V I S UA L P E R F O R M A N C E
V P 4 6 R S S T / S U R , V P 6 2 R S S T / S U R ,
V P 6 6 R S S T / S U R , V P 8 6 R S S T / S U R
Product Family Overview
From the company that invented the category, comes the
BEST
SOUNDING, best looking and most complete range of
in-wall and in-ceiling speakers ever. Visual Performance
V P 4 6 R
V P 6 2 R
S S T / S U R
S S T / S U R

Features and Benefits

SST = Single Stereo Technology, mono summing
SUR = Surround
Sold as each. When purchasing for a Surround System;
remember to purchase (2) SUR.
SST/SUR is a combination of SST and SUR in one speaker
• Uses a switch on the crossover cover to select between
SST or SUR
Absolute best sonic performance at all price points
• Designed using state-of-the-art computer modeling software
to vastly improve magnetic field and suspension linearity
for consistent sonic performance at any SPL for
best-in-class performance
Latest high-tech driver and tweeter material technology
• Improved low frequency performance
• Improved driver cone materials
• Low diffraction driver design
• Pivoting woofers on VP62R, VP66R and VP86R
• Chambered midrange and tweeter design on all models
comes in various shapes and sizes to compliment down lights and
décor and a complete range that allows you to enjoy a consistent
Series
aesthetic for any application in any room.
®
V P 6 6 R
S S T / S U R
The chambered tweeter design does the following
• Lowers the resonance frequency of the tweeter
• Allows for a lower crossover frequency to the woofer
• Reduces the back pressure on the tweeter dome
• Reduces the distortion of the tweeter near the
crossover frequency
Easier to install
• Easier to access Roto-Lock
• Removed metal hang tabs
• One-piece paintable grille with peel and stick scrim cloth for
easier painting
• Two piece toggle feet allows installation with double dry wall
and thicker ceiling and wall materials
S E R I E S
®
V P 8 6 R
S S T / S U R
Square Adapter w/ Grille
®
screws

Advertisement

loading
Need help?

Need help?

Do you have a question about the Visual Perfomance VP46R SST/SUR and is the answer not in the manual?

Questions and answers

Summary of Contents for Sonance Visual Perfomance VP46R SST/SUR

  • Page 1: Features And Benefits

    V I S UA L P E R F O R M A N C E S E R I E S ® V P 4 6 R S S T / S U R , V P 6 2 R S S T / S U R , V P 6 6 R S S T / S U R , V P 8 6 R S S T / S U R Product Family Overview From the company that invented the category, comes the...
  • Page 2: Specifications

    Diameter VP46R SST/SUR Specifications Diameter: 6 7/8” (175mm) Depth: 3 3/4” (95mm) Height 6.29 [159.8] 6.29 [159.8] Cut Out Diameter: 5 7/8” (149mm) With Square Adapter and Grille Ø6.31 [ 160] Ø6.31 [ 160] Width: 7” (178mm) Cut Out Height: 7”...
  • Page 3 SPECIFICATIONS VP46R SST/SUR +VP4SQ VP62R SST/SUR +VP6SQ VP66R SST/SUR +VP6SQ VP86R SST/SUR +VP8SQ 93023 93024 93025 93026 Each Each Each Each Two 1" (25mm) powder coated Two 1" (25mm) cloth dome, Two 1" (25mm) powder coated Two 1" (25mm) powder coated Tweeter aluminum dome, Ferrofluid-cooled, Ferrofluid-cooled,...
  • Page 4 Dealer/Distributor, will be free from defective workmanship and materials for the life of the Product, except for the grille, which is warranted for five (5) years. Sonance will at its option and expense either repair the defect or replace the Product with a new or remanufactured Product or a reasonable equivalent.
