C L A R K S Y N T H E S I S

TACTILE SOUND ®

For additional questions/concerns/issues, contact

Clark Synthesis or visit our web site.

Clark Synthesis, Inc.

8020 Southpark Circle, Suite 600

Littleton, CO 80120

Phone: 1-800-898-1945

Fax: 303-797-7501

Web: www.clarksynthesis.com

Email: info@clarksynthesis.com

www.clarksynthesis.com

C L A R K S Y N T H E S I S

TACTILE SOUND ®

OEM Installation Guide

AW339 All-Weather Transducer-

Hot Tub/Spa Installation

CAUTION: STRONG MAGNETS ARE USED IN THIS PRODUCT.

AVOID CONTACT WITH, OR PLACEMENT NEAR, ITEMS THAT CAN

BE DAMAGED OR AFFECTED BY MAGNETIC FIELDS.

CAUTION: THIS SPEAKER IS DESIGNED FOR OUTDOOR USE.

HOWEVER, THE SPEAKER IS NOT WATERPROOF AND SHOULD

NOT BE EXPOSED TO CONTINUOUS WATER FLOW OR BE

SUBMERGED IN ANY WAY.

CAUTION: DO NOT TIGHTEN THE JAM NUT TO THE BRASS NUT

BY TURNING THE TRANSDUCER. THIS WILL RESULT IN SEVERE

DAMAGE TO THE TRANSDUCER AND WILL VOID THE WARRANTY.

Need help?

Do you have a question about the AW339 and is the answer not in the manual?

Page 1 C L A R K S Y N T H E S I S TACTILE SOUND ® For additional questions/concerns/issues, contact Clark Synthesis or visit our web site. Clark Synthesis, Inc. 8020 Southpark Circle, Suite 600 Littleton, CO 80120 Phone: 1-800-898-1945 Fax: 303-797-7501 Web: www.clarksynthesis.com...
Page 2 AW339- HOT TUB OEM INSTALL The AW339 mounting bracket is the component used to attach the transducer to the hot tub or spa. The mounting bracket and related hardware come in the transducer package. The mounting bracket assembly includes the mounting bracket, a threaded stud, and two jam nuts (see diagram below).
