Surround multi flow refrigerator

Advertisement

1.Safety Instructions

WARNING
Improper use whitch can cause physical damage - personal injury.
ATTENTION
Improper use whitch can cause injury or material damage to the household
BE SURE TO KEEP
NO/NEVER
DO NOT DISASSEMBLE
WARNING
VENTILATION
In case of gas leak,
ventilate the room
instead of unplugging
the refrigerator.
Explosion or fire may
happen.
EXCLUSIVE
POWER
OUTLET
Use exclusive power out-
let for the refrigerator
only.
Several plugs in an outlet
may cause fire.
Do not use a double outlet
or extension cord.
DO NOT TOUCH
UNPLUG
GROUND
CLEAN PLUG
Unplug and clean it with dry
cloth if dirty.
Dusty and dirty plug
may cause fire.
ATTENTION
Do not eat any frozen
food immediately from
the freezer compart-
ment.
It can get you cold-burns.
DISCARDING
When discarding the refrig-
erator, remove the door
packing.
Children may be trapped
inside it.
2
WARNING
NO
Never install the refrig-
erator where there is
much moisture and
water can splash.
It can be a danger of
short circuit or fire.
NO
The power cord should
not be twisted or crushed
under heavy things.
Peeled cord causes
electric shockor fire.
NEVER USE
When you smell some-
thing strange burning out
of refrigerator, unplug it to
stop running
It's very dangerous to keep
the abnormal refrigerator
running on and on.
NEVER USE
Never use any spray near
the refrigerator.
It can cause danger of
explosion.
NO
Do not put heavy things or
water contained tanks on top
of refrigerator.
It's dangerous when they fall
down and fire by short circuit
can happen.
NO
Do not allow children to
hang on the doors.
The refrigerator may
be tipped over to hurt
children.
NEVER USE
Never use plug if it is
loose.
There can be electric shock
or fire by short circuit.
NEVER EAT
Never eat deteriorated food
stored too long in the refrig-
erator or in the out-of-order
refrigerator.
You can be food-poisoned.
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-700CB and is the answer not in the manual?

Questions and answers

Summary of Contents for Daewoo FR-700CB

  • Page 1: Safety Instructions

    1.Safety Instructions WARNING Improper use whitch can cause physical damage - personal injury. WARNING ATTENTION Improper use whitch can cause injury or material damage to the household Never install the refrig- Do not put heavy things or erator where there is water contained tanks on top much moisture and of refrigerator.
  • Page 2: Installation

    WARNING ATTENTION NEVER NEVER MOVING/ MOVING / STORE DISASSEMBLE CARRYING CARRYING This refrigerator is for Do not repair the When you move the Lift the refrigerator up storing only foods. refrigerator on your own. refrigerator, take all the enough not to scratch a foods out and empty the soft floor.
  • Page 3: Right Usage Of Refrigerator

    2.Right usage of Refrigerator ATTENTION POWER HAND OVER Plug in the refrigerator right after installation. Install the refrigerator on a firm and level floor, FAILURE making enough space(more than 10cm) to the Handing over this refrigerator, you’d better give side wall. In case of power failure, user’s guide together to him/her.
  • Page 4: Suitable Installation Place

    3.Installation Instructions 3) Installation Process 1) Suitable Installation Place Plug in the refrigerator. (Be sure to check your Attatch the height adjustable legs to their holes Where the floor is solid Where ventilation is good Where there is little or no heat, local / area voltage !) in the left and right bottom of refrigerator.
  • Page 5: Grounding

    4) Carrying & Moving 5) Grounding Detatch front cover not to be broken when moving. Grounding terminal is the green one connected to the power cord in the back of refrigerator. Unplug in the refrigerator. Take all the foods out. Grounding is necessary water can splash easily ;...
  • Page 6: Name Of Each Part & Function

    4.NAME OF EACH PART & FUNCTION FREEZER COMPARTMENT SHELF OUTLET FOR AIR-CURTAIN/QUICK-POCKET • Provided to make ice or store frozen food. • If fresh food compartment door is opened, cold air is injected for one minute to block the outer warm air.
  • Page 7: Control Buttons & Indicators

    5.CONTROL BUTTONS & INDICATORS Temperature Indicator of Temperature Indicator of Fresh Temperature Regulation Button of Freezer Compartment Food Compartment Fresh Food Compartment Set temperature(ECONO, 1, 2, 3, QF) is Set temperature(ECONO, 1, 2, 3, QR) is By pressing this button, fresh food compartment indicated.
  • Page 8: Temperature Setting & Regulation

    6. TEMPERATURE SETTING & REGULATION SILENT CONTROL FREEZER COMPARTMENT Press button. When you want to run Quick Freeze, press this FRZ.SET Press this button and It goes back to former When you want to stop it, regulation button to choose the indicator of indicator lights up.
  • Page 9: Fresh Food Compartment

    FUNCTION FRESH FOOD COMPARTMENT It reduces the refrigerator’s noise about 2 hours before sleeping when the noise sounds louder Silent Control and gives you cozy sleeping. • Use this function before you go to bed. Press button. When you want to run Quick Refrigeration, REF.SET press this regulation button to choose the •...
  • Page 10: Care & Cleaning

    7.CARE & CLEANING Before Cleaning While Cleaning After Cleaning • When the outside(cabinet, doors) is stained with cooking oil or dirt, wipe it • Don’t pour water to the refrigerator directly. • See to the followings after cleaning. If something’s wrong, call out quickly.
  • Page 11: Helpful Hints

    8.Helpful Hints 9.Efficient Storage of Foods Be sure to wrap foods - fish, meat, etc. - to be stored in the freezer compartment to avoid odor. When you 1. Unplug the refrigerator. Light bulb of replace the 2. Pull the light shield down forward, turn to take the bulb out. freezer Divide foods into one-time 3.
  • Page 12 10.Looks Out of Order, But, Not. Refrigerator Is Not Wrong or Out of Order In These Cases ... Before calling for service, check the followings. Foods freeze in the Refrigerator never get Refrigerator does not Refrigerator is noisy. • Moisture can be formed during the rainy season or continuous hot fresh food compartment cold.
  • Page 13: Table Of Contents

    (3) Fresh Food Compartment ....18 (4) Quick Pocket ........18 (5) Explanation of Function ....19 Should you require after sales service for this product, please contact customer service of DAEWOO Electronics 7. Care & Cleaning ........20 8. Helpful Hints .......... 22 Sales UK (Tel : 01189-252520) or the dealer you purchased the product from.
