Safety Instructions
. . . . . .2-7

Operating Instructions

Aluminum Foil . . . . . . . . . . . . . . . .13
Clock and Timer . . . . . . . . . . .15, 16
Oven . . . . . . . . . . . . . . . . . . . . . .10-25
Baking and Roasting . . . . . . . .13
Broiling, Broiling Guide . . . . . . .14
Oven Control . . . . . . . . . . . . .10, 11
Power Outage . . . . . . . . . . .12, 16
Preheating . . . . . . . . . . . . . . . . . . .13
Sabbath Feature . . . . . . . . .19, 20
Self-Cleaning . . . . . . . . . . . . .24, 25
Special Features . . . . . . . . . . . . .18
Timed Baking
and Roasting . . . . . . . . . . . . . . . .17
Surface Cooking . . . . . . . . . . . . .8, 9
Burner Assembly . . . . . . . . . .26-28
Burner Grates . . . . . . . . . . . . . . . . .26
Control Panel and Knobs . . . . .32
Cooktop Surface . . . . . . . . . . . . . .29
Door Removal . . . . . . . . . . . . . . . .30
Kick Panel . . . . . . . . . . . . . . . . . . . . .31
Lift-Up Cooktop . . . . . . . . . . . . . . .29
Oven Bottom . . . . . . . . . . . . . . . . .30
Oven Vents . . . . . . . . . . . . . . . . . . .29
Self-Cleaning . . . . . . . . . . . . . .24, 25
Racks . . . . . . . . . . . . . . . . . . . . . . . . .32
Stainless Steel Surfaces . . . . . . .29
Storage Drawer . . . . . . . . . . . . . . .31
Warming Drawer . . . . . . . . . . . . .31
Write the model and serial
numbers here:
Model # ____________________
Serial #______________________
You can find them on a label
on the front of the range behind
the warming drawer, storage
drawer or kick panel.
. . . . . . . . . . . .33-44
Air Adjustment . . . . . . . . . . . . . . . .43
Anti-Tip Device . . . . . . . . . . . .36, 44
Checking Burner Ignition . . . . . .42
Connecting the Range
to Gas . . . . . . . . . . . . . . . . . . . .37-40
Electrical Connections . . . . .41, 42
Leveling the Range . . . . . . . . . . .43
Location . . . . . . . . . . . . . . . . . . . . . .36
LP . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
. . . . . . . . . . . . . . . . . . . . . .45-48
. . . . . . . . . . . . . . . .49
Consumer
Support . . . . . . . . . . . . . .Back Cover
Warranty for Customers
in Canada . . . . . . . . . . . . . . . . . . . . .51
Warranty for Customers
in the U.S.A. . . . . . . . . . . . . . . . . . .50
Owner's Manual
& Installation
Instructions
JgB3000
JgB3001
JgB281
JgB300
JgB400
JgBP25
JgBP26
JgBP27
JgBP28
JgBP29
JgBP33
49-85177 04-2010 GE
