Fanned flue system boiler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation and Servicing

SB30e
Fanned Flue System Boiler
G.C. No. 41 920 31
This is a Cat I
The instructions consist of three parts, User, Installation and Servicing Instructions, which include the Guarantee Registration Card.
The instructions are an integral part of the appliance and must, to comply with the current issue of the Gas Safety (Installation and Use)
Saunier Duval appliances' are manufactured to the very highest standard so we are pleased
In the centre pages are to be found your Guarantee Registration Card, which we recommend you complete and
If this card is missing you can obtain a copy or record your registration by telephoning the Heatcall Customer
Our Guarantee gives you peace of mind plus valuable protection against breakdown by covering the cost of:
All replacement parts
All labour charges
All call-out charges
One Contact Local Service

Instructions for Use

To b e l e f t w i t h t h e u s e r
Appliance
2H
Regulations, be handed to the user on completion of the installation.

Guarantee Registration

Thank you for installing a new Saunier Duval appliance in your home.
to offer our customers' a Comprehensive First Year Guarantee.
return as soon as possible.
Service number 01773 828100.
REGISTER YOUR SAUNIER DUVAL APPLIANCE
Customer Services:
Tel: (01773) 828100
Fax: (01773) 828070
FOR 1ST YEAR GUARANTEE PROTECTION
CALL 0208 247 9857
Nottingham Road, Belper, Derbyshire. DE56 1JT
Tel: (01773) 824141 Fax: (01773) 820569
221872B.07.01
Hepworth Heating Ltd.,
General/Sales enquiries:
