend using MDF (medium-density fiberboard) in a platform. Washers Steps for installation using the Hanger Bolt...
