Mr. Heater Heatstar HS50KT Operating Instructions And Owner's Manual
Kerosene forced-air heater
Hide thumbs
Also See for Heatstar HS50KT:
- Operating instructions and owner's manual (20 pages) ,
- Operating instructions and owner's manual (9 pages)
Advertisement
Table of Contents
- 1 Table of Contents
- 2 Warnings
- 3 Heater Specifications
- 4 Operating Precautions
- 5 Safety Precautions
- 6 Start Up/Shut Down/Restart
- 7 Operating Instructions
- 8 Maintenance, Storage and Service
- 9 Wiring Diagram
- 10 Parts List
- 11 Exploded View
- 12 Warranty
- 13 Instructions for Ordering Parts
- Download this manual
OPERATING INSTRUCTIONS AND OWNER'S MANUAL
MR. HEATER
MH50KT, MH75KT,
MH125KT, MH175KT
KEROSENE
FORCED-AIR HEATER
If the information in this manual is not followed exactly, a fire or explosion
WARNING:
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— Service must be performed by a qualified service agency.
This is an unvented portable heater. It uses air (oxygen) from the area in which it is used. Adequate
combustion and ventilation air must be provided. Refer to page 3.
READ INSTRUCTIONS CAREFULLY: Read and
follow all instructions. Place instructions in a
safe place for future reference. Do not allow
anyone who has not read these instructions to
assemble, light, adjust or operate the heater.
ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-881-5500
Serial Numbers 0117001 - 0148811
HEATSTAR
HS50KT, HS75KT,
HS125KT, HS175KT
UL-733, &CSA/CAN3-B140.9.3
04/04 Revision L1 #70276
Advertisement
Table of Contents
Related Manuals for Mr. Heater Heatstar HS50KT
Summary of Contents for Mr. Heater Heatstar HS50KT
- Page 1 READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has not read these instructions to HS50KT, HS75KT, MH50KT, MH75KT, assemble, light, adjust or operate the heater. HS125KT, HS175KT...
-
Page 2: Table Of Contents
WARNING: WARNING: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS, NOT FOR HOME OR RECREATIONAL VEHICLE USE SO PLEASE READ THESE INSTRUCTIONS BEFORE YOU OPERATE THIS HEATER. WARNING: GENERAL HAZARD WARNING: FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH AS BUILDING FAILURE TO COMPLY WITH THE PRECAUTIONS AND MATERIALS, PAPER OR CARDBOARD, A SAFE DIS- INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN... -
Page 3: Heater Specifications
SPECIFICATIONS Type of Fuel: For use with Kerosene or #1 Fuel Oil ONLY on ALL models. Model ........50K ..........75KT ........125KT ........175KT Burn Rate: ........ 50,000 Btu/hr (15 kW) ....75,000 Btu/hr (22 kW) ..125,000 Btu/hr (37 kW) ... 175,000 Btu/hr (51 kW) Fuel Rate: ......... -
Page 4: Operating Instructions
Assemble the wheels onto the wheel support frame as For all models: In cold weather, starting may be follows: improved by holding a finger over the end of the pressure adjusting screw until the heater starts. This unit Install one of the cotter pins into the hole on one end of is equipped with a circuit breaker located near the power axle. -
Page 5: Maintenance, Storage And Service
MAINTENANCE AND STORAGE AIR AND FUEL LINES. If the air or fuel lines are removed during cleaning, be sure all connections are tight before WARNING. To prevent personal injury, unplug the heater operating unit. from the wall outlet before servicing. AIR PRESSURE SETTING. -
Page 6: Wiring Diagram
—— ——— M8783 M8783 Hose Barb Adaptor M6850 M6850 M6850 M6850 Ball,. Pressure adj. —— M8682 M8683 M8683 Logo, Mr. Heater M6851 M6851 M6851 M6851 Spring, Pressure adj. —— M8790 M8790 Adapter, T-hose barb M6863 M6863 M6863 M6863 Oil Flame Control Ass’y... -
Page 7: Exploded View
Kerosene Forced Air Construction Heater • Model #50, #75KT, #125KT and #175KT Enerco Group, Inc. | Kerosene Forced Air Heater Operating Instructions and Owner’s Manual... -
Page 8: Warranty
