Model No. RBTL69211.1

USER’'S MANUAL

Serial No.

Write the serial number in the space

above for reference.

Serial Number

Decal

ACTIVATE YOUR

WARRANTY

To register your product and

activate your warranty today,

go to www.reebokservice.com/

registration.

CUSTOMER CARE

For service at any time, go to

www.reebokservice.com.

Or call 1-877-994-4999

Mon.––Fri. 6 a.m.––6 p.m. MT

Sat. 8 a.m.––4 p.m. MT

Please do not contact the store.

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

Need help?

Do you have a question about the RBTL69211.1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Reebok RBTL69211.1

Page 1 Model No. RBTL69211.1 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.reebokservice.com/ registration. CUSTOMER CARE For service at any time, go to www.reebokservice.com.
Page 2 Apply the decal in the location shown. Note: The decals may not be shown at actual size. REEBOK and the Vector Logo are registered trademarks and service marks of Reebok. This product is manufactured and distributed under license from Reebok International.
Page 3 16. To purchase a surge suppressor, see 4. The treadmill is intended for home use only. your local REEBOK dealer, call the telephone Do not use the treadmill in any commercial, number on the front cover of this manual, or rental, or institutional setting.
Page 4 20. The heart rate monitor is not a medical 24. Do not change the incline of the treadmill by device. Various factors, including the user’’s placing objects under the treadmill. movement, may affect the accuracy of heart rate readings. The heart rate monitor is 25.
Page 5 STANDARD SERVICE PLANS...
Page 6 BEFORE YOU BEGIN Thank you for selecting the new REEBOK ® reading this manual, please see the front cover of this COMPETITOR RT 6.0 treadmill. The COMPETITOR manual. To help us assist you, note the product model RT 6.0 treadmill provides an impressive selection of number and serial number before contacting us.
Page 7 PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
Page 8 ASSEMBLY •• To hire an authorized service technician •• To identify small parts, see page 7. to assemble your exercise equipment, call 1-800-445-2480. •• Assembly requires the following tools: the included hex keys •• Assembly requires two persons. one adjustable wrench ••...
Page 9 2. Make sure that the power cord is unplugged. Locate the Upright Wire (70) bundled around the front of the Base (80). Cut the plastic tie securing the Upright Wire. Then, route the Upright Wire out of the indicated hole. Press a Base Cap (77) into each side of the Base (80).
Page 10 4. Hold the Left Upright (75) against the Base (80). Be careful not to pinch the wires. Partially tighten three 3/8" x 4" Screws (4) with three 3/8" Star Washers (5) into the Left Upright and the Base; do not fully tighten the Screws yet. Attach the Right Upright (not shown) in the same way.
Page 11 6. Identify the left Handrail (71). If there is a wire in the Handrail, remove and discard it. Hold the left Handrail (71) near the Left Upright (75). Insert the wire tie on the Upright Wire (70) into the bottom and out of the end of the Handrail as shown.
Page 12 8. Identify the Left and Right Trays (34, 35). Attach the Trays (34, 35) to the Console Base (83) with eight #8 x 1/2" Screws (9). Note: It may be easier to start the two inside Screws and then slide the Trays into place before starting the other six Screws.
Page 13 10. With the help of a second person, hold the con- sole assembly near the Handrails (71) (only one Console is shown). Assembly Connect the ground wire from the console assembly to the Console Ground Wire (89) on the Pulse Crossbar (31). Connect the Upright Wire (70) to the console wire.
Page 14 12. Attach the Pulse Crossbar (31) to the console assembly with six #8 x 1/2" Screws (9). Start all Console six Screws, and then tighten them. Assembly Firmly tighten the four 5/16" x 5/8" Screws (7). 13. Firmly tighten all six 3/8" x 4" Screws (4). Slide the Left and Right Base Covers (73, 74) down.
Page 15 14. Raise the Frame (49) to the position shown. Have a second person hold the Frame until this step is completed. Orient the Storage Latch (51) so that the large barrel and the latch knob are oriented as shown. Attach the lower end of the Storage Latch (51) to the Base (80) with a 3/8"...
Page 16 OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same damaged by sudden voltage changes in your home’’s...
Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’’s stereo sound system The treadmill console offers an impressive array of while you exercise. features designed to make your workouts more effec- tive and enjoyable.
Page 18 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
Page 19 5. Follow your progress with the displays. To measure your heart The matrix——When rate, stand on you select the manual the foot rails mode, the matrix will and hold the display a track that rep- pulse bar with resents 1/4 mile (400 your palms on m).
Page 20 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the profile flashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
Page 21 HOW TO USE THE WEIGHT LOSS CENTER 4. Follow your progress with the displays. 1. Insert the key into the console. See step 5 on page 19. See HOW TO TURN ON THE POWER on Note: The calorie goal is an estimate of the page 18.
Page 22 HOW TO USE AN IFIT WORKOUT During the workout, the voice of a personal trainer will guide you through the workout. To purchase iFit cards at any time, go to www.iFit.com or call the telephone number on the front cover of this If the speed or incline setting for the current manual.
Page 23 THE INFORMATION MODE An ““E”” for English miles or an ““M”” for metric kilome- The console features an information mode that keeps ters will appear in the right track of the total distance that the walking belt has display. Press the Speed moved and the total number of hours that the treadmill increase button to change has been used.
Page 24 HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left.
Page 25 TROUBLESHOOTING Most treadmill problems can be solved by follow- c. Remove the key from the console, and then ing the simple steps below. Find the symptom that reinsert it. applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual. d.
Page 26 Lower the treadmill. Next, remove the three begin calibrating, press the Stop button again, and indicated #8 x 3/4" Screws (6). Carefully slide the then press the Incline increase or decrease button Motor Hood (57) off. again. When the incline is calibrated, remove the key from the console.
Page 27 SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first when walked on remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the walking belt is off-center, first remove the screws clockwise, 1/4 of a turn.
Page 28 EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
Page 29 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch ——never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
Page 30 NOTES...
Page 31 PART LIST Model No. RBTL69211.1 R1212A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Ground Screw Drive Motor 3/8" x 2 1/2" Bolt Frame Spacer 3/8" Nut Frame 3/8" x 4" Screw Right Foot Rail 3/8" Star Washer Storage Latch #8 x 3/4"...
Page 32 EXPLODED DRAWING A Model No. RBTL69211.1 R1212A...
Page 33 EXPLODED DRAWING B Model No. RBTL69211.1 R1212A...
Page 34 EXPLODED DRAWING C Model No. RBTL69211.1 R1212A...
Page 35 EXPLODED DRAWING D Model No. RBTL69211.1 R1212A...
Page 36 ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
