Surface Units And Drip Pans - GE JBW3 Use And Care & Installation Manual

Surface Units and Drip Pans

To clean the surface units, turn the control to the highest
setting for a minute. The coils will burn off any soil.
CAUTION
Be sure all the controls are turned to OFF and
the surface units are cool before attempting to
remove them.
Do not immerse the surface units in liquids of any kind.
Do not clean the surface units in a dishwasher.
Do not bend the surface unit plug terminals.
Do not attempt to clean, adjust or in any way repair
the plug-in receptacle.
To remove a surface unit:
To remove the drip pans for cleaning, the surface units
must be removed first.
Lift the surface unit about 1 inch above the drip pan
and pull it out.
Do not lift the surface unit more than 1 inch. If you
do, it may not lie flat on the drip pan when you plug
it back in.
Repeated lifting of the surface unit more than
1 inch above the drip pan can permanently damage
the receptacle.
Porcelain Enamel Cooktop
The porcelain enamel finish is sturdy but
breakable if misused. This finish is acid-resistant.
However, any acidic foods spilled (such as fruit
juices, tomato or vinegar) should not be permitted
to remain on the finish.
If acids spill on the cooktop while it is hot, use
a dry paper towel or cloth to wipe it up right away.
When the surface has cooled, wash with soap and
water. Rinse well.
(Electric Coil Models)
To replace a surface unit:
Drip Pans
Remove the surface units. Then lift out the drip pans.
For best results, clean the drip pans by hand.
Place them in a covered container (or a plastic bag)
with 1/4 cup ammonia to loosen the soil. Then scrub
with a soap filled scouring pad if necessary. Rinse with
clean water and polish with a clean soft cloth.
The drip pans may also be cleaned in the dishwasher.
Clean the area under the drip pans often.
Built-up soil, especially grease, may catch on fire.
Do not cover drip pans with foil. Using foil so close
to the receptacle could cause shock, fire or damage to
the range.
Drip Pan
(Electric Coil Models)
Replace the drip pan into the recess in the cooktop.
Make sure opening in the pan lines up with the
receptacle.
opening in the drip pan and into the receptacle.
Guide the surface unit into place so it rests evenly.
For other spills such as fat smatterings, wash with
soap and water or cleansing powders after the surface
has cooled. Rinse well. Polish with a dry cloth.
(continued next page)
25
